DOOSAN SOLAR 400LC-V SOLAR 420LC-V EXCAVATOR 2401-6357A 401-00004 TRAVEL MOTOR ROTARY GROUP AND SPARE ARTS

DOOSAN SOLAR 400LC-V SOLAR 420LC-V EXCAVATOR 2401-6357A 401-00004 TRAVEL MOTOR ROTARY GROUP AND SPARE ARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
2401-6357A 401-00004
SOLAR 400LC-V SOLAR 420LC-V
Pos. Part No Qty Parts name Comments
-. 2401-6357A [1]   TRAVEL DEVICE
-. 401-00004 [1]   MOTOR;TRAVEL
1 2423-7013 [1]   CASING
10 2414-7003 [1]   COUPLING
11 2412-7005 [1]   PLATE;SWASH
12 138-00001 [1]   JOINT;BALL
13 2429-7003 [1]   HOLDER;SPRING
14 2409-7006 [9]   PISTON
15 2180-7137 [1]   D-RING
16 2180-7138 [1]   D-RING
17 2420-7032 [3]   VALVE;CHECK
18 115-00001 [1]   RING;RETAINING
19 115-00002 [1]   RING;RETAINING-C TYPE
2 2627-7009 [1]   COVER;REAR
20 2128-7004 [1]   SHIM
21 2409-7007 [1]   PISTON SHIFTER
22 2148-7006 [1]   BALL
23 2171-7004 [2]   PIVOT
24 2180-7135 [1]   SEAL;PISTON
25 426-00010 [1]   RESTRICTOR(0.6)
26 426-00011 [1]   RESTRICTOR(0.8)
27 2180-7136 [3]   SEAL;OIL
28 2129-7028 [1]   SPRING;CHECK VALVE
29 2129-7027 [9]   SPRING;CYLINDER
3 2441-7005 [1]   BLOCK;CYLINDER
30 2129-7026 [14]   SPRING;BRAKE
31 2109-7047 [1]   BEARING
32 2109-7048 [1]   BEARING;NEEDLE
33 S2224661 [10]   BOLT;SOCKET
34 2123-7054 [2]   PIN;PARALLEL
35 S8000061 [3]   O-RING
36 S8000081 [2]   O-RING
37 S8000091 [5]   O-RING
38 2180-7139 [1]   O-RING
39 2180-7140 [1]   O-RING
4 2223-7003 [1]   RETAINER;SHOE
40 420-00005 [2]   VALVE;OVER LOAD RELIEF
41 420-00006 [1]   VALVE;PILOT
42 420-00007 [1]   VALVE;BRAKE
43 2114-7112 [1]   SPACER
44 S8010351 [2]   O-RING
5 2412-7003 [4]   PLATE;FRICTION
6 2452-7006 [1]   PISTON;BRAKE
7 2352-7004 [5]   PLATE;SEPARATING
8 2412-7004 [1]   PLATE;VALVE
9 2405-7002 [1]   SHAFT
A. K9000979 [1]   PISTON ASS'Y
B. K9000980 [1]   SWASH PLATE ASS'Y
C. K9000981 [1]   SHIFTER PISTON ASS'Y
E. K9000982 [1]   SHOE RETAINER ASS'Y
