DOOSAN K1006575C 170301-00055 170301-00055A 170301-00055B 170301-00055C K1006576A SWING DEVICE ASSY;K1007545 SWING MOTOR PARTS

DOOSAN K1006575C 170301-00055 170301-00055A 170301-00055B 170301-00055C K1006576A SWING DEVICE ASSY;K1007545 SWING MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
K1006575C 170301-00055 170301-00055A 170301-00055B 170301-00055C K1006576A SWING DEVICE ASSY;
K1007545 SWING MOTOR
Pos. Part No Qty Parts name Comments
*. K9002069 [1]   SEAL KIT;SWING MOTOR
-. K1007545 [1]   MOTOR;SWING
1 1.451-00145 [1]   BODY
10 1.131-00070 [9]   SPRING
11 1.427-00007 [1]   SEAT;BALL GUIDE
12 1.429-00008 [1]   GUIDE;BALL
13 *NA00834 [1]
14 1.409-00175 [1]   PISTON ASS'Y
15 1.412-00063 [4]   PLATE;FRICTION
16 1.412-00025 [4]   PLATE
17 1.409-00187 [1]   PISTON;BRAKE
18 2180-1217D160 [2]   O-RING
19 1.131-00071 [19]   SPRING
2 1.180-00523 [1]   SEAL;OIL
20 *NA00839 [1]   . HEAD
21 1.123-00042 [2]   PIN
22 1.109-00058 [1]   BEARING;NEEDLE
23 K9002105 [1]   COVER;REAR
24 S2218661 [7]   BOLT;SOCKET
25 S2219571 [1]   BOLT;SOCKET
26 1.426-00010 [2]   POPPET
27 1.131-00072 [2]   SPRING
28 1.181-00103 [2]   PLUG;DRAIN
29 S8000291 [2]   O-RING
3 1.109-00066 [1]   BEARING;ROLLER
30 1.420-00122 [2]   RELIEF VALVE ASS'Y
31 K9002106 [1]   VALVE;TIME DELAY
32 S2206161 [3]   BOLT;SOCKET
33 2181-1116D2 [3]   PLUG
34 K9000942 [2]   VALVE;SWING REACTIONLESS
35 K9000943 [2]   PLUG
36 S8000181 [2]   O-RING
37 K9000944 [2]   RING;BACK UP
38 S8000121 [2]   O-RING
39 2180-1217D159 [1]   O-RING
4 1.115-00100 [1]   RING;SNAP
40 1.110-00172 [1]   BUSHING
41 K9002107 [1]   ROTARY KIT
42 K9002108 [1]   CYLINDER BLOCK KIT
43 K9002109 [1]   RETAINER KIT
5 1.405-00025 [1]   SHAFT
6 1.123-00041 [1]   PIN
7 1.115-00371 [1]   RING;STOP
8 1.412-00113 [1]   PLATE;SHOE
9 *NA00427 [1]
Parts on group DX380LC:
Pos. Part No Qty Parts name Comments
-. K1006574C [-]   SWING DEVICE INSTALL
1 K1006575C [1]   SWING DEVICE SUB ASS'Y   170301-00055
1 170301-00055 [1]   170301-00055A
1 170301-00055A [1]   170301-00055B
1 170301-00055B [1]   170301-00055C
1 170301-00055C [1]
1-1. K1006576A [1]   SWING DEVICE ASS'Y
1-1A. K1007545 [1]   MOTOR;SWING
1-1B. 2404-1065 [1]   GEAR;PINION
1-1C. 2403-1046A [1]   COVER
1-1D. 2120-4006 [4]   BOLT M16X2.0X40
1-1E. 2126-9001 [2]   WIRE
1-1F. 2182-1706A [1]   PIPE
1-1G. 2119-1063A [1]   CAP   2119-1063B
1-1G. 2119-1063B [1]   . CAP
1-1H. 2181-1110D10 [1]   ADAPTER
1-1I. 404-00094B [1]   GEAR;REDUCTION   130426-00014
1-1I. 130426-00014 [1]   130426-00014A
1-1I. 130426-00014A [1]
1-2. 2181-1110D22 [1]   . ADAPTER
1-3. 181-00717 [1]   . ELBOW
1-4. 121-00010D3 [1]   . NUT
1-5. 2181-1950D7 [1]   . PLUG   DS2901008
1-5. DS2901008 [1]   . PLUG
1-6. S8000181 [1]   O-RING
1-7. 2184-1060D172 [1]   HOSE
1-8. S5011113 [1]   . WASHER
10 160-00020 [1]   CAP
11 2181-1110D30 [1]   ADAPTER
12 124-00208D2 [1]   CLAMP
13 K1001029 [3]   BOLT
14 124-00208D7 [2]   CLIP
2 S0774766 [12]   BOLT M24X2.0X70
3 2114-1831A [12]   . WASHER
4 2123-1717B [2]   PIN;KNOCK
5 198-00028 [2]   CAP
6 2184-1046D148 [1]   HOSE PF1/4-1450L
7 181-00103 [1]   REDUCER
8 121-00006 [1]   NUT
9 S6710041 [1]   NIPPLE,GREASE
