DOOSAN DX80R E80 EXCAVATOR K1042873 170303-00032 170303-00032A 170303-00032B 170303-00032C 170303-00032E 170303-00032G SWING MOTOR ROTARY GROUP

DOOSAN DX80R E80 EXCAVATOR K1042873 170303-00032 170303-00032A 170303-00032B 170303-00032C 170303-00032E 170303-00032G SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
K1042873 170303-00032
170303-00032A 170303-00032B
170303-00032C 170303-00032E
170303-00032G
DX80R E80
Pos. Part No Qty Parts name Comments
*. K9006619 [1]   SEAL KIT;SWING MOTOR
-. 170303-00032 [1]
-. K1042873 [1]   MOTOR;SWING   170303-00032
1 *NA00342 [1]   CASING
11 K9006589 [1]   . BALL;THRUST
12 K9005957 [1]   . WASHER
13 K9006590 [3]   . ROLLER
14 2.114-00862 [2]   . WASHER
15 K9006591 [1]   . SPRING
16 S6510420 [1]   RING
17 K9006612 [1]   . BLOCK;CYLINDER
18 1.412-00064 [2]   PLATE;FRICTION
19 1.412-00073 [1]   PLATE;MATING
2 K9006595 [1]   CASING;VALVE
20 K9006594 [1]   PISTON;BRAKE
21 K9006592 [16]   SPRING;BRAKE
22 K9006596 [1]   PLATE;VALVE
23 K9006202 [2]   PLUNGER
24 K9006203 [2]   SPRING;CHECK
25 K9006180 [2]   PLUG
26 S5700621 [1]   PIN;PARALLEL
27 2180-1217D142 [1]   O-RING
28 2180-1217D147 [1]   O-RING
29 2180-1217D148 [1]   O-RING
3 K9006593 [1]   SHAFT;DRIVE
30 2180-1217D153 [1]   O-RING
31 S8000181 [2]   O-RING
31 S8000161 [2]   O-RING
32 S8000111 [2]   O-RING
33 S2215061 [4]   BOLT;SOCKET M12X1.75X25
34 S2206261 [3]   BOLT;SOCKET
35 2181-1950D1 [2]   PLUG
36 2181-1116D4 [1]   PLUG
37 S6500250 [4]   RING;RETAINING
38 K9006221A [2]
38 K9006221 [2]   VALVE;RELLEF   K9006221A
39 K9006609A [1]
39 K9006609 [1]   VALVE;BRAKE   K9006609A
4 K9006220 [1]   BEARING;ROLLER
40 K9006610 [1]   GAUGE;OIL LEVEL
5 K9006604 [1]   BEARING;BALL
6 K9006605 [1]   SEAL;OIL
7 K9006603A [1]   PLATE;SHOE
7 K9006603 [1]   PLATE;SHOE   K9006603A
8 K9006588 [1]   . PLATE;RETAINER
9 K9006611 [1]   PISTON ASSY
R1. *NA00348 [1]   CASING;GEAR
R11. K9006599 [3]   RING;INNER NO.2
R12. K9006190A [3]   RING,INNER;NO 1
R12. K9006190 [3]   RING(NO.1);INNER   K9006190A
R13. K9006608 [3]   BEARING;NEEDLE
R14. K9006219 [3]   BEARING;NEEDLE
R15. K9006600 [3]   GEAR;PLANET NO.2
R16. K9006192A [3]   GEAR,PLANETARY;(NO.1)
R16. K9006192 [3]   GEAR(NO.1);PLANET   K9006192A
R17. K9006601 [1]   GEAR;SUN;NO.2
R18. K9006194 [1]   GEAR,SUN;NO.1
R19. K9006196 [1]   WASHER(NO.1);THRUST
R2. K9006602A [1]   SHAFT,PINION
R2. K9006602 [1]   SHAFT;PINION   K9006602A
R20. K9006197 [1]   PLATE;THRUST
R21. K9006402 [9]   WASHER;THRUST
R22. K9006403 [3]   SCREW
R23. 2181-1116D3 [1]   PLUG;HEX. SOCKET
R24. 2181-1116D1 [2]   PLUG
R25. S2215271 [6]   BOLT;SOCKET
R26. K9006204 [3]   WASHER(NO.3);THRUST
R3. K9006694 [1]   BEARING;TAPER ROLLER
R3. K9006215 [1]   BEARING;TAPER ROLLER   K9006694
R4. K9006606 [1]   BEARING;TAPER ROLLER
R5. K9006607 [1]   SEAL;OIL
R6. K9006597 [1]   COVER;BEARING
R7. K9006187 [2]   COLLAR;HALF
R8. K9006598A [1]
R8. K9006598 [1]   CARRIER NO.2   K9006598A
R9. K9006188 [1]   CARRIER(NO.1)
170303-00032A 170303-00032B 170303-00032C 170303-00032E 170303-00032G
Pos. Part No Qty Parts name Comments
*. K9006619 [1]   SEAL KIT;SWING MOTOR
-. 170303-00032A [1]   170303-00032B
-. 170303-00032B [1]   170303-00032C
-. 170303-00032C [1]   170303-00032E
-. 170303-00032E [1]   170303-00032G
-. 170303-00032G [1]
1 *NA00342 [1]   CASING
100 130426-00021 [1]   130426-00021B
100 130426-00021B [1]
11 K9006589 [1]   . BALL;THRUST
12 K9005957 [1]   . WASHER
13 K9006590 [3]   . ROLLER
14 2.114-00862 [2]   . WASHER
15 K9006591 [1]   . SPRING
16 S6510420 [1]   RING
17 K9006612 [1]   . BLOCK;CYLINDER
18 1.412-00064 [2]   PLATE;FRICTION
19 1.412-00073 [1]   PLATE;MATING
2 K9006595A [1]   110913-00365
2 110913-00365 [1]   CASE,VALVE
20 K9006594 [1]   PISTON;BRAKE
201 100502-00197 [1]
202 100502-00198 [1]   100502-00198A
202 100502-00198A [1]
21 K9006592 [16]   SPRING;BRAKE
22 K9006596A [1]   PLATE,VALVE   250201-03893
22 250201-03893 [1]
23 K9006202 [2]   PLUNGER
23 410205-00082 [2]   PLUNGER
24 K9006203 [2]   SPRING;CHECK
25 K9006180 [2]   PLUG
26 S5700621 [1]   PIN;PARALLEL
27 2180-1217D142 [1]   O-RING
28 2180-1217D147 [1]   O-RING
29 2180-1217D148 [1]   O-RING
3 K9006593 [1]   SHAFT;DRIVE
30 2180-1217D153 [1]   O-RING
31 S8000181 [2]   O-RING
32 S8000111 [2]   O-RING
33 S2215061 [4]   BOLT;SOCKET M12X1.75X25
34 S2206261 [3]   BOLT;SOCKET
35 2181-1950D1 [2]   PLUG
36 2181-1116D4 [1]   PLUG
37 S6500250 [4]   RING;RETAINING
38 410127-00186 [2]
39 K9006609A [1]   410102-00049
39 410102-00049 [1]   VALVE,BRAKE
4 K9006220 [1]   BEARING;ROLLER
40 K9006610 [1]   GAUGE;OIL LEVEL   800108-00225
40 800108-00225 [1]   GAUGE,OIL LEVEL
41 S5700751 [2]
5 K9006604 [1]   BEARING;BALL
6 K9006605 [1]   SEAL;OIL
7 K9006603A [1]   PLATE;SHOE
8 K9006588 [1]   . PLATE;RETAINER
9 K9006611 [1]   PISTON ASSY
R1. *NA00348 [1]   CASING;GEAR
R12. K9006190A [3]   RING,INNER;NO 1
R13. 140104-00066 [3]   BEARING,NEEDLE
R14. K9006219 [3]   BEARING;NEEDLE
R15. 130413-00025 [3]   GEAR,PLANET;(NO.2)
R16. K9006192A [3]   GEAR,PLANETARY;(NO.1)
R17. K9006601 [1]   GEAR;SUN;NO.2
R18. K9006194 [1]   GEAR,SUN;NO.1
R19. K9006196 [1]   WASHER(NO.1);THRUST
R2. K9006602A [1]   SHAFT,PINION
R20. 250201-01716 [6]   PLATE,THRUST
R21. K9006402 [6]   WASHER;THRUST
R23. 2181-1116D3 [1]   PLUG;HEX. SOCKET
R24. 2181-1116D1 [2]   PLUG
R25. S2215271 [6]   BOLT;SOCKET
R26. 120501-02069 [3]
R26. 120501-02069A [3]
R27. S5740790 [3]   PIN,SPRING
R3. K9006694 [1]   BEARING;TAPER ROLLER
R4. K9006606 [1]   BEARING;TAPER ROLLER
R5. K9006607 [1]   SEAL;OIL
R54. 120501-02741 [3]
R6. K9006597 [1]   COVER;BEARING
R67. 123-00151 [1]   PIN D8X12L
R7. K9006187 [2]   COLLAR;HALF
R8. 100502-00172 [1]
R8. 100502-00172A [1]   CARRIER;NO.2
R9. 100502-00173 [1]
R9. 100502-00173A [1]
