DOOSAN DX80R E80 EXCAVATOR K1029668 K9006752 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

DOOSAN DX80R E80 EXCAVATOR K1029668 K9006752 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$600.00 USD
$600.00 USD
特價 售罄
結帳時計算運費。
K1029668 K9006752 DX80R E80
Pos. Part No Qty Parts name Comments
*. K9006767 [1]   SEAL KIT
--. K1029668 [2]   MOTOR;TRAVEL
102 K9006753 [1]   SHAFT
103 K9006754 [1]   PLATE;SWASH
104 K9006774 [1]   CYLINDER & PISTON KIT
105 K9006773 [1]   PISTON ASSY
107 K9006771 [1]   PLATE;RETAINER
108 K9006768 [1]   BALL;THRUST
109 K9006755 [1]   PLATE;TIMING
110 2.114-00862 [2]   . WASHER
111 2.114-00863 [1]   WASHER
112 2.409-00039 [1]   PISTON
113 K9005367 [10]   SPRING
114 K9006772 [1]   SPRING
115 1.412-00064 [2]   PLATE;FRICTION
116 1.412-00073 [3]   PLATE;MATING
132 K9006815 [1]   SEAL;OIL
135 2.180-00424 [1]   O-RING
139 2.180-00423 [1]   O-RING
145 S6530420 [1]   RING;SNAP
149 1.109-00023 [1]   BEARING;BALL
150 K9006776 [1]   BEARING;BALL
151 2.109-00172 [3]   ROLLER
161 K9006769 [1]   PISTON ASSY
167 2.540-00017 [2]   PIVOT
171 2.123-00169 [2]   PIN;PARALLEL
190 2.131-00087 [1]   SPRING
201 K9006763 [2]   VALVE;RELIEF
207 S8002701 [2]   . O-RING
208 S8060101 [4]   RING;BACK UP
211 S8000111 [2]   O-RING
212 S8000201 [2]   O-RING
215 S8002721 [2]   O-RING
216 K9006813 [4]   RING;BACK-UP
299 K9006764 [1]   REAR FLANGE ASSY
300 K9006765 [1]   REAR FLANGE KIT
301 *NA00460 [1]   . FLANGE;REAR
321 2.181-00460 [1]   PLUG
323 *NA01161 [1]   . SPOOL
324 K9006756 [2]   PLUG
325 2.131-00442 [2]   SPRING;RETAINER
327 K9006779 [2]   VALVE
328 K9006766 [2]   SPRING
330 K9006780 [2]   SPRING
336 S8000261 [2]   O-RING
338 S8000181 [3]   O-RING
342 S5700621 [1]   PIN;PARALLEL
345 S2215271 [8]   BOLT;SOCKET
352 2181-1116D1 [3]   PLUG
363 K9005396 [1]   SPOOL
366 K9006770 [1]   SPRING
368 S6250121 [1]   BALL;STEEL
375 2.181-00370 [3]   PLUG
382 2181-1890D4 [3]   PLUG
392 S8000141 [1]   O-RING
401 K9006752 [1]   MOTOR;TRAVEL
