DOOSAN DX80R E80 EXCAVATOR 401-00327 K1029884A INSTALLATION PUMP ROATRY GROUP

DOOSAN DX80R E80 EXCAVATOR 401-00327 K1029884A INSTALLATION PUMP ROATRY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
401-00327 K1029884A DX80R E80
Pos. Part No Qty Parts name Comments
-. K1029884A [-]   PUMP INSTALLATION
1 110508-09003 [1]
1 K1029881 [1]   COVER;PUMP   110508-09003
2 401-00327 [1]   PUMP ASS'Y
3 K1029882 [1]   COUPLING
4 S0521466 [2]   BOLT
5 S5102903 [2]   WASHER
6 S0512253 [12]   BOLT M10X1.5X30
7 S5102603 [12]   . WASHER
8 S2221066 [3]   BOLT;SOCKET
9 S5110903 [3]   WASHER
Parts on group DX80R:
Pos. Part No Qty Parts name Comments
1 K9006566 [1]   ROTARY GROUP
1-1. K9006553 [9]   PISTON ASSY
1-2. K9006569 [1]   CYLINDER
1-3. K9006564 [1]   PLATE;RATAINING
1-4. K9006555 [1]   BALL;RETAINING
1-5. K9006539 [1]   SPRING
1-6. K9006568 [3]   PIN;PRESSURE
1-7. K9006552 [1]   RING;SEEGER V
1-8. K9006540 [1]   WASHER;THRUST
1-9. K9006565 [1]   PLATE;DISTRIBUTOR
10 K9006558 [1]   COUPLER;GEAR SHAFT
12 K9006554 [1]   SHIM
15 K9006557 [1]   BEARING SET
17 K9006546 [2]   SHIM
2 K9006550 [1]   UNIT;CONTROL
2-1. K9006549 [1]   PISTON;CONTROL
2-2. *NA00501 [1]
2-3. K9006548 [1]   PISTON;COUNTER
2-4. *NA00501 [1]
2-6. K9006545 [1]   SPRING
20 K9006541 [1]   SEAL;SHAFT
22 K9006542 [1]   O-RING
23 K9006543 [4]   O-RING
24 K9006537 [1]   O-RING
25 K9006556 [1]   RING;SAFETY
27 S2218461 [4]   BOLT;SOCKET M14X2.0X40
28 S2212061 [2]   BOLT;SOCKET M10X1.5X25
30 K9006563 [1]   PLUG
33 K9006538 [1]   PIN;DOWEL
36 K9006574 [2]   WASHER
5 K9006551 [1]   HOUSING;PUMP
6 K9006567 [1]   PLATE;PORT
7 K9006561 [1]   PLATE;SWASH
8 K9006570 [1]   SHAFT;DRIVE
Parts on group DX80R:
Pos. Part No Qty Parts name Comments
-. 401-00327 [1]   PUMP ASS'Y
1 *NA01284 [1]   UNITE
10 K9006562 [1]   PIPE ASSY
10-2. K9006559 [2]   NIPPLE;GREASE
10-3. K9006560 [2]   RING;SPACER
12 K9006573 [1]   PUMP;GEAR
14 K9002215 [1]   PLUG
2 K9006572 [1]   VALVE;PILOT
2-2. 2180-1217D11 [3]   O-RING
2-3. S2205261 [4]   BOLT
3 K9006571 [1]   VALVE;PILOT
3-10. S5740600 [1]   PIN;SPRING
3-11. K9006544 [1]   CAP;INSULATION
3-2. K9006547 [1]   CARRIER LR
3-6. 2180-1216D26 [1]   O-RING
3-7. S2204661 [1]   SCREW;SOCKET
3-8. S2205061 [2]   BOLT;SOCKET M6X1.0X25
3-9. S5740490 [1]   PIN;SPRING
