DOOSAN DX60R SWING DEVICE GEAR PARTS

DOOSAN DX60R SWING DEVICE GEAR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
SWING DEVICE DX60R Doosan parts
R1. K9006211 [1]   CASING(D);GEAR   K9006211A
R1. K9006211B [1]   CASE,GEAR
R1. K9006211A [1]   K9006211B
R10. K9006204 [3]   WASHER(NO.3);THRUST
R11. K9006191 [3]   RING(NO.2);INNER
R12. K9006190 [3]   RING(NO.1);INNER
R13. K9006218 [3]   BEARING;NEEDLE
R14. K9006219 [3]   BEARING;NEEDLE
R15. K9006193 [3]   GEAR(NO.2);PLANET
R16. K9006192 [3]   GEAR(NO.1);PLANET
R17. K9006195 [1]   GEAR(NO.2);SUN
R18. K9006194 [1]   GEAR,SUN;NO.1
R19. K9006196 [1]   WASHER(NO.1);THRUST
R2. 130712-01903 [1]   SHAFT,PINION
R2. K9006212 [1]   SHAFT(D);PINION   K9006212A
R2. K9006212A [1]
R20. K9006197 [1]   PLATE;THRUST
R21. K9006402 [6]   WASHER;THRUST
R22. K9006403 [3]   SCREW
R3. K9006694 [1]   BEARING;TAPER ROLLER
R30. 401101-00036 [1]   PLATE,SEAL
R4. K9006695 [1]   BEARING;TAPER ROLLER
R5. K9006217 [1]   SEAL;OIL
R6. K9006186 [1]   COVER;BEARING
R7. K9006187 [2]   COLLAR;HALF
R8. 100502-00261 [1]   CARRIER(NO.1)
R8. K9006189 [1]   CARRIER(NO.2)
R9. 100502-00101A [1]   CARRIER(NO.1)
R9. K9006188 [1]   CARRIER(NO.1)
