DOOSAN DX60R E60 EXCAVATOR TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

DOOSAN DX60R E60 EXCAVATOR TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
K9005744
DX60R E60 ROTARY GROUP K9005749
Pos. Part No Qty Parts name Comments
-. K9005744 [1]   HYD MOTOR
12 1.409-00197 [1]   PISTON;PARKING
13 1.131-00148 [8]   SPRING
13 1.131-00148 [6]   SPRING
15 1.412-00064 [2]   PLATE;FRICTION
16 1.412-00073 [2]   PLATE;MATING
2 K9005745 [1]   REAR FLANGE ASS'Y
2 430215-00262 [1]
2-18. 1.427-00032 [1]   . SEAT;VALVE
2-19. 1.424-00011 [1]   . PLUNGER,VALVE
2-20. 1.131-00177 [1]   . SPRING
2-21. 2181-1950D2 [1]   PLUG
2-22. 1.115-00139 [1]   . RING;T-TYPE
2-24. 1.181-00088 [2]   . PLUG;VP
2-25. K9005747 [2]   . RETAINER;SPRING
2-26. 1.181-00097 [2]   . PLUG
2-27. 1.420-00021 [2]   . VALVE
2-28. 1.131-00141 [2]   . SPRING;MAIN
2-30. 1.131-00107 [2]   . SPRING;CHECK
2-33. S8000091 [1]   O-RING
2-37. S8000161 [2]   O-RING
2-44. 2181-1116D1 [6]   PLUG
2-52. 2181-1890D2 [2]   PLUG
2-52. 2181-1890D2 [4]   PLUG
2-54. 181-00318 [4]   BOLT;SOCKER
2-63. 422-00031A [1]   . VALVE(TWO SPEED)
2-64. 116-00016 [1]   . STOPPER;T/SPEED
2-65. 411-00005 [1]   . RING;TWO SPEED
2-66. 1.131-00099 [1]   . SPRING;TWO SPEED
2-68. S6250161 [2]   . BALL;STEEL
2-A. K9005746 [1]   .. REAR FLANGE KIT
2-A. 430215-00263 [1]
2-A1. *NA00460 [1]   . FLANGE;REAR
2-A23. *NA01176 [1]   . SPOOL;MAIN
20 K9005752A [1]   SHAFT   K9005752B
20 K9005752B [1]   SHAFT
3 K9005749 [1]   CYLINDER BLOCK & PISTON KIT
3-10. 1.114-00314 [2]   WASHER
3-11. K9005957 [1]   . WASHER
3-14. *NA01182 [1]   . SPRING
3-3. K9005750 [1]   . PISTON ASS`Y
3-4. *NA00074 [1]   . BLOCK;CYLINDER
3-51. *NA00752 [3]   PIN
3-7. *NA00830 [1]   . PLATE;RETAINER
3-8. *NA00040 [1]   . BALL;THRUST
30 K9006696 [1]   PLATE;SWASH
32 1.180-00525A [1]   OIL SEAL
35 1.180-00183 [1]   O-RING
36 S8000261 [2]   O-RING
38 S8000141 [4]   O-RING
39 S8011401 [1]   O-RING
40 S8000081 [1]   O-RING
41 S5700621 [2]   PIN;PARALLEL
42 1.123-00055 [2]   PIN;PARALLEL
43 S2212271 [8]   BOLT;SOCKET M10X30
45 S6510420 [1]   RING
46 S8000181 [4]   O-RING
47 1.180-00290 [1]   RING;BACK-UP
48 1.180-00291 [1]   RING;BACK-UP
49 1.109-00121 [1]   BEARING;ROLLER
5 K9005757 [1]   RELIEF VALVE BLOCK KIT   K9005757A
5 K9005757A [1]   RELIEF VALVE BLOCK KIT
5-201. K9005758 [1]   . BLOCK;VALVE
5-202. *NA01107 [1]   . SEAT
5-203. *NA00890 [1]   . PLUNGER
5-204. *NA01182 [1]   . SPRING
5-205. *NA00079 [1]   BODY
5-206. *NA01133 [1]   . SHIM
5-207. *NA00796 [1]   PISTON
5-208. *NA00996 [1]   . ROD
5-209. *NA00843 [1]   PLUG
5-210. S8060181 [2]   . RING;BACKUP
5-210. S8060181 [1]   . RING;BACKUP
5-250. K9005759A [2]   . RELIEF VALVE ASS`Y
5-250. K9005759 [2]   RELIEF VALVE ASS'Y   K9005759A
50 1.109-00032 [1]   BEARING;BALL
60 K9005751 [1]   PISTON ASS`Y(2 SPEED)
66 K9005755 [2]   PIN;PARALLEL
67 K9005756 [2]   PIVOT
70 S2209661 [4]   BOLT
74 S8000111 [2]   O-RING
74 S8000111 [4]   O-RING
75 S8000071 [2]   O-RING
76 S6510520 [1]   RING;SNAP
9 K9005754 [1]   PLATE;TIMING
91 2181-1116D2 [2]   PLUG
