DOOSAN DX60R E60 EXCAVATOR 400914-00350 K1033766A HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

DOOSAN DX60R E60 EXCAVATOR 400914-00350 K1033766A HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
400914-00350 K1033766A
DX60R E60
Pos. Part No Qty Parts name Comments
-. K1033766A [1]   MAIN PUMP
-. 400914-00350 [1]
1 K9005713 [1]   SHAFT ASS'Y
10 K9005705 [1]   VALVE;RELIEF
11 2.421-00061 [1]   BREATHER;AIR
13 K9006691 [1]   SPRING
14 2.131-00261 [1]   SPRING
15 2.181-00324 [1]   PLUG
2 2.412-00279 [1]   HANGER ASS'Y
3 K9005710 [1]   ROTARY GROUP ASS'Y
4 K9005714 [1]   COVER ASS'Y
5 K9006690 [1]   CONTROL SPRING ASS'Y
5 K9005707 [1]   CONTROL SPRING ASS'Y
6 K9006692 [1]   CONTROL PISTON ASS'Y
6 K9005711 [1]   CONTROL PISTON ASS'Y
7 400910-00177 [1]
7 K9005709 [1]   GEAR PUMP
8 2.402-00182 [1]   HOUSING
9 K9005708 [1]   SOLENOID VALVE ASS'Y
Parts on group DX60R:
Pos. Part No Qty Parts name Comments
1 2.430-00253 [1]   COVER
10 2.109-00078 [1]   BEARING
11 2.181-00220 [2]   PLUG
12 S8000081 [3]   O-RING
13 S2215766 [1]   BOLT
14 2.471-00007 [1]   FILTER
15 S6500250 [1]   RING;RETAINING
16 2.181-00184 [3]   PLUG
2 2.412-00126 [1]   PLATE;CONTROL
3 S5700881 [2]   PIN;PARALLEL
4 S2215266 [3]   BOLT
5 2.180-00507 [1]   O-RING
6 2.180-00475 [4]   O-RING
7 2.181-00183 [3]   PLUG
9 2.415-00027 [3]   ORIFICE
Parts on group DX60R:
Pos. Part No Qty Parts name Comments
1 2.412-00280 [1]   HANGER
2 2.412-00037 [1]   PLATE
3 2.114-00762 [1]   SPACER
4 2.109-00077 [2]   BEARING
5 S2204663 [4]   BOLT M6X1.0X16
6 2180-1216D80 [1]   O-RING
Parts on group DX60R:
Pos. Part No Qty Parts name Comments
1 2.409-00108 [10]   PISTON ASS'Y
1 130602-00208 [10]
10 S6510400 [1]   RING;RETAINING
2 2.410-00054 [1]   BLOCK;CYLINDER
4 2.115-00278 [1]   RING;RETAINER
5 2.412-00038 [1]   PLATE
6 2.429-00027 [1]   PLATE;GUIDE
7 2.131-00260 [1]   SPRING
8 2.123-00079 [3]   PIN;PARALLEL
9 2.427-00070 [2]   SEAT;SPRING
Parts on group DX60R:
Pos. Part No Qty Parts name Comments
1 K9005712 [1]   SHAFT
10 S6510720 [1]   RING;RETAINING
2 2.423-00069 [1]   SEAL;CASE
3 2.109-00076 [1]   BEARING
6 S6500280 [1]   RING;SNAP
8 K9005697 [1]   SEAL;OIL
9 2180-1216D83 [1]   O-RING
Parts on group DX60R:
Pos. Part No Qty Parts name Comments
1 *NA00079 [1]   BODY
10 K9005702 [1]   SOLENOID(B)
11 K9005703 [1]   SOLENOID(A)
12 2.181-00183 [3]   PLUG
18 2.181-00225 [1]   PLUG
19 S8000081 [1]   O-RING
2 K9003838 [2]   SPOOL
20 2.131-00115 [1]   SPRING
21 S6250150 [1]   BALL;STEEL
4 S8000141 [2]   O-RING
5 2180-1216D17 [2]   O-RING
6 K9003839 [2]   SPRING
8 S2209071 [2]   BOLT;SOCKET M8X25
9 2.474-00011 [1]   FILTER
