DOOSAN DX60 E60 EXCAVATOR TRAVEL REDUCTION GEAR

DOOSAN DX60 E60 EXCAVATOR TRAVEL REDUCTION GEAR

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group DX60R:TRAVEL REDUCTION GEAR DX60R Doosan parts catalog online
Pos. Part No Qty Parts name Comments
-. 170402-00035 [1]   GEAR,REDUCTION,TRAVEL
-. K9005741 [1]   REDUCTION GEAR   K9005741A
-. K9005741A [1]   170402-00035
101 K9005742A [1]
101 K9005742 [1]   FLANGE;HOLDER
102 K1000470 [2]   FLOATING SEAL   K1000470C
102 K1000470C [2]   SEAL,FLOATING
103 1.121-00086 [1]   NUT;RING
104 2181-1116D3 [4]   PLUG;HEX. SOCKET
105 K9005743A [1]
105 K9005743 [1]   HOUSING   K9005743A
106 S6250141 [104]   BALL;STEEL
107 2181-1116D1 [3]   PLUG
108 1.403-00130A [4]
108 1.403-00130 [4]   GEAR;PLANETARY   1.403-00130A
109 1.114-00516 [4]   WASHER;THRUST
110 1.120-00065 [4]   SCREW
111 1.109-00060 [4]   BEARING;NEEDLE
112 1.114-00004 [4]   COLLAR
113 1.412-00160 [1]   PLATE;THRUST
114 1.403-00112A [1]
114 1.403-00112 [1]   GEAR;SUN   1.403-00112A
115 S6500480 [1]   RING;RETAINING
116 110928-00496 [1]   HOLDER
116 1.429-00017 [1]   HOLDER
117 1.403-00068A [3]
117 1.403-00068 [3]   GEAR;PLANETARY   1.403-00068A
118 1.109-00059 [3]   BEARING;NEEDLE
119 1.216-00021A [3]   RACE;INNER
120 S0504666 [3]   BOLT
120 S5740890 [3]   PIN;SPRING
121 1.405-00029A [1]
121 1.405-00029 [1]   GEAR;DRIVE   1.405-00029A
122 1.412-00161 [1]   PLATE;THRUST
123 1.430-00041A [1]   COVER   1.430-00041B
123 1.430-00041B [1]   COVER
124 S2208871 [12]   BOLT;SOCKET
125 1.109-00006 [1]   BEARING;ANGULAR
126 2180-1217D147 [1]   O-RING
127 S8002000 [1]   O-RING
128 2181-1890D3 [3]   PLUG
