DOOSAN DX480LC DX520LC DX520LCA EXCAVATOR SWING REDUCTION GEARBOX PARTS

DOOSAN DX480LC DX520LC DX520LCA EXCAVATOR SWING REDUCTION GEARBOX PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
SWING REDUCTION GEAR DX480LC Doosan parts catalog online
Pos. Part No Qty Parts name Comments
-. K1000350 [2]   REDUCTION GEAR;SWING   K1033589
-. K1033589 [2]   REDUCTION GEAR;SWING   130426-00005A
-. 130426-00005A [2]
1 2402-6003C [1]   CASING
10 230-00061 [1]   CARRIER NO.2
11 2114-1901A [4]   WASHER;THRUST NO.2
12 104-00050 [4]   GEAR;PLANET NO.2
13 110-00219 [4]   BUSH NO.2
14 123-00437A [4]   PIN NO.2
15 S5741341 [4]   PIN;SPRING
16 S0121061 [1]   BOLT
17 114-00548 [1]   WASHER;THRUST NO.3
18 104-00048 [1]   GEAR;SUN NO.2
19 2705-1030 [4]   PIN;KNOCK
2 2405-1018C [1]   SHAFT;DRIVE   K1033590
2 K1033590 [1]   SHAFT;DRIVE
20 230-00060A [1]   CARRIER NO.1
20 100502-00001 [1]
21 114-00527 [3]   WASHER;THRUST NO.1
21 114-00527 [4]   WASHER;THRUST NO.1
22 104-00049A [3]   GEAR;PLANET NO.1
22 130424-00001 [4]
23 123-00435A [3]   PIN ASS'Y NO.1
23 120501-00009 [4]
24 S2217471 [16]   BOLT;SOCKET
24 120107-00002 [16]
25 104-00047A [1]   GEAR;SUN NO.1   130425-00001
25 130425-00001 [1]
26 2114-1914A [1]   SPACER
26 K1033591 [1]   SPACER
27 2181-1116D2 [2]   PLUG
28 2181-1116D4 [1]   PLUG
29 2140-1406 [1]   PIPE;LEVEL GAUGE
3 2412-1040 [1]   PLATE
30 2119-1065 [1]   GAUGE;LEVEL
31 S5231090 [1]   WASHER;DOUBLE TAP
31 120811-00001 [1]
32 140-01374A [4]   PIPE
33 120-00144 [8]   BOLT
34 S6500450 [1]   RING;SNAP
35 120816-00001 [1]
4 2109-9033 [1]   BEARING;ROLLER
5 2891-1421B [1]   PLATE;COVER
51 100502-00022 [1]
51 K9006810 [1]   CARRIER NO1 ASS'Y
52 K9006811 [1]   CARRIER NO2 ASS'Y
6 S6500380 [3]   RING;SNAP
6 S6500380 [4]   RING;SNAP
7 2180-1254 [1]   SEAL;OIL
8 2109-1050 [1]   BEARING;ROLLER   109-00174
8 109-00174 [1]   BEARING;ROLLER
9 104-00051A [1]   GEAR;RING
9 130422-00001A [1]
