DOOSAN DX480LC DX520LC DX520LCA EXCAVATOR K1000777 K1000777A 170303-00050 170303-00050A 170303-00050B SWING MOTOR PARTS

DOOSAN DX480LC DX520LC DX520LCA EXCAVATOR K1000777 K1000777A 170303-00050 170303-00050A 170303-00050B SWING MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
DX480LC DX520LC DX520LCA K1000777 K1000777A 170303-00050 170303-00050A 170303-00050B
Pos. Part No Qty Parts name Comments
*. K9001903 [1]   SEAL KIT;SWING MOTOR
*. K9008336 [1]   SEAL KIT;SWING MOTOR   K9008336A
*. K9008336A [1]
-. 170303-00050 [2]   170303-00050A
-. 170303-00050A [2]   170303-00050B
-. 170303-00050B [2]
-. K1000777 [2]   MOTOR;SWING   K1000777A
-. K1000777A [2]   MOTOR;SWING   170303-00050
101 K9001944 [1]   VALVE;CASING
102 2.121-00009 [2]   PLUG
103 K9001840 [2]   SPRING
104 K9001841 [2]   PLUNGER
105 410116-00410 [1]
105 410116-00311 [1]   VALVE;SWING REACTIONLESS
105 1.420-00016 [1]   VALVE;SWING REACTIONLESS
105 K9006899 [1]   VALVE;SWING REACTIONLESS   410116-00410
106 S8000341 [2]   O-RING
107 K9008333A [2]   VALVE,RELIEF
107 1.420-00111 [2]   VALVE;RELIEF   K9002674
107 K9002674 [2]   VALVE;RELIEF   K9008333A
108 S6005050 [1]   BEARING;BALL
109 S2227561 [4]   BOLT;SOCKET
110 2181-1950D1 [2]   PLUG
111 S8000111 [2]   O-RING
112 K9001842 [1]   O-RING
113 S5741162 [2]   PIN;SPRING
201 K9001843 [1]   SHAFT;DRIVE
202 K9001844C [1]
202 K9001844 [1]   PLATE;SWASH   K9001844C
203 K9001845 [1]   PISTON & SHOE ASS'Y
205 150102-00439 [1]
205 K9001945 [1]   CYLINDER;BLOCK
205 K9001846 [1]   BLOCK;CYLINDER
206 1.148-00015 [1]   BALL;THRUST
207 110943-00057 [1]
207 1.412-00092 [1]   PLATE;RETAINER   110943-00057
208 1.114-00009 [1]   COLLAR
209 1.109-00134 [5]   ROLLER
210 1.114-00286 [2]   WASHER
211 1.131-00048 [1]   SPRING
212 S6510620 [1]   RING;SNAP
213 250201-01934 [1]
213 K9001847 [1]   PLATE;TIMING
301 K9001848B [1]
301 K9001848 [1]   CASING
301 K9001848A [1]   CASING   K9001848B
302 401106-00181 [1]
302 180-00219 [1]   SEAL;OIL
302 K9006399 [1]   SEAL;OIL   401106-00181
303 S6005090 [1]   BEARING;BALL
304 1.123-00053 [1]   PIN,PARALLEL
305 352-00014 [3]   PLATE,SEPARATION
306 K9001946 [2]   PLATE;FRICTION
306 412-00013 [2]   PLATE,FRICTION
307 180-00220 [1]   O-RING
308 180-00221 [1]   O-RING
309 452-00020 [1]   PISTON;BRAKE
310 129-00062 [18]   SPRING;BRAKE
311 2181-1116D4 [1]   PLUG
311 181-00346 [1]   PLUG
312 2181-1116D2 [1]   PLUG
313 2181-1950D1 [1]   PLUG
314 S8000111 [1]   O-RING
400 410102-00039 [1]
400 410102-00024 [1]
400 420-00110 [1]   VALVE;BRAKE
