DOOSAN DX420LC SOLAR 420LC-V EXCAVATOR 2401-6357C 401-00004 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

DOOSAN DX420LC SOLAR 420LC-V EXCAVATOR 2401-6357C 401-00004 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
2401-6357C 401-00004
DX420LC SOLAR 420LC-V
Pos. Part No Qty Parts name Comments
-. 2401-6357C [1]   MOTOR;TRAVEL
-. 401-00005A [1]   REDUCTION GEAR;TRAVEL
-. 401-00004 [1]   MOTOR;TRAVEL
1 21622213252-01 [1]   COVER
10 2101-7028A [1]   SUN GEAR 2
11 2230-7024A [1]   CARRIER 2
12 2217-7009A [4]   PIN;CARRIER 2
13 2109-7045 [4]   BEARING;NEEDLE   K9005136
13 K9005136 [4]   BEARING;NEEDLE
14 2101-7029 [4]   PLANETARY 2
15 2123-7055A [4]   PIN;SPRING
16 2114-7114 [8]   WASHER;THRUST
17 2104-7010A [1]   RING GEAR
18 21622210267-01 [1]   HOUSING
19 2109-7046 [2]   BEARING
2 21622212469-01 [1]   CARRIER 1
20 114-00002 [1]   SHIM
21 2114-7115 [2]   WASHER;LOCK
22 2411-7004 [1]   RING;SUPPORT
23 2180-7134 [1]   SEAL;FLOATING
24 S2212261 [24]   SOCKET-HEAD BOLT
25 00020118105-51 [24]   BOLT;SOCKET M10X100
26 120-00001 [2]   SCREW;CAP TAPER
27 2423-7013 [1]   CASING
28 2627-7009 [1]   COVER;REAR
29 2441-7005 [1]   BLOCK;CYLINDER
3 21624212470-01 [3]   PIN;CARRIER 1
30 2223-7003 [1]   RETAINER;SHOE
31 2412-7003 [4]   PLATE;FRICTION
32 2452-7006 [1]   PISTON;BRAKE
33 2352-7004 [5]   PLATE;SEPARATING
34 2412-7004 [1]   PLATE;VALVE
35 2405-7002 [1]   SHAFT
36 2414-7003 [1]   COUPLING
37 2412-7005 [1]   PLATE;SWASH
38 138-00001 [1]   JOINT;BALL
39 2429-7003 [1]   HOLDER;SPRING
4 2109-7044 [3]   BEARING;NEEDLE   K9005135
4 K9005135 [3]   BEARING;NEEDLE
40 2409-7006 [9]   PISTON
41 2180-7137 [1]   D-RING
42 2180-7138 [1]   D-RING
43 2420-7032 [3]   VALVE;CHECK
44 115-00001 [1]   RING;RETAINING
45 115-00002 [1]   RING;RETAINING-C TYPE
46 2128-7004 [2]   SHIM
47 2409-7007 [1]   PISTON SHIFTER
48 2148-7006 [1]   BALL
49 2171-7004 [2]   PIVOT
5 2114-7113 [6]   WASHER;THRUST
50 2180-7135 [1]   SEAL;PISTON
51 426-00010 [1]   RESTRICTOR(0.6)
52 426-00011 [1]   RESTRICTOR(0.8)
53 2180-7136 [1]   SEAL;OIL
54 2129-7028 [3]   SPRING;CHECK VALVE
55 2129-7027 [9]   SPRING;CYLINDER
56 2129-7026 [14]   SPRING;BRAKE
57 2109-7047 [1]   BEARING
58 2109-7048 [1]   BEARING;NEEDLE
59 S2224661 [10]   BOLT;SOCKET
6 2101-7026 [3]   PLANETARY 1
60 2123-7054 [1]   PIN;PARALLEL
61 S8000061 [3]   O-RING
62 S8000081 [2]   O-RING
63 S8000091 [3]   O-RING
64 2180-7139 [1]   O-RING
65 2180-7140 [1]   O-RING
66 420-00005 [2]   VALVE;OVER LOAD RELIEF
67 420-00006 [1]   VALVE;PILOT
68 2.420-00059 [1]   VALVE;BRAKE
7 02560060036-80 [3]   PIN;SPRING
71 K9001037 [1]   KIT;HOUSING (18,25)
8 2412-7006 [1]   PLATE;THRUST
9 2101-7027A [1]   SUN GEAR 1
A. K9000979 [1]   PISTON ASS'Y
B. K9000980 [1]   SWASH PLATE ASS'Y
C. K9000981 [1]   SHIFTER PISTON ASS'Y
E. K9000982 [1]   SHOE RETAINER ASS'Y
