DOOSAN DX380LC EXCAVATOR TRAVEL REDUCTION GEAR

DOOSAN DX380LC EXCAVATOR TRAVEL REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group DX380LC:TRAVEL REDUCTION GEAR DX380LC Doosan parts catalog online
Pos. Part No Qty Parts name Comments
1 104-00035 [1]   GEAR;RING
10 404-00081 [1]   GEAR;SUN NO.2
11 404-00082 [1]   GEAR;SUN NO.3
12 K9005494 [3]   GEAR;PLANETARY NO.1
13 1.403-00065 [3]   GEAR;PLANETARY NO.2
14 104-00036 [4]   GEAR;PLANETARY NO.3
16 K9002264 [3]   PIN NO.2
17 123-00285 [4]   PIN NO.3
18 1.412-00121 [3]   PLATE;SIDE E
19 1.412-00117 [6]   PLATE;SIDE A
2 K9005498 [1]   HOUSING
20 412-00038 [8]   PLATE;SIDE F
21 1.216-00017 [3]   CAGE,NEEDLE
22 1.216-00015 [3]   CAGE;NEEDLE
23 1.216-00018 [4]   CAGE;NEEDLE
24 1.115-00232 [3]   RING;INNER
25 110-00126 [4]   BUSH;FLOATING
26 114-00347 [2]   RING;THRUST 60
27 114-00348 [1]   RING;THRUST 90
29 S2222671 [28]   BOLT;SOCKET
30 S2208871 [12]   BOLT;SOCKET
32 2181-1890D4 [3]   PLUG
33 109-00145 [2]   BEARING;ANGULAR
34 180-00345 [1]   SEAL;FLOATING
35 1.114-00054 [1]   SHIM 1.0
35 1.114-00053 [1]   SHIM 0.9
35 1.114-00051 [1]   SHIM 0.8
35 1.114-00049 [1]   SHIM 0.7
35 1.114-00047 [1]   SHIM 0.6
35 1.114-00045 [1]   SHIM 0.5
36 1.123-00081 [3]   PIN;SPRING
37 S6510420 [4]   RING
4 1.430-00216 [1]   COVER;SIDE   1.430-00216B
4 1.430-00216B [1]
44 S6500450 [3]   RING;SNAP
45 124-00150 [1]   CLIP
46 124-00151 [1]   CLIP
47 1.115-00248 [1]   NUT;RING
47 401003-00095 [1]
5 K9005495 [1]   CARRIER NO.1
53 1.114-00306 [1]   WASHER 1.0t
54 K9006417 [6]   SCREW;SET
54 K9006417 [3]   SCREW;SET
55 110956-00045 [4]   110956-00045A
55 110956-00045A [4]
56 S2215266 [8]   BOLT
6 1.230-00015 [1]   CARRIER NO.2
81 1.180-00162 [1]   O-RING
82 1.180-00163 [1]   O-RING
83 S8000181 [3]   O-RING
9 K9005496 [1]   GEAR;SUN NO.1
901 K9005518 [1]   CARRIER NO.1 SUB ASS'Y
902 230-00044 [1]   CARRIER NO.2 SUB ASS'Y
