DOOSAN DX380LC EXCAVATOR SWING REDUCTION GEAR

DOOSAN DX380LC EXCAVATOR SWING REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group DX380LC:SWING REDUCTION GEAR DX380LC Doosan parts catalog online
Pos. Part No Qty Parts name Comments
-. 130426-00014 [1]   130426-00014A
-. 130426-00014A [1]
-. 404-00094B [1]   GEAR;REDUCTION   130426-00014
1 105-00011A [1]   SHAFT
10 104-00038 [1]   GEAR;SUN NO.1
11 104-00042 [3]   GEAR;PLANETARY NO.1
11 130413-00041 [3]
12 223-00044 [3]   PLATE;SIDE NO.1
12 250111-00371 [6]
13 123-00457 [3]   PIN ASS'Y   120501-00457
13 120501-00457 [3]
13 1.216-00017 [3]   CAGE,NEEDLE
14 104-00040 [1]   GEAR;RING
15 223-00045 [1]   PLATE;THRUST
16 621-02348 [1]   COVER   110508-17490
16 110508-17490 [1]
17 705-00008 [4]   PIN;LOCK
18 114-00543 [1]   SPACER
19 114-00544 [1]   COLLAR
2 423-00172 [1]   CASE;GEAR
20 159-00233 [1]   PLATE
21 278-00090 [1]   RING;LOCK
22 109-00168 [1]   BEARING;SPHERICAL ROLLER
23 109-00169 [1]   BEARING;SPHERICAL ROLLER
24 180-00472 [1]   SEAL;OIL
25 S5741361 [4]   PIN;SPRING
26 S5810030 [1]   PLUG
27 S5810010 [2]   PLUG
28 S5810050 [1]   PLUG
29 120-00294 [16]   BOLT;SOCKET M16X180
3 230-00056A [1]   CARRIER NO.2
30 140-01343A [1]   PIPE
31 119-00020 [1]   BAR;LEVEL
32 120-00293 [4]   BOLT;SOCKET M16X40
33 250122-00098 [3]
33 140201-00074 [3]
33 223-00046 [3]   PLATE;SIDE NO.3   250122-00098
34 S6500400 [3]   RING,RETAINING
35 230-00064A [1]   100502-00254
35 100502-00254 [1]
35 230-00064 [1]   CARRIER NO.1 ASS'Y   230-00064A
36 230-00065 [1]   CARRIER NO.2 ASS'Y
38 250201-02834 [1]
39 120-00144 [3]   BOLT
4 104-00039 [1]   GEAR;SUN NO.2
5 104-00037 [4]   GEAR;PLANETARY NO.2
6 223-00043 [4]   PLATE;SIDE NO.2
7 123-00459 [4]   SHAFT FOR PIN NO.2
8 110-00228 [4]   BUSH NO.2
9 230-00057 [1]   CARRIER NO.1   100502-00073
9 100502-00073 [1]
9 100502-00252 [1]
