DOOSAN DX340LC DX350LC EXCAVATOR K1003132 170403-00104 FINAL DRIVE TRAVEL MOTOR ROTARY GROUP

DOOSAN DX340LC DX350LC EXCAVATOR K1003132 170403-00104 FINAL DRIVE TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
K1003132 170403-00104 DX340LC DX350LC
Pos. Part No Qty Parts name Comments
*. 2401-9264KT [1]   SEAL KIT;MOTOR
-. K1003132 [2]   TRAVEL MOTOR
-. 170403-00104 [2]
101 K9002261 [1]   SHAFT;DRIVE   K9002261A
101 K9002261A [1]   SHAFT;DRIVE
102 109-00143 [1]   BEARING;ROLLER   K9009896
102 K9009896 [1]   BEARING;ROLLER
103 109-00144 [1]   BEARING;NEEDLE
107 S6500500 [1]   RING;STOP
11 410-00011 [1]   CYLINDER ASS'Y
113 408-00021 [1]   BUSH
114 129-00096 [9]   SPRING;CYLINDER
12 409-00033 [1]   PISTON ASS'Y
123 412-00034 [1]   PLATE;SET
13 423-00081 [1]   VALVE CASING ASS'Y
14 409-00034 [1]   TILTING PISTON ASS'Y
201 K9002262 [1]   PLATE;SWASH
22 424-00085 [1]   SPOOL;COUNTER BALANCE
22 424-00147 [1]   SPOOL;COUNTER BALANCE   424-00147A
22 424-00147A [1]
272 K9002263 [1]   CASING;SHAFT
272 110913-00097 [1]
350 420-00195 [2]   VALVE;RELIEF   420-00195A
350 420-00195A [2]
351 420-00196 [1]   VALVE;REDUCING
352 430-00025 [1]   COVER
361 114-00345 [2]   WASHER
362 129-00097 [2]   SPRING;COUNTER BALANCE
364 403-00005 [2]   COVER;COUNTER BALANCE
365 S8010451 [2]   O-RING
366 S2215561 [8]   BOLT;SOCKET
401 S2228671 [2]   BOULON A 6 PANS CREUX
402 S2227661 [4]   BOLT;SOCKET
435 S6510900 [1]   RING;SNAP
461 181-00519 [14]   PLUG
461 181-00318 [14]   BOLT;SOCKER
464 2181-1950D3 [2]   PLUG
472 1.180-00159 [1]   O-RING
485 S8000181 [2]   O-RING
491 2180-8002A [1]   JOINT TORIQUE
504 148-00019 [2]   BALL;PIVOT
509 S8000181 [1]   O-RING
509 S8000161 [1]   O-RING
531 424-00086 [1]   SPOOL;TILTING
533 129-00098 [1]   SPRING;TILTING
541 429-00021 [1]   SEAT
542 416-00012 [1]   STOPPER
543 S6250132 [1]   BALL;STEEL
545 415-00032 [1]   ORIFICE   430219-00013
545 430219-00013 [1]
546 415-00033 [1]   ORIFICE   430219-00012
546 430219-00012 [1]
547 S8000111 [2]   O-RING
564 2181-1116D2 [2]   PLUG
567 2181-1950D1 [4]   PLUG
569 2181-1890D2 [2]   PLUG
570 S8000111 [6]   O-RING
571 2181-1890D3 [1]   PLUG
572 S8000141 [1]   O-RING
702 452-00023 [1]   PISTON;BRAKE   452-00023A
702 452-00023A [1]
703 415-00034 [1]   ORIFICE
704 415-00035 [1]   ORIFICE
705 129-00062 [14]   SPRING;BRAKE
705 129-00062 [18]   SPRING;BRAKE
707 2180-1217D156 [1]   O-RING
708 1.180-00161 [1]   O-RING
741 412-00036 [3]   PLATE;SEPARATOR
742 412-00037 [2]   PLATE;FRICTION
