DOOSAN DX340LC DX340LCA DX350LC DX360LCA DX420LC EXCAVATOR K1007543A SWING MOTOR ROTARY GROUP

DOOSAN DX340LC DX340LCA DX350LC DX360LCA DX420LC EXCAVATOR K1007543A SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
K1007543A
DX340LC DX340LCA DX350LC DX360LCA DX420LC ROTARY KIT K9002107 CYLINDER BLOCK KIT K9002108 RETAINER KIT K9002109
Pos. Part No Qty Parts name Comments
*. K9002069 [1]   SEAL KIT;SWING MOTOR
-. K1007543A [1]   MOTOR;SWING
1 1.451-00145 [1]   BODY
10 1.131-00070 [9]   SPRING
11 1.427-00007 [1]   SEAT;BALL GUIDE
12 1.429-00008 [1]   GUIDE;BALL
13 *NA00834 [1]
14 1.409-00175 [1]   PISTON ASS'Y
15 1.412-00063 [4]   PLATE;FRICTION
16 1.412-00025 [4]   PLATE
17 1.409-00187 [1]   PISTON;BRAKE
18 2180-1217D160 [2]   O-RING
19 1.131-00071 [19]   SPRING
2 1.180-00523 [1]   SEAL;OIL
20 *NA00839 [1]   . HEAD
21 1.123-00042 [2]   PIN
22 1.109-00058 [1]   BEARING;NEEDLE
23 K9002105 [1]   COVER;REAR
24 S2218661 [7]   BOLT;SOCKET
25 S2219571 [1]   BOLT;SOCKET
26 1.426-00010 [2]   POPPET
27 1.131-00072 [2]   SPRING
28 1.181-00103 [2]   PLUG;DRAIN
29 S8000291 [2]   O-RING
3 1.109-00066 [1]   BEARING;ROLLER
30 1.420-00122 [2]   RELIEF VALVE ASS'Y
31 K9002106 [1]   VALVE;TIME DELAY
32 S2206161 [3]   BOLT;SOCKET
33 2181-1116D2 [3]   PLUG
34 K9000942 [2]   VALVE;SWING REACTIONLESS
35 K9000943 [2]   PLUG
36 S8000181 [2]   O-RING
37 K9000944 [2]   RING;BACK UP
38 S8000121 [2]   O-RING
39 2180-1217D159 [1]   O-RING
4 1.115-00100 [1]   RING;SNAP
40 1.110-00172 [1]   BUSHING
41 K9002107 [1]   ROTARY KIT
42 K9002108 [1]   CYLINDER BLOCK KIT
43 K9002109 [1]   RETAINER KIT
5 1.405-00025 [1]   SHAFT
6 1.123-00041 [1]   PIN
7 1.115-00371 [1]   RING;STOP
8 1.412-00113 [1]   PLATE;SHOE
9 *NA00427 [1]
