DOOSAN DX300LC-5 EXCAVATOR 401107-02157 400914-00395A HYDRAULIC PUMP PARTS

DOOSAN DX300LC-5 EXCAVATOR 401107-02157 400914-00395A HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
401107-02157 400914-00395A DX300LC-5
Pos. Part No Qty Parts name Comments
*. 401107-02157 [1]
-. 400914-00395A [1]
11 K9006418 [2]   PISTON
111 1.405-00055 [1]   SHAFT;DRIVE(F)
113 1.405-00057 [1]   SHAFT;DRIVE(R)
116 1.403-00004 [1]   GEAR;1st
123 1.109-00111 [2]   PALIER
124 1.109-00055 [2]   BEARING;NEEDLE
127 2.109-00228 [3]   BAGUE D'ECARTEMENT
13 K9006419 [1]   CYLINDER ASS'Y(R)
14 K9006420 [1]   CYLINDER ASS'Y(L)
153 1.412-00098 [2]   PLAQUE
156 1.110-00101 [2]   BAGUE
157 1.131-00131 [18]   RESSORT
211 1.412-00110 [2]   PLAQUE
212 K9001177 [1]   PLATE;SWASH
214 2.408-00088 [1]   BUSH;TILTING
251 K9001180 [2]   SUPPORT
261 1.430-00213 [1]   COVER;SEAL(F)
271 K9005964 [2]   CASING;PUMP
30 K9001176 [2]   SWASH PLATE ASS'Y
312 K9001181 [1]   BLOCK;VALVE
325 1.402-00097 [1]   CASING;VALVE
326 K9001182 [1]   COVER;SEAL(F)
401 S2229071 [8]   BOLT;SOCKET
406 S2208871 [4]   BOLT;SOCKET
407 S2205861 [3]   SCREW
41 K9001183 [2]   CHECK VALVE ASS'Y(1)
414 S2211861 [4]   BOLT;SOCKET M10X1.5X20
42 K9001186 [2]   CHECK VALVE ASS'Y(2)
466 2181-1950D1 [3]   PLUG
467 2181-1950D2 [2]   PLUG
468 2181-1950D5 [4]   PLUG PF3/4
490 2.181-00214 [35]   PRISE
530 1.123-00089 [2]   TILTING PIN ASS'Y
531 1.123-00090 [1]   PIN;TILTING
532 1.409-00209 [2]   PISTON
534 1.416-00020 [2]   STOPPER(L)
535 1.416-00021 [2]   STOPPER(S)
541 K9001184 [4]   SEAT
543 K9001185 [2]   STOPPER;1
544 K9001187 [2]   STOPPER;1
545 S6250132 [4]   BALL;STEEL
548 2.123-00154 [1]   PIN;FEED BACK
702 S8010355 [2]   O-RING
710 S8010955 [2]   O-RING
717 S8011455 [4]   O-RING
724 401003-00823 [16]
725 S8000115 [8]   .. O-RING
726 S8000145 [2]   O-RING 1BP14
728 S8000245 [4]   O-RING
732 S8000185 [3]   . O-RING
774 401106-00108 [1]
789 S8060181 [2]   . RING;BACKUP
79 K9001179 [1]   E.P.P.R VALVE
79-1. 2180-1217D13 [1]   . O-RING
79-2. 2180-1217D14 [1]   O-RING
79-3. 2180-1217D15 [1]   . O-RING
792 S8090350 [2]   RING;BACK-UP
80 K9001178 [1]   PROPORTIONAL REDUCING VALVE
806 S4012931 [2]   NUT
808 S4015130 [2]   ECROU
824 S6500400 [2]   RING,RETAINING
885 2.123-00067 [2]   GOUJON
886 S5740870 [4]   PIN,SPRING
901 S3140025 [2]   BOLT,EYE
953 S3527906 [2]   SCREW
954 1.120-00071 [2]   SCREW
-. K9001192 [1]   GEAR PUMP
