DOOSAN DX210W WHEEL EXCAVATOR K1005191 170403-00075 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

DOOSAN DX210W WHEEL EXCAVATOR K1005191 170403-00075 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
K1005191 170403-00075 DX210W
Pos. Part No Qty Parts name Comments
-. K1005191 [1]   MOTOR;TRAVEL   170403-00075
-. 170403-00075 [1]
1 K9004020 [1]   ROTARY GROUP
10 K9004021 [1]   SEAL;OIL
11 K9004022 [1]   SHIM
12 K9004023 [1]   O-RING
13 K9004024 [1]   PLUG
17 2.123-00297 [2]   BOLT;STUD
18 2.121-00263 [2]   NUT;SEAL LOCK
2 K9004025 [1]   CONTROL GROUP
5 K9004026 [1]   HOUSING;PUMP
51 K9004027 [1]   COUNTER BALANCE VALVE
8 K9004028 [1]   PLUG
9 K9004029 [1]   RING;RETAINING
Parts on group DX210W:
Pos. Part No Qty Parts name Comments
1 K9001820 [1]   REGULLATOR;CONROL PART
15 S2221561 [8]   BOLT;SOCKET
19 K9000961 [2]   O-RING
2 K9004049 [1]   STROKE LIMITER ASS'Y
20 2.180-01187 [2]   O-RING
23 S2218063 [1]   BOLT;SOCKET
24 K9004050 [2]   RING;PISTON
26 K9004051 [2]   PIN;CYLINDER
28 K9004052 [2]   PLUG
3 K9004053 [1]   PLATE;PORT
32 2.181-00184 [1]   PLUG
34 2.120-00816 [2]   PLUG
4 K9004054 [1]   PISTON ASS'Y
5 K9004055 [1]   ROD
50 K9000957 [2]   RELIEF VALVE;PRESSURE   410127-00125
50 410127-00355 [2]
7 K9004056 [1]   PISTON   130602-00633
7 130602-00633 [1]
8 K9004057 [1]   SCREW;SOCKET
Parts on group DX210W:
Pos. Part No Qty Parts name Comments
-. K9004020 [1]   ROTARY GROUP
1 K9004030 [1]   CYLINDER BLOCK ASS'Y
1-1. *NA00074 [1]   . BLOCK;CYLINDER
1-11. K9004034 [1]   PLATE
1-12. K9004035 [14]   BOLT
1-2. K9004036 [1]   PLATE;CONTROL
1-3. K9004037 [1]   PIN;CENTER
1-4. K9004038 [7]   PISTON ASS'Y
1-6. K9004039 [1]   SHIM
1-6. K9004040 [1]   SHIM
1-6. K9004041 [1]   SHIM
1-7. K9004042 [1]   SPRING
10 K9004031 [1]   BEARING;TAPER ROLLER
11 K9004032 [1]   BEARING;TAPER ROLLER
2 K9004043 [1]   SHAFT;DRIVE
3 K9004044 [1]   PIECE;DISTANCE
6 K9004045 [1]   SHIM 3.1t
6 K9004047 [1]   SHIM 3.5t
6 K9004046 [1]   SHIM 3.45t
7 K9004048 [1]   RING;RETAINING
