DOOSAN DX210W WHEEL EXCAVATOR 400914-00104 400914-00104A K1003934B MAIN PUMP ROTARY GROUP AND SPARE PARTS

Name: DOOSAN DX210W WHEEL EXCAVATOR 400914-00104 400914-00104A K1003934B MAIN PUMP ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

DOOSAN DX210W WHEEL EXCAVATOR 400914-00104 400914-00104A K1003934B MAIN PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

400914-00104 400914-00104A K1003934B DX210W

Pos.	Part No	Qty	Parts name	Comments
-.	K1003934B	[1]	PUMP;MAIN	400914-00104
-.	400914-00104	[1]		400914-00104A
-.	400914-00104A	[1]
1	*NA00911	[1]	POMPE
2	K9004220	[1]	CONTROL
5	K9004246	[1]	FLANGE ASS'Y
5	430215-00412	[1]
6	K9004206	[1]	PORT PLATE WITH VALVES	410116-00407
6	410116-00407	[1]		410116-00986
6	410116-00986	[1]
7	K9004225	[1]	PIPE ASS'Y
Parts on group DX210W:

Pos.	Part No	Qty	Parts name	Comments
10	*NA00828	[1]
11	K9004247	[1]	GASKET
12	K9004197	[2]	PISTON;POSITIONING
13	K9004198	[2]	TRUNNION;POSITIONING
14	K9004224	[2]	COLLAR;SPRING
15	K9004201	[2]	SPRING
16	K9004199	[2]	PISTON
17	2.123-00296	[2]	PIN;THREADED
18	K9004200	[2]	PLUG
2	K9004221	[1]	CONTROL MODULE
26	K9004231	[2]	SCREW;HEX
2A.	K9004203	[1]	CONTROL MODULE
2Aa.	*NA00534	[1]
2Ab.	2.409-00179	[2]	PISTON;CONTROL
2Ac.	2.408-00065	[2]	BUSH;CONTROL
2Ad.	2.409-00202	[2]	PISTON;POSITIONING
2Ae.	2.123-00066	[2]	PIN
2Af.	2.114-00039	[4]	COLLAR;SPRING
2Ag.	2.131-00415	[2]	SPRING;PRESSURE
2Ah.	2.120-00613	[2]	SCREW;LOCKING
2Ai.	2.123-00235	[2]	PIN;THREADED
2Aj.	2.121-00202	[2]	NUT;SEAL LOCK
2Ak.	2.180-01191	[2]	O-RING
2Al.	2.180-00471	[2]	O-RING
2Am.	2.180-01181	[2]	O-RING
2An.	2.120-00826	[6]	SCREW;SOCKET-HEAD
2Ao.	2.181-00183	[5]	PLUG
2Ap.	2.123-00131	[2]	PIN;CYLINDER
2Aq.	2.181-00184	[1]	PLUG
2Ar.	2.181-00262	[1]	PLUG
2As.	2.120-00612	[1]	PLUG
2B.	*NA00534	[1]
2C.	K9004226	[2]	PISTON;CONTROL
2D.	2.408-00083	[2]	BUSH;SPRING
2E.	2.131-00418	[2]	SPRING;PRESSURE
2F.	2.123-00238	[2]	PIN;THREADED
2G.	K9004244	[2]	COLLAR;SPRING
2H.	K9004245	[2]	COLLAR;SPRING
2I.	K9004222	[2]	SPRING
2J.	K9004223	[2]	SPRING
2K.	2.180-00471	[4]	O-RING
2L.	2180-1217D70	[2]	O-RING
2M.	2.120-00611	[2]	SCREW;LOCKING
2N.	2.121-00202	[2]	NUT;SEAL LOCK
2O.	S2210466	[6]	BOLT
37	K9004229	[2]	RING;STEEL SEALING
42	S2215666	[8]	BOLT;SOCKET
43	S2216266	[4]	BOLT;SOCKET
44	2.123-00134	[2]	PIN;CYLINDER
46	2.181-00183	[1]	PLUG
47	2.121-00203	[2]	NUT;SEAL LOCK
48	2.123-00240	[2]	PIN;THREADED
49	2180-1217D59	[2]	O-RING	S8040161
49	S8040161	[2]	O-RING
50	2.120-00616	[2]	SCREW;LOCKING
Parts on group DX210W:

Pos.	Part No	Qty	Parts name	Comments
1	K9004246	[1]	FLANGE ASS'Y
1	430215-00412	[1]
1A.	K9004195	[1]	GEAR
1A.	130418-00310	[1]
1B.	K9004205	[1]	COVER
1C.	2.180-01199	[4]	O-RING
1D.	K9004234	[4]	BEARING;BALL
1E.	2.109-00131	[4]	BEARING;BALL
1F.	2.120-00832	[4]	BOLT;SOCKET
1G.	2180-1217D132	[4]	O-RING
2	K9004206	[1]	PORT PLATE WITH VALVES	410116-00407
2	410116-00407	[1]
2A.	*NA00828	[1]
2B.	2.409-00216	[1]	PISTON;VALVE
2C.	2.131-00417	[1]	SPRING;PRESSURE
2D.	2.120-00617	[1]	SCREW;LOCKING
2E.	2.114-00877	[1]	WASHER
2F.	S2209361	[2]	BOLT;SOCKET M8X1.25X35
2G.	2.180-01180	[1]	O-RING
2H.	2.180-01182	[1]	O-RING
2I.	K9001933	[1]	VALVE	410116-00395
2I.	410116-00395	[1]
2J.	2.123-00138	[1]	PIN;DOUBLE BREAK-OFF
Parts on group DX210W:

Pos.	Part No	Qty	Parts name	Comments
2	210204-00003	[1]
2	K9004207	[1]	ROTARY GROUP
20	2.115-00303	[1]	RING;RETAINING
21	K9004253	[1]	RING;SHAFT SEAL
22	K9004235	[1]	SHIM
23	2.120-00611	[1]	SCREW;LOCKING
24	2.120-00612	[3]	PLUG
25	K9004233	[2]	BEARING;PLAIN ROLLER
27	2.405-00240	[1]	KEY;SHAFT
2A.	K9004208	[1]	ROTARY GROUP. HYDR. SECTION
2Aa.	K9004210	[1]	CYLINDER
2Ab.	K9004202	[1]	PIN;CENTER
2Ac.	K9004209	[9]	PISTON & PISTON RINGS
2Ac1.	*NA00796	[1]	PISTON
2Ac2.	K9004219	[1]	RING;STEEL SEALING
2Ad.	K9004239	[1]	COLLAR;SPRING
2Ad.	K9004240	[1]	COLLAR;SPRING
2Ad.	K9004241	[1]	COLLAR;SPRING
2Ad.	K9004242	[1]	COLLAR;SPRING
2Ad.	K9004243	[1]	COLLAR;SPRING
2Ae.	K9004238	[4]	CUP SPRING
2Af.	K9004211	[1]	PLATE;RETAINING
2Ag.	K9004228	[18]	SCREW;PAN HEAD
2B.	K9004212	[1]	SHAFT WITH BEARING ASS'Y
2B.	130712-00171	[1]
2Ba.	K9004213	[1]	SHAFT;DRIVE
2Ba.	130712-00172	[1]
2Bb.	K9004248	[1]	SHIM
2Bb.	K9004249	[1]	SHIM
2Bb.	K9004250	[1]	SHIM
2Bb.	K9004251	[1]	SHIM
2Bb.	K9004252	[1]	SHIM
2Bc.	K9004259	[1]	PLATE;BACK-UP
2Bc.	K9004258	[1]	PLATE;BACK-UP
2Bc.	K9004257	[1]	PLATE;BACK-UP
2Bc.	K9004256	[1]	PLATE;BACK-UP
2Bc.	K9004255	[1]	PLATE;BACK-UP
2Bc.	K9004254	[1]	PLATE;BACK-UP
2Bd.	K9004232	[1]	RING;RETAINING
2Be.	K9004237	[1]	BEARING;UNIT TAPERED-ROLLER
2Be.	K9009883	[1]	BEARING;UNIT TAPERED-ROLLER
2Bf.	K9004236	[1]	BEARING;TAPERED-ROLLER
2Bf.	K9009884	[1]	BEARING;TAPERED-ROLLER
2D.	K9004214	[1]	LENS;CONTROL RIGHT-HAND
3	K9004215	[1]	ROTARY GROUP
3	210204-00004	[1]
3A.	K9004208	[1]	ROTARY GROUP. HYDR. SECTION
3Aa.	K9004210	[1]	CYLINDER
3Ab.	K9004202	[1]	PIN;CENTER
3Ac.	K9004209	[9]	PISTON & PISTON RINGS
3Ac1.	*NA00796	[1]	PISTON
3Ac2.	K9004219	[1]	RING;STEEL SEALING
3Ad.	K9004239	[1]	COLLAR;SPRING
3Ad.	K9004240	[1]	COLLAR;SPRING
3Ad.	K9004241	[1]	COLLAR;SPRING
3Ad.	K9004242	[1]	COLLAR;SPRING
3Ad.	K9004243	[1]	COLLAR;SPRING
3Ae.	K9004238	[4]	CUP SPRING
3Af.	K9004211	[1]	PLATE;RETAINING
3Ag.	K9004228	[18]	SCREW;PAN HEAD
3B.	130712-00173	[1]
3B.	K9004216	[1]	SHAFT WITH BEARING ASS'Y
3Ba.	130712-00174	[1]
3Ba.	K9004217	[1]	SHAFT;DRIVE
3Bb.	K9004248	[1]	SHIM
3Bb.	K9004249	[1]	SHIM
3Bb.	K9004250	[1]	SHIM
3Bb.	K9004251	[1]	SHIM
3Bb.	K9004252	[1]	SHIM
3Bc.	K9004259	[1]	PLATE;BACK-UP
3Bc.	K9004258	[1]	PLATE;BACK-UP
3Bc.	K9004257	[1]	PLATE;BACK-UP
3Bc.	K9004256	[1]	PLATE;BACK-UP
3Bc.	K9004255	[1]	PLATE;BACK-UP
3Bc.	K9004254	[1]	PLATE;BACK-UP
3Bd.	K9004232	[1]	RING;RETAINING
3Be.	K9009883	[1]	BEARING;UNIT TAPERED-ROLLER
3Be.	K9004237	[1]	BEARING;UNIT TAPERED-ROLLER
3Bf.	K9009884	[1]	BEARING;TAPERED-ROLLER
3Bf.	K9004236	[1]	BEARING;TAPERED-ROLLER
3D.	K9009885	[1]	LENS;CONTROL LEFT-HAND
3D.	K9004218	[1]	LENS;CONTROL LEFT-HAND
4	K9004230	[1]	GEAR PUMP ASS'Y
4A.	K9004260	[1]	PUMP;GEAR
4B.	2180-1217D82	[1]	O-RING
4C.	2180-1217D16	[1]	O-RING
4D.	S2210276	[2]	BOLT;SOCKET
4E.	S2209071	[2]	BOLT;SOCKET M8X25
5	*NA00539	[1]
7	130418-00079	[1]
7	K9004196	[1]	GEAR
8	K9004204	[1]	SHAFT;STUB
