DOOSAN DX180LC DX190W DX210W DX225LC DX225LL DX225NLC DX235NLC TXC225LC-2 WHEEL EXCAVATOR K1000697A 170303-00048 170303-00048A SWING MOTOR ROTARY GROUP

Name: DOOSAN DX180LC DX190W DX210W DX225LC DX225LL DX225NLC DX235NLC TXC225LC-2 WHEEL EXCAVATOR K1000697A 170303-00048 170303-00048A SWING MOTOR ROTARY GROUP
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

DOOSAN DX180LC DX190W DX210W DX225LC DX225LL DX225NLC DX235NLC TXC225LC-2 WHEEL EXCAVATOR K1000697A 170303-00048 170303-00048A SWING MOTOR ROTARY GROUP

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

K1000697A 170303-00048 170303-00048A DX180LC DX190W DX210W DX225LC DX225LL DX225NLC DX235NLC TXC225LC-2

Pos.	Part No	Qty	Parts name	Comments
*.	K9001903	[1]	SEAL KIT;SWING MOTOR
*.	K9008336	[1]	SEAL KIT;SWING MOTOR
-.	K1000697A	[1]	SWING MOTOR	170303-00048
-.	170303-00048	[1]		170303-00048A
-.	170303-00048A	[1]
101	*NA00351	[1]	CASING;VALVE
102	2.121-00009	[2]	PLUG
103	K9001840	[2]	SPRING
104	K9001841	[2]	PLUNGER
105	1.420-00016	[1]	VALVE;SWING REACTIONLESS	K9006899
105	K9006899	[1]	VALVE;SWING REACTIONLESS
105	410116-00311	[1]	VALVE;SWING REACTIONLESS
106	S8000341	[2]	O-RING
107	1.420-00111	[2]	VALVE;RELIEF	K9008333A
107	K9008333A	[2]	VALVE,RELIEF
108	S6005050	[1]	BEARING;BALL
109	S2227561	[4]	BOLT;SOCKET
110	2181-1950D1	[2]	PLUG
111	S8000111	[2]	O-RING
112	K9001842	[1]	O-RING
113	S5741162	[2]	PIN;SPRING
201	K9001843	[1]	SHAFT;DRIVE
202	K9001844	[1]	PLATE;SWASH	K9001844C
202	K9001844C	[1]
203	K9001845	[1]	PISTON & SHOE ASS'Y
205	K9001846	[1]	BLOCK;CYLINDER
205	150102-00439	[1]
206	1.148-00015	[1]	BALL;THRUST
207	1.412-00092	[1]	PLATE;RETAINER	110943-00057
207	110943-00057	[1]
208	1.114-00009	[1]	COLLAR
209	1.109-00134	[5]	ROLLER
210	1.114-00286	[2]	WASHER
211	1.131-00048	[1]	SPRING
212	S6510620	[1]	RING;SNAP
213	K9001847	[1]	PLATE;TIMING
213	250201-01934	[1]
301	K9001848	[1]	CASING
301	K9001848A	[1]	CASING	K9001848B
301	K9001848B	[1]
302	180-00219	[1]	SEAL;OIL
302	K9006399	[1]	SEAL;OIL
303	S6005090	[1]	BEARING;BALL
304	1.123-00053	[1]	PIN,PARALLEL
305	352-00014	[3]	PLATE,SEPARATION
306	412-00013	[2]	PLATE,FRICTION
307	180-00220	[1]	O-RING
308	180-00221	[1]	O-RING
309	452-00020	[1]	PISTON;BRAKE
310	129-00062	[18]	SPRING;BRAKE
311	181-00346	[1]	PLUG
311	2181-1116D4	[1]	PLUG
312	2181-1116D2	[1]	PLUG
313	2181-1950D1	[1]	PLUG
314	S8000111	[1]	O-RING
400	420-00110	[1]	VALVE;BRAKE	410102-00024
400	410102-00024	[1]
Parts on group DX210W:

Pos.	Part No	Qty	Parts name	Comments
-.	K1009866C	[-]	SWING DEVICE ASS'Y
1	K1009865A	[1]	SWING DEVICE SUB ASS'Y	K1009865B
1	K1009865B	[1]	SWING DEVICE SUB ASS'Y	K1009865C
1	K1009865C	[1]	SWING DEVICE SUB ASS'Y	170301-00110
1	170301-00110	[1]		170301-00110A
1	170301-00110A	[1]		170301-00110B
1	170301-00110B	[1]		170301-00110C
1	170301-00110C	[1]		170301-00110E
1	170301-00110E	[1]		170301-00110G
1	170301-00110G	[1]
1A.	K1000697A	[1]	SWING MOTOR	170303-00048
1A.	170303-00048	[1]		170303-00048A
1A.	170303-00048A	[1]
1B.	404-00097C	[1]	REDUCTION GEAR ASS'Y	130426-00011
1B.	130426-00011	[1]		130426-00011A
1B.	130426-00011A	[1]
1C.	2181-1110D3	[1]	. ADAPTER
1D.	181-00717	[1]	. ELBOW
1E.	121-00010D3	[1]	. NUT
1F.	S8000181	[1]	O-RING
1G.	2181-1950D7	[1]	. PLUG	DS2901008
1G.	426-00278	[1]	. VALVE;DRAIN
1G.	DS2901008	[1]	. PLUG
1H.	2181-1913D24	[1]	REDUCER
1I.	K1000266	[1]	PIPE
1J.	2119-1063B	[1]	. CAP
1K.	2184-1036D303	[1]	HOSE
1K.	DS2055980	[1]	HOSE
1L.	S5011113	[1]	. WASHER
2	DS2214050	[1]	ADAPTER
2	DS2214051	[1]	ADAPTER
3	2114-9012A	[11]	WASHER
4	S0570166	[11]	BOLT M20X2.5X65
5	160-00027	[2]	CAP
6	2123-4030	[1]	PIN;LOCK
7	S0511666	[2]	BOLT
