DOOSAN 170401-00009H 170401-00009L 200108-00001A TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

DOOSAN 170401-00009H 170401-00009L 200108-00001A TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
170401-00009H 170401-00009L 200108-00001A DX530LC-5B
Pos. Part No Qty Parts name Comments
-. 650105-00014 [-]
14 S0570166 [72]   BOLT M20X2.5X65
15 2114-9012A [72]   WASHER
16 S0575166 [52]   BOLT
22 2114-1831A [52]   . WASHER
3 170401-00009H [2]   170401-00009L
3 170401-00009L [2]
5 200108-00001A [2]
Parts on group DX530LC-5B:
Pos. Part No Qty Parts name Comments
100 250201-01442 [3]
101 130602-00680 [1]
102 415-00034 [1]   ORIFICE
103 410127-00153A [2]
46 2180-1217D160 [1]   O-RING
47 2180-1217D164 [1]
48 S8000081 [2]   O-RING
49 *NA00915 [1]   REAR FLANGE
50 410207-00250 [1]
57 120808-00420 [2]
58 111601-00353 [2]
60 S8010451 [2]   O-RING
61 110910-00379 [2]
62 S2215561 [8]   BOLT;SOCKET
63 111601-00354 [1]   SPRING
64 410207-00243 [1]
65 2181-1890D4 [3]   PLUG
66 S8000181 [1]   O-RING
67 2181-1890D2 [4]   PLUG
68 S8000111 [6]   O-RING
69 2181-1116D2 [2]   PLUG
70 415-00035 [1]   ORIFICE
71 181-00318 [6]   BOLT;SOCKER
72 S6250182 [2]   BALL
73 109-00144 [1]   BEARING;NEEDLE
74 123-00153 [1]
75 250201-01443 [1]
76 1.131-00049 [14]   SPRING
77 430219-00012 [1]
78 430219-00013 [1]
79 2180-1217D163 [1]
80 S2227561 [8]   BOLT;SOCKET
81 420-00196 [1]   VALVE;REDUCING
82 430-00025 [1]   COVER
83 2180-8002A [1]   JOINT TORIQUE
84 101560-00006 [2]
85 S6500550 [1]   RING;RETAINER
86 1.109-00066 [1]   BEARING;ROLLER
87 130712-00860 [1]
88 S6511000 [1]   RING;LOCK
89 130602-01581 [1]
89 130602-00681A [1]   130602-01581
90 150102-00417A [1]
91 1.131-00042 [1]   SPRING
92 400901-00052 [1]
93 *NA00423 [1]
94 111601-00355 [9]
95 110202-00040 [1]
96 110943-00045 [1]
97 130602-00679 [1]
99 130113-00019 [4]
C. 430215-00562A [1]
