Caterpillar MCB195 travel motor parts

Caterpillar MCB195 travel motor parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
MCB195 CAT330C CAT330D
TRAVEL MOTOR
191-5606 271-6376 296-6217  353-0601 CAT325C CAT328D LCR CAT330C CAT330CFM CAT330CL CAT330CMH CAT330D CAT330DL CAT330DLN CAT330DMH CAT336D CAT336DL CAT330DLN CAT340DL
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 1T-0936 [1] PLUG-ORIFICE
2 4B-4158 [4] SCREW-DRIVE (NO 4X0.25-IN)
3 6V-3382 J [1] SEAL-LIP TYPE
4 8J-2559 [1] PLATE-WARNING (OIL FILL)
5 087-4786 [1] ADAPTER
6 108-6503 [9] PISTON AS
7 118-4057 [9] SPRING
8 124-1541 [2] PIN
9 124-1561 [20] SPRING-BRAKE
10 137-3708 [1] RETAINER
11 167-3855 [1] SHAFT
12 167-3857 [1] KEY
13 167-3858 [1] KEY
14 167-3859 [1] PLATE-CAM
15 167-3862 [1] PLATE-RETAINER
16 167-3863 [1] BALL
17 167-3865 [5] PLATE-SEPARATOR
18 167-3866 [4] PLATE-FRICTION
19 167-3867 [1] PLATE-PORT
20 167-3868 [1] PISTON-BRAKE
21 167-3872 [1] SPOOL
22 170-1612 J [2] SEAL
23 170-1626 J [1] RING-BACKUP
24 170-1627 J [1] RING-BACKUP
25 173-4063 [1] BARREL AS-MOTOR
26 173-4066 [1] SPACER (63.05X79.8X7-MM THK)
27 175-7436 [1] VALVE
28 175-7887 [2] DOWEL
29 180-6769 [1] BEARING AS
30 180-6770 [1] BEARING AS
31 186-5175 [1] PLUG
32 189-3189 [1] RING-SEAL
33 193-7901 [1] BODY AS
34 196-4987 [1] PISTON-ACTUATOR
35 271-6377 [1] HEAD AS
36 274-4512 [1] SEAT
37 274-4513 [2] RETAINER
38 095-1572 J [2] SEAL-O-RING
39 095-1585 J [1] SEAL-O-RING
40 095-1596 J [1] SEAL-O-RING
41 095-1700 J [2] SEAL-O-RING
42 095-7380 [1] SPRING
44 096-3978 [1] SPRING
45 096-5919 J [2] RING-BACKUP
46 099-7030 J [1] RING-BACKUP
47 170-1616 J [1] SEAL
48 2D-6642 [2] BALL
49 2M-9780 J [1] SEAL-O-RING
50 2R-1236 [1] RING-RETAINING (LOCK, INTERNAL)
51 3D-2824 J [2] SEAL-O-RING
53 3K-0360 J [2] SEAL-O-RING
54 4K-4284 [1] RING-RETAINING
55 6V-5192 M [4] BOLT-SOCKET HEAD (M8X1.25X30-MM)
56 7Y-5219 J [2] SEAL-O-RING
57 8T-2393 M [8] BOLT-SOCKET HEAD (M16X2X60-MM)
58 9S-8005 [2] PLUG (3/4-16-THD)
59 9S-8008 [2] PLUG (1-1/16-12-THD)
  AVAILABLE REPAIR KIT(S):
272-0290 J [1] KIT-SEAL (TRAVEL MOTOR)
  (ALSO INCLUDES O-RING SEALS)
J   KIT MARKED J SERVICES PART(S) MARKED J
M   METRIC PART
