MOTOR & MTG GP-TRAVEL
519-2480 MOTOR & MTG GP-TRAVEL
S/N LKG1-UP
PART OF 511-6019, 527-7097 DRIVE GP-FINAL |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
451-2176 |
[4] |
WASHER-HARD (22X35X3.5-MM THK) |
|
| 2 |
504-9481 |
[4] |
BOLT-SOCKET HEAD |
|
| 3 |
511-0317 |
[1] |
MOTOR GP-TRAVEL |
|
| 4 |
1T-0132 |
[1] |
SEAL-O-RING |
|
|
R |
|
REMANUFACTURED PART MAY BE AVAILABLE |
|
Y |
|
SEPARATE ILLUSTRATION |
DRIVE GP-FINAL
518-1211 DRIVE GP-FINAL -WITH MOTOR, RH
S/N GAX1-UP
PART OF 518-1210 DRIVE GP-FINAL
FIELD REPLACEMENT ORDER 527-7097 |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
417-7195 Y |
[1] |
MOTOR & MTG GP-TRAVEL |
|
| 2 |
518-1212 Y |
[1] |
DRIVE GP-FINAL (WITHOUT MOTOR, RH) |
|
| 3 |
095-1269 M |
[1] |
SETSCREW-SOCKET (M10X1.5-THD) |
|
|
M |
|
METRIC PART |
|
Y |
|
SEPARATE ILLUSTRATION |
MOTOR GP-TRAVEL
511-0317 MOTOR GP-TRAVEL CAT349D2L CAT352 CAT350 CAT352F-VG CAT349EL CAT349FL CAT349E
S/N RBY1-UP
PART OF 519-2480 MOTOR & MTG GP-TRAVEL |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
542-1323 |
[1] |
BODY AS |
|
| 2 |
542-1311 |
[1] |
PISTON |
|
| 3 |
542-1304 |
[1] |
PLATE-RETAINING |
|
| 4 |
542-1325 |
[1] |
PISTON AS |
|
| 5 |
200-3279 |
[1] |
GUIDE |
|
| 6 |
542-1320 |
[6] |
PLATE-SEPARATOR |
|
| 7 |
542-1321 |
[5] |
PLATE-FRICTION |
|
| 8 |
542-1318 |
[1] |
PISTON-BRAKE |
|
| 9 |
542-1327 |
[1] |
HEAD AS |
|
| 10 |
542-1307 |
[1] |
RING-RETAINING |
|
| 11 |
542-1302 |
[1] |
BEARING-NEEDLE |
|
| 12 |
542-1319 |
[20] |
SPRING-BRAKE |
|
| 13 |
5S-3676 |
[1] |
SEAL-O-RING |
|
| 14 |
095-1579 |
[4] |
SEAL-O-RING |
|
| 15 |
7I-8164 |
[2] |
ORIFICE (1/16-NPTF) |
|
| 16 |
243-4572 |
[1] |
SEAL-O-RING |
|
| 17 |
170-9997 |
[2] |
PLUG |
|
| 18 |
6V-3684 |
[1] |
SEAL-O-RING |
|
| 19 |
542-1326 |
[1] |
BARREL AS |
|
| 20 |
542-1303 |
[9] |
SPRING |
|
| 21 |
542-1328 |
[1] |
SWASHPLATE AS |
|
| 22 |
542-1312 |
[2] |
KEY |
|
| 23 |
6V-5203 |
[1] |
RING-RETAINING |
|
| 24 |
542-1301 |
[1] |
BEARING-ROLLER |
|
| 25 |
542-1310 |
[1] |
SEAL-LIP TYPE |
|
| 26 |
542-1300 |
[1] |
SHAFT-DRIVE |
|
| 27 |
096-5516 |
[1] |
RING-RETAINING (EXTERNAL) |
|
| 28 |
542-1306 M |
[1] |
BOLT-SOCKET HEAD (M20X2.5X105-MM) |
|
| 29 |
542-1313 |
[1] |
SPOOL |
|
| 30 |
111-9998 |
[1] |
PLUG |
|
| 31 |
095-1582 |
[1] |
SEAL-O-RING |
|
| 32 |
7Y-5216 M |
[3] |
BOLT-SOCKET HEAD (M20X2.5X80-MM) |
|
| 33 |
542-1314 |
[1] |
SPRING |
|
| 34 |
191-5663 |
[1] |
COVER |
|
| 35 |
542-1305 |
[1] |
VALVE GP-PRESSURE REDUCING |
|
| 36 |
542-1316 |
[1] |
ORIFICE |
|
| 37 |
096-2323 |
[1] |
RING-RETAINING (EXTERNAL) |
|
| 38 |
542-1309 |
[2] |
PLUG (3/4-16-NPTF) |
|
| 39 |
3K-0360 |
[2] |
SEAL-O-RING |
|
| 40 |
4I-1022 |
[1] |
ORIFICE |
|
| 41 |
542-1315 |
[1] |
STOPPER |
|
| 42 |
5H-1472 |
[1] |
BALL |
|
| 43 |
191-5669 |
[1] |
SEAT |
|
|
M |
|
METRIC PART |
MOTOR GP-PISTON
505-5180 MOTOR GP-PISTON -FAN, SUCTION
S/N RBY1-UP
PART OF 541-1391 FAN GP-SUCTION |
