CATERPILLAR CAT349 CAT352 EXCAVATOR SWING DRIVE REDUCTION GEARBOX PARTS

CATERPILLAR CAT349 CAT352 EXCAVATOR SWING DRIVE REDUCTION GEARBOX PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
DRIVE GP-SWING
544-4801 DRIVE GP-SWING -WITHOUT MOTOR, LH
S/N LKG1-UP
PART OF 521-3867 DRIVE GP-SWING
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 4H-6112 [1] BREATHER (SWING DRIVE)
2 6V-7238 [1] VALVE-SHUTOFF
3 7Y-0597 [1] SPACER-SPECIAL
4 094-0611 [14] WASHER (47.3X76X1-MM THK)
5 114-1398 [1] GAUGE-OIL LEVEL (SWING DRIVE)
6 114-1399 [1] PIPE-GAUGE
7 114-1403 [1] CAGE
8 227-6108 [1] SHAFT-PINION
9 227-6215 [1] BOSS (1/4-18-THD)
10 296-6268 [3] BEARING AS-ROLLER
11 418-7160 [1] GEAR-SUN (13-TEETH, 18-TEETH)
12 418-7161 [1] GEAR-SUN (23-TEETH)
13 418-7162 [3] GEAR-PLANETARY (25-TEETH)
14 418-7163 [4] GEAR-PLANETARY (22-TEETH)
15 418-7164 [1] GEAR-RING (69-TEETH)
16 418-7167 [4] SHAFT
17 418-7232 [1] COVER-HOUSING
18 418-7233 [8] BEARING AS-ROLLER
19 418-7234 [1] CARRIER AS
20 418-7235 [1] CARRIER-PLANETARY
21 422-1352 [2] SPACER (49.6X69.5X6-MM THK)
22 422-4054 [3] RING-RETAINING
23 451-2182 [52] WASHER-HARD (13.5X25.5X3-MM THK)
24 453-3446 M [1] BOLT (M12X1.75X35-MM)
25 453-3447 M [20] BOLT (M12X1.75X40-MM)
26 456-0784 [1] HOUSING
27 550-3121 [1] HOSE AS
28 093-1730 [2] RING-RETAINING
29 095-0670 M [30] BOLT (M12X1.75X45-MM)
30 509-6676 [4] PIN-SPRING
31 095-1806 [1] BEARING-ROLLER
32 096-2653 [1] RING-RETAINING
33 096-4339 [1] BEARING AS-ROLLER
34 135-9044 [2] SEAL-LIP TYPE
35 136-2803 [2] CLIP
36 3K-0360 [1] SEAL-O-RING
37 5P-2235 [1] SEAL-O-RING
38 7D-5363 [2] CONNECTOR (9/16-18-THD)
39 8T-4244 M [1] NUT (M12X1.75-THD)
1U-8846 BF SEALANT-GASKET
B   USE AS REQUIRED
F   NOT SHOWN
M   METRIC PART
DRIVE GP-SWING
544-4802 DRIVE GP-SWING -WITHOUT MOTOR, RH
S/N LKG1-UP
PART OF 521-3866 DRIVE GP-SWING
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 4H-6112 [1] BREATHER (SWING DRIVE)
2 6V-7238 [1] VALVE-SHUTOFF
3 7Y-0597 [1] SPACER-SPECIAL
4 094-0611 [14] WASHER (47.3X76X1-MM THK)
5 114-1398 [1] GAUGE-OIL LEVEL (SWING DRIVE)
6 114-1399 [1] PIPE-GAUGE
7 114-1403 [1] CAGE
8 227-6108 [1] SHAFT-PINION
9 227-6215 [1] BOSS (1/4-18-THD)
10 296-6268 [3] BEARING AS-ROLLER
11 418-7160 [1] GEAR-SUN (13-TEETH, 18-TEETH)
12 418-7161 [1] GEAR-SUN (23-TEETH)
13 418-7162 [3] GEAR-PLANETARY (25-TEETH)
14 418-7163 [4] GEAR-PLANETARY (22-TEETH)
15 418-7164 [1] GEAR-RING (69-TEETH)
16 418-7167 [4] SHAFT
17 418-7232 [1] COVER-HOUSING
18 418-7233 [8] BEARING AS-ROLLER
19 418-7234 [1] CARRIER AS
20 418-7235 [1] CARRIER-PLANETARY
21 422-1352 [2] SPACER (49.6X69.5X6-MM THK)
22 422-4054 [3] RING-RETAINING
23 451-2182 [52] WASHER-HARD (13.5X25.5X3-MM THK)
24 453-3446 M [1] BOLT (M12X1.75X35-MM)
25 453-3447 M [20] BOLT (M12X1.75X40-MM)
26 456-0784 [1] HOUSING
27 550-3121 [1] HOSE AS
28 093-1730 [2] RING-RETAINING
29 095-0670 M [30] BOLT (M12X1.75X45-MM)
30 509-6676 [4] PIN-SPRING
31 095-1806 [1] BEARING-ROLLER
32 096-2653 [1] RING-RETAINING
33 096-4339 [1] BEARING AS-ROLLER
34 135-9044 [2] SEAL-LIP TYPE
35 136-2803 [2] CLIP
36 3K-0360 [1] SEAL-O-RING
37 5P-2235 [1] SEAL-O-RING
38 7D-5363 [2] CONNECTOR (9/16-18-THD)
39 8T-4244 M [1] NUT (M12X1.75-THD)
1U-8846 BF SEALANT-GASKET
B   USE AS REQUIRED
F   NOT SHOWN
M   METRIC PART
