CATERPILLAR CAT349 CAT352 EXCAVATOR 566-8632 PISTON PUMP PARTS

CATERPILLAR CAT349 CAT352 EXCAVATOR 566-8632 PISTON PUMP PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
PUMP GP-HYDRAULIC
569-8251 PUMP GP-HYDRAULIC
S/N LKG1-UP
PART OF 566-8632 CAT349 CAT352 PUMP GP-PISTON
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 451-2184 M [4] NUT (M20X2.5-THD)
2 551-1107 [2] SETSCREW
3 567-1729 [2] COVER
4 567-3610 [2] RING-BACKUP
5 567-3714 [2] SEAL-O-RING
6 200-3291 [2] STOP
7 567-1717 [2] PISTON AS
8 567-1727 [2] RING-RETAINING
9 242-6919 M [2] SETSCREW (M20X2.5X56-MM)
10 567-1747 [2] BOLT-EYE
11 7I-8172 [2] RING-BACKUP
12 109-1296 [2] SEAL-O-RING
13 549-4311 [2] STOPPER
14 210-0835 [2] SEAL-O-RING
15 360-3695 [4] PLUG
16 238-5082 [4] SEAL-O-RING
17 567-1725 [2] PISTON AS
18 567-1735 [2] PLATE
19 567-1718 [2] SUPPORT AS
20 567-1734 [2] BEARING
21 567-1742 [1] SHAFT-REAR
22 567-1732 [1] COVER-REAR
23 295-9516 [2] RING
24 567-1730 [8] BOLT-SOCKET HEAD
25 567-1721 [1] BODY AS-REAR
26 567-1749 [12] SEAL-O-RING
27 567-1731 [4] BOLT-SOCKET HEAD
28 549-4306 [2] PIN
29 567-1720 [1] BLOCK AS
30 567-1741 [1] GEAR
31 567-1739 [2] BEARING-ROLLER
32 567-1738 [2] BEARING-NEEDLE
33 234-4539 [2] DOWEL
34 567-1724 [1] BARREL AS
35 110-5525 [1] PLUG
36 214-7568 [1] SEAL-O-RING
37 542-1303 [18] SPRING
38 567-1736 [2] GUIDE-BALL
39 567-1737 [2] PLATE-RETAINER
40 567-1722 [1] BODY AS-FRONT
41 567-1719 [2] SWASHPLATE AS
42 096-5516 [2] RING-RETAINING (EXTERNAL)
43 567-1740 [2] BEARING-ROLLER
44 567-1728 [1] SEAL-LIP TYPE
45 567-1743 [1] SHAFT-FRONT
46 567-1733 [1] COVER-FRONT
47 567-1750 [2] SEAL-O-RING
48 200-3276 [2] SPACER
49 5I-4167 [2] PIN
50 567-1748 [1] SEAL-O-RING
51 277-2550 [2] SEAL-O-RING
52 196-3784 [2] PLUG
53 7Y-5221 M [4] BOLT-SOCKET HEAD (M20X2.5X45-MM)
54 347-6530 [8] SEAL-RECTANGULAR
55 7I-8164 [2] ORIFICE (1/16-NPTF)
56 559-3652 [12] SEAL-SQUARE
57 371-7201 [43] PLUG
58 567-1723 [1] BARREL AS
M   METRIC PART
PUMP GP-PISTON
566-8632 CAT349 CAT352 PUMP GP-PISTON
S/N LKG1-UP
PART OF 522-6893 PUMP & MTG GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 567-1715 [1] HEAD GP-PUMP
2 567-1716 [1] HEAD GP-PUMP
3 569-8251 Y [1] PUMP GP-HYDRAULIC
4 567-1726 Y [1] DRIVE GP-PUMP
Y   SEPARATE ILLUSTRATION
