CATERPILLAR 9T4833 9T1700 9T3877 hydraulic pump rotary group and spare parts for caterpillar 426 436 438 backhoe loader

CATERPILLAR 9T4833 9T1700 9T3877 hydraulic pump rotary group and spare parts for caterpillar 426 436 438 backhoe loader

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9T4833 9T1700 9T3877
backhoe loader CAT426 CAT436 CAT438
ROTARY GROUP 9T-3017 backhoe loader CAT416 CAT426 CAT436 CAT438
track skidder D5HTSK II
track-type tractor D5H
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 9T-3877 CY [1] VALVE GP-PRESS & FLOW CMPNSTR
2 9S-4185 C [1] PLUG-O-RING (3/4 X 16 THD)
3 3J-7354 [2] SEAL-O-RING (8.92MM ID)
4 8T-0372 M [1] BOLT (M12X1.75X90MM)
5 9S-8002 C [2] PLUG-O-RING
6 3K-0360 C [1] SEAL-O-RING (16.36MM ID)
7 9T-7032 [1] HEAD-LH
8 9T-1699 [1] SPRING
9 9T-1710 [1] POPPET
10 9T-1636 [1] SEAT
11 1T-0550 C [2] PIN-SPRING
12 9T-1652 [1] PIN
13 6V-5684 CM [6] BOLT (M12X1.75X45MM)
14 5A-3604 M [4] BOLT-SOCKET HEAD
15 9W-2109 [1] CONE
16 9W-2110 [1] CUP
17 9T-3038 B [1] KIT-SHAFT SHIM
18 9T-3030 [1] PLATE
19 9T-3017 [1] ROTATING GP-PUMP
9T-3026 [1] BARREL
20 002-3455 [1] RING-RETAINING
21 9T-3021 [1] GUIDE
22 9T-3023 [1] SPRING
23 9T-3025 [1] GUIDE
24 9T-3024 [1] SPACER
25 9T-3019 [1] PLATE
26 9T-3020 [1] PLATE
27 9T-3018 [9] PISTON AS
28 9T-1709 [1] KEY
29 9T-3039 [1] SHAFT
30 1M-8736 [1] CUP-ROLLER BEARING
31 1M-8735 [1] CONE-ROLLER BEARING
32 1A-2036 [1] DOWEL
33 9T-3027 [1] SWASHPLATE
34 9T-3033 [2] STOP
35 6V-8336 CM [1] BOLT (M12X1.75X70MM)
36 9T-3016 [1] KIT-PISTON CONTROL
37 2M-9780 [2] SEAL-O-RING (19.18MM ID)
38 9T-3014 [1] KIT-BIAS PISTON
39 9T-3015 [1] SPRING
40 8T-5039 C [3] SEAL-O-RING
41 9T-3035 [1] GASKET
42 9T-3037 [1] HOUSING
43 6V-5217 M [8] BOLT (M8X1.25X20MM)
44 9T-1712 [2] COVER
45 5P-3863 [2] SEAL-O-RING
46 9T-3036 [2] SPACER
47 9S-3582 [2] CONE-ROLLER BEARING
48 9S-3581 [2] CUP-ROLLER BEARING
49 9T-2216 B [1] KIT-PINTLE SHIM
50 8T-6785 [1] SEAL
51 008-3214 [1] RING-RETAINING
B   USE AS REQUIRED
C   CHANGE FROM PREVIOUS TYPE
M   METRIC PART
Y   SEPARATE ILLUSTRATION
PUMP GP-PISTON
9T4833 PUMP GP-PISTON SLIPPER*R
TYPE 2
9T3877-PAGE 244.01
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 9T-3877 CY [1] VALVE GP-PRESS & FLOW CMPNSTR
2 9S-4185 C [1] PLUG-O-RING (3/4 X 16 THD)
3 3J-7354 [2] SEAL-O-RING (8.92MM ID)
4 8T-0372 M [1] BOLT (M12X1.75X90MM)
5 9S-8002 C [2] PLUG-O-RING
6 3K-0360 C [1] SEAL-O-RING (16.36MM ID)
7 9T-7032 [1] HEAD-LH
8 9T-1699 [1] SPRING
9 9T-1710 [1] POPPET
10 9T-1636 [1] SEAT
11 1T-0550 C [2] PIN-SPRING
12 9T-1652 [1] PIN
13 6V-5684 CM [6] BOLT (M12X1.75X45MM)
14 5A-3604 M [4] BOLT-SOCKET HEAD
15 9W-2109 [1] CONE
16 9W-2110 [1] CUP
17 9T-3038 B [1] KIT-SHAFT SHIM
18 9T-3030 [1] PLATE
19 9T-3017 [1] ROTATING GP-PUMP
9T-3026 [1] BARREL
20 002-3455 [1] RING-RETAINING
21 9T-3021 [1] GUIDE
22 9T-3023 [1] SPRING
23 9T-3025 [1] GUIDE
24 9T-3024 [1] SPACER
25 9T-3019 [1] PLATE
26 9T-3020 [1] PLATE
27 9T-3018 [9] PISTON AS
28 9T-1709 [1] KEY
29 9T-3039 [1] SHAFT
30 1M-8736 [1] CUP-ROLLER BEARING
31 1M-8735 [1] CONE-ROLLER BEARING
32 1A-2036 [1] DOWEL
33 9T-3027 [1] SWASHPLATE
34 9T-3033 [2] STOP
35 6V-8336 CM [1] BOLT (M12X1.75X70MM)
36 9T-3016 [1] KIT-PISTON CONTROL
37 2M-9780 [2] SEAL-O-RING (19.18MM ID)
38 9T-3014 [1] KIT-BIAS PISTON
39 9T-3015 [1] SPRING
40 8T-5039 C [3] SEAL-O-RING
41 9T-3035 [1] GASKET
42 9T-3037 [1] HOUSING
43 6V-5217 M [8] BOLT (M8X1.25X20MM)
44 9T-1712 [2] COVER
45 5P-3863 [2] SEAL-O-RING
46 9T-3036 [2] SPACER
47 9S-3582 [2] CONE-ROLLER BEARING
48 9S-3581 [2] CUP-ROLLER BEARING
49 9T-2216 B [1] KIT-PINTLE SHIM
50 8T-6785 [1] SEAL
51 008-3214 [1] RING-RETAINING
B   USE AS REQUIRED
C   CHANGE FROM PREVIOUS TYPE
M   METRIC PART
Y   SEPARATE ILLUSTRATION
