551-1118 CAT336 CAT340 CAT345 CAt345GC PUMP GP-HYDRAULIC
S/N JHD1-UP
PART OF 550-4341 PUMP GP-MAIN HYDRAULIC |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
8T-4131 M |
[4] |
NUT (M20X2.5-THD) |
|
| 2 |
551-1107 |
[2] |
SETSCREW |
|
| 3 |
549-4309 |
[2] |
COVER |
|
| 4 |
7I-8171 |
[2] |
RING-BACKUP |
|
| 5 |
095-1522 |
[2] |
SEAL-O-RING |
|
| 6 |
549-4310 |
[2] |
STOPPER |
|
| 7 |
549-4327 |
[2] |
PISTON AS |
|
| 8 |
549-4308 |
[2] |
SEAL-O-RING |
|
| 9 |
242-6919 M |
[2] |
SETSCREW (M20X2.5X56-MM) |
|
| 10 |
551-1108 |
[2] |
BOLT-EYE |
|
| 11 |
347-6530 |
[8] |
SEAL-RECTANGULAR |
|
| 12 |
7I-8172 |
[2] |
RING-BACKUP |
|
| 13 |
095-1701 |
[2] |
SEAL-O-RING |
|
| 14 |
549-4311 |
[2] |
STOPPER |
|
| 15 |
549-4331 |
[2] |
PISTON AS |
|
| 16 |
549-4317 |
[2] |
PLATE |
|
| 17 |
6V-5192 M |
[4] |
BOLT-SOCKET HEAD (M8X1.25X30-MM) |
|
| 18 |
551-1111 |
[1] |
FLANGE |
|
| 19 |
095-1717 |
[2] |
SEAL-O-RING |
|
| 20 |
551-1102 |
[1] |
BODY AS-REAR |
|
| 21 |
551-1114 |
[1] |
SHAFT-REAR |
|
| 22 |
549-4329 |
[2] |
SWASHPLATE AS |
|
| 23 |
551-1110 |
[4] |
BOLT-SOCKET HEAD |
|
| 24 |
549-4330 |
[1] |
BARREL AS |
|
| 25 |
559-3652 |
[14] |
SEAL-SQUARE |
|
| 26 |
095-1715 |
[1] |
SEAL-O-RING |
|
| 27 |
551-1113 |
[1] |
GEAR |
|
| 28 |
551-1101 |
[1] |
BLOCK AS |
|
| 29 |
549-4321 |
[2] |
BEARING |
|
| 30 |
549-4306 |
[4] |
PIN |
|
| 31 |
551-1117 |
[1] |
BARREL AS |
|
| 32 |
360-3695 |
[4] |
PLUG |
|
| 33 |
238-5082 |
[4] |
SEAL-O-RING |
|
| 34 |
200-3280 |
[18] |
SPRING |
|
| 35 |
549-4319 |
[2] |
BUSHING |
|
| 36 |
549-4320 |
[2] |
PLATE |
|
| 37 |
8T-4241 |
[2] |
RING-RETAINING |
|
| 38 |
549-4322 |
[2] |
BEARING |
|
| 39 |
551-1103 |
[1] |
BODY AS-FRONT |
|
| 40 |
6V-8202 M |
[4] |
BOLT-SOCKET HEAD (M8X1.25X16-MM) |
|
| 41 |
551-1112 |
[1] |
COVER-FRONT |
|
| 42 |
551-1115 |
[1] |
SHAFT-FRONT |
|
| 43 |
551-1109 |
[1] |
SEAL-LIP TYPE |
|
| 44 |
247-8719 |
[2] |
SPACER (50X64X3-MM THK) |
|
| 45 |
247-8786 |
[2] |
DOWEL |
|
| 46 |
549-4316 |
[2] |
SUPPORT |
|
| 47 |
371-7201 |
[16] |
PLUG |
|
| 48 |
6V-3938 M |
[4] |
BOLT (M10X1.5X20-MM) |
|
| 49 |
516-4306 |
[1] |
COVER |
|
| 50 |
110-5525 |
[1] |
PLUG |
|
| 51 |
382-4825 |
[1] |
SEAL-O-RING |
|
| 52 |
184-1836 M |
[4] |
BOLT (M18X2.5X45-MM) |
|
|
M |
|
METRIC PART |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
8T-4223 |
[2] |
WASHER-HARD (13.5X25.5X3-MM THK) |
|
| 2 |
8T-4956 M |
[2] |
BOLT (M12X1.75X35-MM) |
|
| 3 |
236-6919 |
[1] |
SEAL-O-RING |
|
| 4 |
447-1720 M |
[4] |
BOLT (M20X2.5X70-MM) |
|
| 5 |
451-2176 |
[4] |
WASHER-HARD (22X35X3.5-MM THK) |
|
| 6 |
550-4341 |
[1] |
PUMP GP-MAIN HYDRAULIC |
|
| 7 |
511-8604 |
[1] |
SEAL-O-RING |
|
| 8 |
524-0924 |
[1] |
PUMP GP-PISTON |
|
| 9 |
2B-7556 |
[2] |
CORK |
|
|
M |
|
METRIC PART |
|
Y |
|
SEPARATE ILLUSTRATION |
