Caterpillar CAT336 CAT336FLXE CAT336GC CAT336F CAT340 CAT340F excavator 568-9405 568-9802 574-3203 511-0315 travel motor parts

Caterpillar CAT336 CAT336FLXE CAT336GC CAT336F CAT340 CAT340F excavator 568-9405 568-9802 574-3203 511-0315 travel motor parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
MOTOR GP-TRAVEL
568-9405 CAT336 CAT336FL CAT336GC CAT340 CAT340F CAT345GC MOTOR GP-TRAVEL
S/N KEF210-UP
PART OF 568-9802 MOTOR & MTG GP-TRAVEL
FIELD REPLACEMENT ORDER @@@@@574-3203@@@@@
FIELD REPLACEMENT FOR @@@@@511-0315@@@@@
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 536-2653 [1] BALL BEARING
2 8T-2503 M [10] BOLT-SOCKET HEAD (M14X2X35-MM)
3 536-2662 [4] PIN
4 536-2640 [1] ROTATING GP-MOTOR
5 536-2641 [1] RETAINER AS
6 536-2650 [1] SWASHPLATE
7 536-2663 [4] SPRING
8 139-7308 [4] PLUG
9 570-9925 [1] SHAFT
10 536-2642 [1] BODY AS
11 536-2655 J [1] SEAL-LIP TYPE
12 536-2652 [1] BALL BEARING
13 536-2651 [2] BALL
14 536-2656 [4] PLATE-FRICTION
15 536-2657 [3] PLATE-SEPARATOR
16 536-2659 [1] GUIDE-PISTON
17 536-2658 [1] PISTON-BRAKE
18 536-2661 [2] SPRING-BRAKE
19 536-2660 [8] SPRING-BRAKE
20 536-2654 [1] PIN
21 279-4706 [2] PLUG
22 536-2639 [1] HEAD-MOTOR
23 568-3820 [2] VALVE AS-RELIEF
24 7I-1041 [1] SPRING
25 137-3687 [2] PLUG
26 536-2664 [2] PLUG
27 108-9151 [2] ORIFICE
28 536-2643 [2] SEAT-SPRING
29 536-2644 [2] SPRING
30 536-2645 [2] SEAT-SPRING
31 536-2637 [2] CAP AS
32 536-2648 [3] ORIFICE
33 571-7210 J [1] SEAL-D-RING
  AVAILABLE REPAIR KIT(S):
571-7202 [1] KIT-SEAL
  (INCLUDES SEALS & BACKUP RINGS)
J   KIT MARKED J SERVICES PART(S) MARKED J
M   METRIC PART
Y   SEPARATE ILLUSTRATION
MOTOR & MTG GP-TRAVEL
519-2479 MOTOR & MTG GP-TRAVEL
S/N KEF1-209
PART OF 511-6010, 511-6017 DRIVE GP-FINAL
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 096-0008 M [4] BOLT-SOCKET HEAD (M16X2X140-MM)
2 511-0315 Y [1] MOTOR GP-TRAVEL
3 3F-1547 [1] SEAL-O-RING
M   METRIC PART
Y   SEPARATE ILLUSTRATION
MOTOR GP-TRAVEL
511-0315 CAT335FL CAT336 CAT336DL CAT336D2 CAT336D2L CAT336D2XE CAT336F CAT336FL CAT340D2L CAT340F CAT345GC MOTOR GP-TRAVEL
S/N KEF1-209
PART OF 519-2479 MOTOR & MTG GP-TRAVEL
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 536-2653 [1] BALL BEARING
2 8T-2503 M [10] BOLT-SOCKET HEAD (M14X2X35-MM)
3 536-2662 [4] PIN
4 536-2640 [1] ROTATING GP-MOTOR
5 536-2641 [1] RETAINER AS
6 536-2650 [1] SWASHPLATE
7 536-2663 [4] SPRING
8 139-7308 [4] PLUG
9 536-2649 [1] SHAFT
10 536-2642 [1] BODY AS
11 536-2655 [1] SEAL-LIP TYPE
12 536-2652 [1] BALL BEARING
13 536-2651 [2] BALL
14 536-2656 [4] PLATE-FRICTION
15 536-2657 [3] PLATE-SEPARATOR
16 536-2659 [1] GUIDE-PISTON
17 536-2658 [1] PISTON-BRAKE
18 536-2661 [2] SPRING-BRAKE
19 536-2660 [8] SPRING-BRAKE
20 536-2654 [1] PIN
21 279-4706 [2] PLUG
22 536-2639 [1] HEAD-MOTOR
23 536-2638 [2] VALVE AS-RELIEF
24 7I-1041 [1] SPRING
25 137-3687 [2] PLUG
26 536-2664 [2] PLUG
27 108-9151 [2] ORIFICE
28 536-2643 [2] SEAT-SPRING
29 536-2644 [2] SPRING
30 536-2645 [2] SEAT-SPRING
31 536-2637 [2] CAP AS
32 536-2648 [3] ORIFICE
M   METRIC PART
