Caterpillar CAT320 CAT320GC excavator hydraulic piston pump rotary group and spare parts

Caterpillar CAT320 CAT320GC excavator hydraulic piston pump rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
531-9885 CAT320 CAT320GC
SWASHPLATE GP
543-3690 SWASHPLATE GP
S/N BR41-UP
PART OF 531-9885 PUMP GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3714 [1] SWASHPLATE AS
2 543-3716 [1] LINER-BEARING
3 543-3717 [1] LINER-BEARING
4 543-3715 [1] PLATE
5 543-3718 [2] SCREW (M5X16-MM)
SWASHPLATE GP
543-3691 SWASHPLATE GP
S/N BR41-UP
PART OF 531-9885 PUMP GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3719 [1] SWASHPLATE AS
2 543-3720 [1] LINER-BEARING
3 543-3721 [1] LINER-BEARING
4 543-3715 [1] PLATE
5 543-3718 [2] SCREW (M5X16-MM)
531-9885
PART OF 489-3482 PUMP & MTG GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3690 Y [1] SWASHPLATE GP
2 543-3692 Y [2] CONTROL AS-PISTON PUMP
3 543-3689 Y [1] SHAFT & CPLG GP-PISTON PUMP (MAIN HYDRAULIC)
4 543-3694 Y [2] VALVE GP-PUMP CONTROL (CONTROL)
5 543-3691 Y [1] SWASHPLATE GP
6 543-3693 Y [1] COVER GP-PUMP
7 517-2780 [1] RING-RETAINING
8 543-3698 [1] SEAL-LIP TYPE
9 9T-3743 [2] SHIM (1-MM THK)
10 095-0687 M [16] BOLT-SOCKET HEAD (M14X2X45-MM)
11 543-3695 [1] FLANGE
12 543-3687 [1] ROTATING GP-PUMP
13 465-4551 [4] PIN-CYLINDER
14 543-3697 [2] GASKET
15 543-3688 [1] ROTATING GP-PUMP
16 543-3696 [1] BLOCK
17 469-3314 [1] SEAL-O-RING
18 543-3699 [1] COVER
19 6V-3938 M [2] BOLT (M10X1.5X20-MM)
M   METRIC PART
Y   SEPARATE ILLUSTRATION
ROTATING GP-PUMP
543-3687 ROTATING GP-PUMP
S/N BR41-UP
PART OF 531-9885 PUMP GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3703 [1] PLATE-RETAINING
2 543-3701 [9] PISTON AS
3 179-6916 [20] SPRING
4 543-3705 [2] PLATE
5 543-3706 [1] RING-RETAINING
6 543-3700 [1] BARREL
7 202-6535 [1] PIN
8 543-3704 [1] PLATE-CONTROL
9 6E-4373 [1] SPRING
10 543-3707 [1] PLATE
11 543-3702 [1] GUIDE-BALL
ROTATING GP-PUMP
543-3688 ROTATING GP-PUMP
S/N BR41-UP
PART OF 531-9885 PUMP GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3703 [1] PLATE-RETAINING
2 543-3701 [9] PISTON AS
3 179-6916 [20] SPRING
4 543-3705 [2] PLATE
5 543-3706 [1] RING-RETAINING
6 543-3700 [1] BARREL
7 202-6535 [1] PIN
8 543-3708 [1] PLATE-CONTROL
9 6E-4373 [1] SPRING
10 543-3707 [1] PLATE
11 543-3702 [1] GUIDE-BALL
CONTROL AS-PISTON PUMP
543-3692 CONTROL AS-PISTON PUMP
S/N BR41-UP
PART OF 531-9885 PUMP GP-MAIN HYDRAULIC
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 543-3724 [1] PISTON AS
543-3725 [1] RING
2 524-6339 [1] CAP AS
3 543-3722 [1] PISTON AS
543-3723 [1] SEAL AS
COUPLING GP-FLEXIBLE
339-6951 COUPLING GP-FLEXIBLE
S/N BR41-UP
PART OF 341-5368 COUPLING GP-PUMP
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 7Y-0466 M [2] SETSCREW-SOCKET (M16X2X22-MM)
2 7Y-0467 M [4] BOLT-SOCKET HEAD (M18X2.5X55-MM)
3 339-6952 [1] HUB
4 339-6953 [4] INSERT-COUPLING
5 339-6954 [4] INSERT-COUPLING
6 339-6955 [1] ELEMENT-COUPLING
7 7Y-0468 [8] PIN-SPRING
M   METRIC PART
