CATERPILLAR 9T4833 hydraulic axial variable fixed piston pump rotary group and spare parts

CATERPILLAR 9T4833 hydraulic axial variable fixed piston pump rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9T4833 9T1700 9T3877
backhoe loader CAT426 CAT436 CAT438
ROTARY GROUP 9T-3017 backhoe loader CAT416 CAT426 CAT436 CAT438
track skidder D5HTSK II
track-type tractor D5H
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 9T-3877 CY [1] VALVE GP-PRESS & FLOW CMPNSTR
2 9S-4185 C [1] PLUG-O-RING (3/4 X 16 THD)
3 3J-7354 [2] SEAL-O-RING (8.92MM ID)
4 8T-0372 M [1] BOLT (M12X1.75X90MM)
5 9S-8002 C [2] PLUG-O-RING
6 3K-0360 C [1] SEAL-O-RING (16.36MM ID)
7 9T-7032 [1] HEAD-LH
8 9T-1699 [1] SPRING
9 9T-1710 [1] POPPET
10 9T-1636 [1] SEAT
11 1T-0550 C [2] PIN-SPRING
12 9T-1652 [1] PIN
13 6V-5684 CM [6] BOLT (M12X1.75X45MM)
14 5A-3604 M [4] BOLT-SOCKET HEAD
15 9W-2109 [1] CONE
16 9W-2110 [1] CUP
17 9T-3038 B [1] KIT-SHAFT SHIM
18 9T-3030 [1] PLATE
19 9T-3017 [1] ROTATING GP-PUMP
9T-3026 [1] BARREL
20 002-3455 [1] RING-RETAINING
21 9T-3021 [1] GUIDE
22 9T-3023 [1] SPRING
23 9T-3025 [1] GUIDE
24 9T-3024 [1] SPACER
25 9T-3019 [1] PLATE
26 9T-3020 [1] PLATE
27 9T-3018 [9] PISTON AS
28 9T-1709 [1] KEY
29 9T-3039 [1] SHAFT
30 1M-8736 [1] CUP-ROLLER BEARING
31 1M-8735 [1] CONE-ROLLER BEARING
32 1A-2036 [1] DOWEL
33 9T-3027 [1] SWASHPLATE
34 9T-3033 [2] STOP
35 6V-8336 CM [1] BOLT (M12X1.75X70MM)
36 9T-3016 [1] KIT-PISTON CONTROL
37 2M-9780 [2] SEAL-O-RING (19.18MM ID)
38 9T-3014 [1] KIT-BIAS PISTON
39 9T-3015 [1] SPRING
40 8T-5039 C [3] SEAL-O-RING
41 9T-3035 [1] GASKET
42 9T-3037 [1] HOUSING
43 6V-5217 M [8] BOLT (M8X1.25X20MM)
44 9T-1712 [2] COVER
45 5P-3863 [2] SEAL-O-RING
46 9T-3036 [2] SPACER
47 9S-3582 [2] CONE-ROLLER BEARING
48 9S-3581 [2] CUP-ROLLER BEARING
49 9T-2216 B [1] KIT-PINTLE SHIM
50 8T-6785 [1] SEAL
51 008-3214 [1] RING-RETAINING
B   USE AS REQUIRED
C   CHANGE FROM PREVIOUS TYPE
M   METRIC PART
Y   SEPARATE ILLUSTRATION
