CATERPILLAR 6E-3136 piston pump piston shoe piston subassembly

CATERPILLAR 6E-3136 piston pump piston shoe piston subassembly

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
6E-3136 ROTARY GROUP 6E-6571 MOTOR GRADER  CAT12H CAT12K CAT120H CAT120HES CAT120HNA CAT120K CAT120K2 CAT135H CAT135HNA CAT140H CAT140K CAT140K2 CAT160H CAT160K
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 6E-6594 [1] BEARING-SWASH
2 6E-4224 [1] PLUG-SWASHPLATE
3 033-6036 [1] SEAL-O-RING
4 102-2386 [1] HEAD-PUMP
5 9T-1699 [1] SPRING
6 9T-1710 [1] POPPET
7 9T-1636 [1] SEAT
8 6E-6596 [1] COVER-TRUNNION
9 6V-3834 [1] SEAL-O-RING
10 3E-4302 M [2] SCREW-FLAT HEAD (M4X0.7X10-MM)
11 6V-8214 M [3] BOLT (M6X1X20-MM)
12 6E-6597 [1] BEARING-SWASH
13 6V-7673 M [2] BOLT (M12X1.75X50-MM)
14 8T-0372 M [4] BOLT (M12X1.75X90-MM)
15 104-3122 Y [1] VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)
16 109-3204 [3] SEAL-O-RING
17 6V-8337 M [4] BOLT-SOCKET HEAD (M8X1.25X35-MM)
18 095-0888 [2] PIN-SPRING
19 102-2385 [1] SHAFT-PUMP
20 102-2384 [1] HOUSING-PUMP
21 006-8663 [1] RING
22 8T-4750 [1] SEAL-LIP TYPE
23 6E-6599 [1] KIT-BIAS PISTON
  (INCLUDES SPRING,ROD,PISTON,SEAL)
24 6E-6600 [1] SPRING-BIAS
25 6E-6571 [1] ROTATING GP-PUMP (STEERING)
26 6E-6601 [1] GASKET
27 7L-9061 [2] SEAL-O-RING
28 3E-7417 [2] PLUG
29 8T-7876 [2] SEAL-O-RING
30 9T-1633 [1] PLATE
31 9T-2197 B [1] SHIM PACK (INCLUDES 17-SHIMS)
32 1P-6872 [1] CUP-BEARING
33 004-9040 [1] CONE-BEARING
34 9T-1652 [1] PIN
35 6E-6602 [1] KIT-PISTON CONTROL
  (INCLUDES ROD,PISTON,SEAL)
36 167-1802 [1] SWASHPLATE GP
167-1801 [2] STOP
1H-3937 [2] PIN
37 7T-8273 [1] CUP-BEARING
38 7T-8272 [1] CONE-BEARING
39 3K-0360 [1] SEAL-O-RING
40 9S-4185 [1] PLUG (3/4-16-THD)
41 104-3124 [1] SHIELD
B   USE AS REQUIRED
M   METRIC PART
Y   SEPARATE ILLUSTRATION
