Caterpillar 209-5992 334-9986 511-0313 511-6006 511-6008 519-2478 557-5878 557-5880 travel motor rotary group

Name: Caterpillar 209-5992 334-9986 511-0313 511-6006 511-6008 519-2478 557-5878 557-5880 travel motor rotary group
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

Caterpillar 209-5992 334-9986 511-0313 511-6006 511-6008 519-2478 557-5878 557-5880 travel motor rotary group

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

MOTOR & MTG GP-TRAVEL 519-2478 MOTOR & MTG GP-TRAVEL S/N BR91-UP PART OF 511-6006, 511-6008 DRIVE GP-FINAL

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
1	095-0707 M	[3]	BOLT (M16X2X120-MM)
2	511-0313	[1]	MOTOR GP-TRAVEL
3	095-1685	[1]	SEAL-O-RING
	M		METRIC PART
	Y		SEPARATE ILLUSTRATION
MOTOR & MTG GP-TRAVEL 334-9986 MOTOR & MTG GP-TRAVEL S/N BR91-UP PART OF 507-6558, 507-6561 DRIVE GP-FINAL

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
1	209-5992	[1]	MOTOR GP-TRAVEL
2	322-8714 Y	[1]	VALVE GP-TRAVEL COUNTERBALANCE
3	095-0707 M	[3]	BOLT (M16X2X120-MM)
4	095-1685	[1]	SEAL-O-RING
5	8C-8729 M	[6]	BOLT-SOCKET HEAD (M12X1.75X80-MM)
	M		METRIC PART
	R		REMANUFACTURED PART MAY BE AVAILABLE
	Y		SEPARATE ILLUSTRATION
MOTOR GP-TRAVEL 209-5992 CAT318B CAT318C CAT318FL CAT319DL CAT320C CAT320D CAT320D2 CAT320D2 CAT320DLN CAT320DLRR CAT320D2GC CAT320E CAT320FL CAT320GC CAT321C CAT322C CAT323DL CAT323FL CAT323FLN CAT324D CAT324DLN CAT325F CAT326D2 CAT326D2L CAT326FL MOTOR GP-TRAVEL S/N BR91-UP PART OF 334-9986 MOTOR & MTG GP-TRAVEL

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
1	209-5894	[1]	SHAFT
2	087-4743	[2]	STOP
3	094-1399	[1]	RING-RETAINING
4	7Y-4212	[1]	BEARING
5	087-4757	[2]	PISTON
6	107-6969	[1]	BODY
7	122-5114	[1]	GUIDE-BALL
8	209-5909	[1]	PLATE-CAM
9	147-5860	[1]	PISTON AS
10	133-6777	[1]	BARREL AS
11	107-6954	[4]	PLATE-FRICTION
12	107-6955	[5]	PLATE-SEPARATOR
13	096-1523	[1]	GUIDE-PISTON
14	7Y-4213	[1]	PISTON-BRAKE
15	7Y-4202	[1]	HEAD
16	8T-4944 M	[10]	BOLT-SOCKET HEAD (M16X2X40-MM)
17	096-1521 B	[1]	SHIM (1-MM THK)
18	096-3785 B	[1]	SHIM (1.2-MM THK)
19	096-3786 B	[1]	SHIM (1.4-MM THK)
20	096-3787 B	[1]	SHIM (1.6-MM THK)
21	096-1522 B	[1]	SHIM (2-MM THK)
22	096-3788 B	[1]	SHIM (1.8-MM THK)
23	096-5916	[2]	SEAT
24	2D-6642	[2]	BALL
25	095-1572 J	[2]	SEAL-O-RING
26	096-5919 J	[2]	RING-BACKUP
27	096-5915	[2]	RETAINER
28	096-4003	[1]	SET-BEARING
	7Y-4234	[1]	RACE-NEEDLE ROLLER
29	095-1585 J	[1]	SEAL-O-RING
30	087-4742	[1]	VALVE
31	096-1519	[1]	SEAT
32	095-7380	[1]	SPRING
33	095-7382	[1]	RETAINER
34	094-1875	[1]	DOWEL
35	095-7378	[1]	WASHER SET
36	8T-6759	[10]	PLUG-PIPE
37	095-1575 J	[3]	SEAL-O-RING
38	096-4378 J	[1]	RING-BACKUP
39	096-4377 J	[2]	SEAL-O-RING
40	8T-6759	[1]	PLUG-PIPE
41	095-7384 J	[1]	SEAL-O-RING
42	095-7383 J	[1]	SEAL-O-RING
43	095-7386 J	[1]	RING-BACKUP
44	095-7387 J	[1]	RING
45	095-1685 J	[1]	SEAL-O-RING
46	118-4057	[9]	SPRING
47	7Y-4215	[1]	SPACER
48	095-1586 J	[2]	SEAL-O-RING
49	7Y-4217 J	[2]	RING-BACKUP
50	096-4376 J	[1]	SEAL-LIP TYPE
51	123-2008	[2]	KEY
54	3K-0360 J	[1]	SEAL-O-RING
55	9S-4185	[1]	PLUG (3/4-16-THD)
56	095-1700 J	[2]	SEAL-O-RING
57	7Y-4224	[2]	ORIFICE
58	096-3978	[1]	SPRING
59	7Y-4216	[1]	SPOOL
60	2M-9780 J	[1]	SEAL-O-RING
61	087-4786	[1]	ADAPTER
62	121-1558	[2]	PIN
64	094-1882 B	[11]	PLUG

			AVAILABLE REPAIR KIT(S):
	7Y-4222	[1]	KIT-SEAL (TRAVEL MOTOR)
	B		USE AS REQUIRED
	J		KIT MARKED J SERVICES PART(S) MARKED J
	M		METRIC PART
MOTOR GP-TRAVEL 511-0313 CAT318FL CAT320GC CAT323 CAT323EL CAT323F CAT323FSA CAT324DL CAT324E CAT325FL CAT326D2 CAT326F CAT326FL CAT329EL CAT330D2 CAT330F CAT330FL MOTOR GP-TRAVEL S/N BR91-UP PART OF 557-5878, 557-5880 DRIVE GP-FINAL, 519-2478 MOTOR & MTG GP-TRAVEL

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
1	551-5110	[1]	BALL BEARING
2	8T-2503 M	[7]	BOLT-SOCKET HEAD (M14X2X35-MM)
3	551-5116	[4]	PIN
4	551-5104	[1]	ROTATING GP-MOTOR
5	551-5105	[1]	RETAINER AS
6	551-5108	[1]	SWASHPLATE
7	551-5118	[4]	SPRING
8	139-7308	[2]	PLUG
9	551-5107	[1]	SHAFT
10	551-5106	[1]	BODY AS
11	551-5111	[1]	SEAL-LIP TYPE
12	551-5109	[1]	BEARING-ROLLER
13	536-2651	[2]	BALL
14	551-5112	[4]	PLATE
15	551-5113	[4]	PLATE
16	551-5115	[1]	GUIDE-PISTON
17	551-5114	[1]	PISTON-BRAKE
18	137-3688	[1]	ORIFICE
19	551-5117	[14]	SPRING-BRAKE
20	280-3109	[1]	PIN
21	279-4706	[2]	PLUG
22	551-5103	[1]	HEAD-MOTOR
23	559-2948	[2]	VALVE AS-RELIEF
24	551-5120	[1]	SPRING
25	099-7197	[2]	PLUG
26	551-5119	[2]	PLUG
27	108-9151	[2]	ORIFICE
28	536-2643	[2]	SEAT-SPRING
29	559-2950	[2]	SPRING
30	559-2951	[2]	SEAT-SPRING
31	559-2947	[2]	CAP AS
32	536-2648	[2]	ORIFICE
	M		METRIC PART
