CATERPILLAR 161-8919 hydraulic axial variable fixed piston motor rotary group and spare parts

CATERPILLAR 161-8919 hydraulic axial variable fixed piston motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
161-8919 824C, 824G II, 824H, 825G II, 825H, 966G, 966G II, 966H, 966K, 966M XE, 972G, 972G II, 972H, 972M XE, 980C, 980G II
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 1D-4539 [3] BOLT (5/16-18X2.5-IN)
2 1B-9575 [3] BOLT (5/16-18X1.56-IN)
3 9S-8004 [1] PLUG (9/16-18-THD)
4 3J-1907 [2] SEAL-O-RING
5 117-9734 [1] PLUG (9/16-18 THD)
6 9J-5706 [1] PLUNGER
7 9J-5696 [1] SPRING
8 033-5381 [1] BEARING AS-NEEDLE
9 5P-1827 [2] RACE-THRUST BEARING
10 5P-1828 [1] BEARING-THRUST
11 135-2037 [1] RING-RETAINING
12 117-9736 J [1] SEAL AS-SHAFT
13 117-9735 [1] SEAL-SHAFT
14 8C-3078 [1] SEAL-O-RING
15 131-4859 [1] SHAFT-MOTOR
16 5L-4019 [2] RING-RETAINING
17 5P-1941 [1] BEARING AS-NEEDLE
18 3G-3484 [1] PLATE-CAM
19 3G-3483 [1] ROTATOR
20 117-9737 [1] PLATE-VALVE
21 3K-0715 [1] SEAL-O-RING
5H-8985 F [1] PIN-SPRING (4.76-MM)
8L-6565 F [1] PIN-SPRING (3.18-MM)
F   NOT SHOWN
J   INCLUDES ITEMS 13 & 14 SEALS
