CATERPILLAR 096-4355 085-4530 1R-8671 1R-9902 HYDRAULIC PUMP PARTS

Name: CATERPILLAR 096-4355 085-4530 1R-8671 1R-9902 HYDRAULIC PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

CATERPILLAR 096-4355 085-4530 1R-8671 1R-9902 HYDRAULIC PUMP PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

096-4355 085-4530 1R-8671 1R-9902 E200B

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
1-325.	096-4355	[1]	PUMP ASSY.
	085-4530	[1]	PUMP ASSY.
	1R-8671	[1]	PUMP ASSY.
	1R-9902	[1]	PUMP ASSY.
	096-6379	[1]	REPAIR KIT
1	096-3981	[1]	BODY, FR.
	1R-6170	[1]	BODY, FR.
	1R-7164	[1]	BODY, FR.
2	095-1578	[8]	O-RING
3	096-1445	[2]	PLUG
4	096-3831	[1]	ORIFICE
5	094-1882	[4]	PLUG
6	096-3947	[1]	SPRING
	099-2147	[1]	SPRING
	099-3671	[1]	SPRING
	4I-1514	[1]	PISTON. NF. ASSY.
7	096-5906	[1]	PISTON
8	099-3669 B		SHIM
	099-6109 B		SHIM
	099-6110 B		SHIM
	B		USE AS REQUIRED
	N		NOT SUPPLIED INDIVIDUALLY
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
8	099-6111 B		SHIM
	099-6112 B		SHIM
	099-6113 B		SHIM
	099-6115 B		SHIM
	099-6117 B		SHIM
	099-6118 B		SHIM
	099-6119 B		SHIM
	099-6120 B		SHIM
	099-6121 B		SHIM
	099-6122 B		SHIM
	099-6123 B		SHIM
	099-6124 B		SHIM
	099-6125 B		SHIM
	099-6126 B		SHIM
	099-6127 B		SHIM
	099-6128 B		SHIM
	099-3670 B		SHIM
11	096-4363	[1]	SPRING
12	096-5905	[1]	PISTON
13	095-1657	[1]	O-RING
	B		USE AS REQUIRED
	N		NOT SUPPLIED INDIVIDUALLY
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
14	096-4015	[1]	COVER
15	8T-1159	[4]	BOLT
16	095-1600	[2]	O-RING
17	096-4925	[2]	RING
18	096-4012	[2]	STOPPER
19	096-4010	[2]	COVER
20	8T-0273	[8]	BOLT
21	096-4011	[2]	SCREW
22	096-4878	[2]	NUT
23	096-3986	[1]	SHAFT, FR.
	4I-9467	[1]	SHAFT, FR.
24	096-4009	[1]	PISTON
26-27.	096-4014	[1]	SPOOL SLEEVE ASSY.
31	096-4843	[1]	STEEL BALL
32	096-4013	[1]	GUIDE
	085-4525	[1]	GUIDE
33	096-4362	[1]	SPRING
35	096-4021	[1]	RETAINER
36	8T-0211	[2]	O-RING
	N		NOT SUPPLIED INDIVIDUALLY
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
37	096-2966	[1]	SCREW
38	096-4874	[1]	NUT
39	096-4020	[1]	COVER
41	095-1658	[1]	O-RING
42	094-1815	[1]	PLUG
43	096-4002	[1]	BEARING
44	095-7424	[1]	RING
45	096-3998	[1]	SEAL
46	096-3944	[1]	O-RING
47	096-3984	[1]	CASE
48	096-3983	[1]	RING
49	093-1323	[1]	PLUG
50	095-1526	[1]	O-RING
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
61	096-4006	[1]	RETAINER
	4I-9474	[1]	RETAINER
62	095-1522	[1]	O-RING
63	096-4004	[2]	BUSHING
64	096-3988	[1]	PLATE
	087-5192	[1]	PLATE
66-68.	096-3989	[1]	PISTON SHOE RETAINER ASSY.
	4I-9469	[1]	PISTON SHOE RETAINER ASSY.
76	096-3995	[1]	RETAINER
	096-4387	[1]	RETAINER
77	096-3996	[1]	SPACER
	096-4388	[1]	SPACER
81-82.	096-3990	[1]	DRUM ASSY.
	099-6342	[1]	DRUM ASSY.
86	096-4001	[6]	SPRING
	096-4389	[6]	SPRING
	N		NOT SUPPLIED INDIVIDUALLY
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
87	096-3991	[1]	RETAINER
88	096-3997	[9]	SEAL
89	096-3992	[1]	PLATE
90	096-3993	[1]	PLATE, FR.
91	094-1875	[2]	ROLLER
92	094-1881	[1]	PLATE
93	096-4018	[1]	LINK, FR.
94	096-4016	[1]	ROLLER
	4I-9476	[1]	ROLLER
95	096-4007	[1]	SPACER
	4I-9475	[1]	SPACER
96	096-3943	[1]	NUT
97	095-0844	[1]	PIN
98	096-4017	[1]	PIN, DOWEL
99	096-4008	[1]	BLOCK
100	096-3987	[1]	HANGER
	1R-9734	[1]	HANGER
101	8T-1159	[8]	BOLT
102-103.	122-2917	[2]	SHAFT ASSY.
102	096-4000	[2]	SHAFT
	4I-9470	[2]	SHAFT
	122-2915	[2]	SHAFT
103	095-1659	[2]	O-RING
	6V-7660	[2]	O-RING
	6V-7657	[2]	O-RING
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
104	096-4001	[3]	SPRING
	096-4389	[3]	SPRING
105	094-1875	[1]	ROLLER
111-113.	4I-9472	[1]	BARREL PLATE ASSY., FR.
	N		NOT SUPPLIED INDIVIDUALLY
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
121	096-4003	[2]	BEARING
122	096-3999	[1]	COUPLING
123	096-4921	[2]	O-RING
124	096-4880	[8]	NUT
125	096-3945	[8]	WASHER, SPRING
126	096-3946	[8]	STUD
127	096-4357	[1]	BLOCK
128	094-1882	[8]	PLUG
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
141	094-1875	[2]	ROLLER
142	096-3994	[1]	PLATE, RE.
143	096-3992	[1]	PLATE
144	096-3991	[1]	RETAINER
145	096-4001	[6]	SPRING
	096-4389	[6]	SPRING
146	096-3996	[1]	SPACER
	096-4388	[1]	SPACER
147	096-3995	[1]	RETAINER
	096-4387	[1]	RETAINER
148	096-3988	[1]	PLATE
	087-5192	[1]	PLATE
149	095-0844	[1]	PIN
150	096-3943	[1]	NUT
151	096-4007	[1]	SPACER
	4I-9475	[1]	SPACER
152	096-4016	[1]	ROLLER
	4I-9476	[1]	ROLLER
153	096-4019	[1]	LINK, RE.
154	094-1881	[1]	PLATE
155	096-4004	[2]	BUSHING
Parts for your E200B EXCAVATOR:

CATERPILLAR SIS
Pos.	Part No	Qty	Parts name	Comments
156	095-1522	[1]	O-RING
157	096-4006	[1]	RETAINER
	4I-9474	[1]	RETAINER
158	8T-1159	[8]	BOLT
159-160.	122-2917	[2]	SHAFT ASSY.
159-160.	096-4000	[2]	SHAFT
	4I-9470	[2]	SHAFT
	122-2915	[2]	SHAFT
160	095-1659	[2]	O-RING
	6V-7660	[2]	O-RING
	6V-7657	[2]	O-RING
161	096-3987	[1]	HANGER
	1R-9734	[1]	HANGER
162	096-4008	[1]	BLOCK
163	096-4017	[1]	PIN, DOWEL
166-168.	096-3989	[1]	PISTON SHOE RETAINER ASSY.
	4I-9469	[1]	PISTON SHOE RETAINER ASSY.
176-177.	096-3990	[1]	DRUM ASSY.
	099-6342	[1]	DRUM ASSY.
	N		NOT SUPPLIED INDIVIDUALLY
