ROTATING GP-PUMP
295-9535 ROTATING GP-PUMP
S/N P5D1-UP; L5R1-UP
PART OF 295-9426 PUMP GP-PISTON |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
295-9540 |
[1] |
RETAINER-BALL |
|
| 2 |
194-9479 |
[3] |
PIN |
|
| 3 |
194-9481 |
[1] |
DISC-THRUST |
|
| 4 |
295-9536 |
[1] |
PLATE-VALVE |
|
| 5 |
194-9480 |
[1] |
RING-RETAINING |
|
| 6 |
295-9538 |
[1] |
BARREL |
|
| 7 |
295-9541 |
[1] |
SPRING |
|
| 8 |
295-9537 |
[9] |
PISTON AS |
|
| 9 |
295-9539 |
[1] |
RETAINER |
|
|
|
|
|
|
|
|
|
|
|
PUMP GP-MAIN HYDRAULIC
326-4424 PUMP GP-MAIN HYDRAULIC -WITH PILOT GEAR PUMP
S/N P5D1-UP; L5R1-UP
PART OF 296-4670 PUMP & MTG GP-MAIN HYDRAULIC |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
4M-0189 |
[1] |
SEAL-O-RING |
|
| 2 |
295-9426 Y |
[1] |
PUMP GP-PISTON |
|
| 3 |
295-9663 Y |
[1] |
PUMP GP-PISTON & GEAR (MAIN HYDRAULIC) |
|
| 4 |
108-1781 M |
[2] |
BOLT-SOCKET HEAD (M12X1.75X35-MM) |
|
|
M |
|
METRIC PART |
|
R |
|
REMANUFACTURED PART MAY BE AVAILABLE |
|
Y |
|
SEPARATE ILLUSTRATION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PUMP GP-PISTON
295-9426 PUMP GP-PISTON -MAIN HYDRAULIC
S/N P5D1-UP; L5R1-UP
PART OF 326-4424 PUMP GP-MAIN HYDRAULIC |
|
|
|
|
|
| CATERPILLAR SIS |
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
8T-9597 |
[1] |
RING-RETAINING |
|
| 2 |
185-0303 |
[1] |
SEAL-OIL |
|
| 3 |
155-9125 |
[1] |
BEARING AS-ROLLER |
|
| 4 |
279-3393 |
[1] |
SWASHPLATE |
|
| 5 |
259-5507 |
[1] |
ROD-PISTON |
|
| 6 |
168-7861 |
[1] |
PISTON-ACTUATOR |
|
| 7 |
295-9544 |
[1] |
PLUG AS |
|
| 8 |
191-7582 |
[1] |
SHIM (2.5-MM THK) |
|
| 9 |
9X-8979 |
[1] |
DOWEL |
|
| 10 |
191-7583 |
[1] |
BEARING-TAPERED |
|
| 11 |
9X-6032 M |
[4] |
BOLT-SOCKET HEAD (M10X1.5X30-MM) |
|
| 12 |
311-9540 |
[1] |
COVER |
|
| 13 |
231-4707 |
[1] |
SEAL-O-RING |
|
| 14 |
295-9546 |
[1] |
NUT (SPECIAL) |
|
| 15 |
095-1750 |
[2] |
SEAL-O-RING |
|
| 16 |
244-4468 M |
[1] |
NUT (M10X1-THD) |
|
| 17 |
295-9535 Y |
[1] |
ROTATING GP-PUMP |
|
| 18 |
295-9545 |
[1] |
ROD |
|
| 19 |
194-9474 |
[2] |
BEARING-CRADLE |
|
| 20 |
194-9473 |
[1] |
RING |
|
| 21 |
295-9542 |
[1] |
HOUSING |
|
| 22 |
191-7581 |
[1] |
SHAFT |
|
| 23 |
168-3504 |
[1] |
SEAL |
|
| 24 |
244-4120 Y |
[1] |
VALVE GP-PILOT |
|
| 25 |
120-4394 |
[1] |
PLUG-BREAK OFF |
|
|
M |
|
METRIC PART |
|
Y |
|
SEPARATE ILLUSTRATION |
