CASE CX130 EXCAVATOR LJ01072 HYDRAULIC PUMP PARTS

CASE CX130 EXCAVATOR LJ01072 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
LJ01072
Pos. Part No Qty Parts name Comments
1 LJ01069 [2]   PISTON
     Consists Of Ref. Numbers 2, 3
2 NSS [9]   NOT SOLD SEPARAT      Piston
3 NSS [9]   NOT SOLD SEPARAT      Shoe
4 LJ01070 [1]   VALVE BODY
     Consists Of Ref. Numbers 5, 6
5 NSS [1]   NOT SOLD SEPARAT      Block; Cylinder
6 NSS [1]   NOT SOLD SEPARAT      Plate
7 LJ01071 [1]   VALVE BODY
     Consists Of Ref. Numbers 8, 9
8 NSS [1]   NOT SOLD SEPARAT      Block; Cylinder
9 NSS [1]   NOT SOLD SEPARAT      Plate
10 TR00049 [2]   PLATE
     Consists Of Ref. Numbers 11, 12
11 NSS [1]   NOT SOLD SEPARAT      Plate
12 NSS [1]   NOT SOLD SEPARAT      Bush
13 TA00051 [2]   SPECIAL PIN
     Consists Of Ref. Numbers 14, 15
14 NSS [1]   NOT SOLD SEPARAT      Pin
15 NSS [1]   NOT SOLD SEPARAT      Pin
16 LB00884 [1]   SHAFT
17 LB00885 [1]   SHAFT
18 LC00228 [1]   GEAR
19 TB00032 [2]   BEARING, ROLLER, CYL,35mm ID x 80mm OD x 21mm
20 TB00031 [2]   NEEDLE BEARING,28 mm ID x 39 mm OD x 30 mm
21 TH00018 [4]   SPACER
22 TR00054 [2]   PLATE
23 TB00030 [2]   BUSHING
24 TG00027 [18]   SPRING
25 TR00053 [2]   PLATE
26 TS00009 [2]   HOLDER
27 TW00035 [1]   SEAL
28 TW00034 [2]   CASE
29 LS00232 [1]   BLOCK
30 TA00055 [8]   BOLT
31 861-6016 [4]   HEX SOC SCREW,M6 x 16mm, Cl 12.9      M6 x 16; 12.9
32 155496A1 [2]   PLUG
33 LK00004 [4]   PLUG
34 LK00008 [2]   PLUG
35 LK00003 [15]   PLUG
36 TJ00074 [2]   PISTON
37 TG00026 [2]   STOP
38 LG00008 [2]   STOP
39 154529A1 [2]   O-RING
40 154697A1 [1]   O-RING
41 154713A1 [1]   O-RING
42 154761A1 [2]   O-RING,119.4mm ID x 3.1mm Width
43 154753A1 [2]   O-RING,114.4mm ID x 3.1mm Width
44 154455A1 [18]   O-RING
45 154467A1 [2]   O-RING,10.8mm ID x 2.4mm Width
46 154475A1 [2]   O-RING
47 154487A1 [4]   O-RING
48 154483A1 [2]   O-RING
49 TE00042 [1]   OIL SEAL
50 153967A1 [2]   BACK-UP RING
51 LE00540 [2]   SCRAPER RING
52 829-1316 [4]   NUT,M16, Cl 10
53 800-1135 [2]   SNAP RING,M35, Ext
54 157018A1 [2]   COTTER PIN
55 338W060Z014B [4]   LINCH PIN
56 126R010SR [2]   EYEBOLT      BOLT, EYE
57 160295A1 [2]   SET SCREW
58 TV00002 [2]   SCREW
59 NSS [1]   NOT SOLD SEPARAT      Plate
60 NSS [2]   NOT SOLD SEPARAT      Rivet
192 LJ01072 [1]   HYDRAULIC PUMP
     See Page(s) 08-083L-00
