CASE CX130 EXCAVATOR LJ00855 SWING MOTOR ROTARY GROUP AND SPARE PARTS

CASE CX130 EXCAVATOR LJ00855 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
LJ00855
CX130
Pos. Part No Qty Parts name Comments
1 LJ00855 [1]   MOTOR, HYDRAULIC
     Consists Of Ref. Numbers 2-47
2 160941A1 [1]   SEALING RING
3 160780A1 [1]   OIL SEAL
4 160966A1 [1]   TAPERED BEARING,30mm ID x 62mm OD x 21.25mm W
5 KRC0172 [1]   DIPSTICK
6 160993A1 [1]   BACK-UP RING
7 160940A1 [1]   LARGE PLATE      PLATE, LARGE
8 160994A1 [1]   TRAY
9 LNM0553 [9]   PISTON
10 160996A1 [2]   BRAKE DISC      DISC, BRAKE
11 160995A1 [2]   DISC
12 161060A1 [1]   O-RING
13 160938A1 [1]   PISTON
14 161061A1 [2]   O-RING
15 156077A1 [16]   SPRING
16 LE00774 [2]   RING
17 LJ00722 [2]   PISTON
18 160306A1 [3]   CAP
19 154467A1 [3]   O-RING,10.8mm ID x 2.4mm Width
20 LG00336 [4]   SPRING
21 LE00775 [4]   RING
22 LB00543 [4]   BUSHING
23 LR00572 [1]   ACTUATING PLATE
24 160967A1 [1]   BEARING, NEEDLE,22 mm ID x 35 mm OD x 20 mm
25 160867A1 [1]   RING, SNAP      RING SNAP
26 NSS [1]   NOT SOLD SEPARAT      Block Assy
27 NSS [1]   NOT SOLD SEPARAT      Housing
28 151033A1 [1]   PLUG
29 LNM0426 [2]   VALVE POPPET
30 166176A1 [2]   BACK-UP RING
31 154487A1 [2]   O-RING
32 154471A1 [2]   O-RING
33 NSS [1]   NOT SOLD SEPARAT      Cover Sheet
34 160859A1 [2]   DOWEL
35 LJ01137 [2]   VALVE, PRESSURE RELI      EF
     Consists Of Ref. Numbers 36-41
36 LH00347 [1]   SHIM
37 LH00348 [1]   SHIM
38 LH00349 [1]   SHIM
39 LH00350 [1]   SHIM
40 153982A1 [1]   BACK-UP RING
41 LE01045 [1]   O-RING
42 LE01045 [2]   O-RING
43 108R014Z045B [4]   BOLT
44 155944A1 [2]   PLUNGER
45 156079A1 [2]   SPRING
46 156305A1 [2]   CAP
47 153991A1 [2]   BACK-UP RING
