CASE CX130 EXCAVATOR LJ00721 SWING MOTOR ROTARY GROUP

CASE CX130 EXCAVATOR LJ00721 SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
LJ00721
CX130
Pos. Part No Qty Parts name Comments
1 LJ00721 [1]   MOTOR, HYDRAULIC
     Consists Of Ref. Numbers 2-41
2 160941A1 [1]   SEALING RING
3 160780A1 [1]   OIL SEAL
4 160966A1 [1]   TAPERED BEARING,30mm ID x 62mm OD x 21.25mm W
5 KRC0172 [1]   DIPSTICK
6 160993A1 [1]   BACK-UP RING
7 160940A1 [1]   LARGE PLATE      PLATE, LARGE
8 160994A1 [1]   TRAY
9 NSS [9]   NOT SOLD SEPARAT      Piston
10 160996A1 [2]   BRAKE DISC      DISC, BRAKE
11 160995A1 [2]   DISC
12 161060A1 [1]   O-RING
13 160938A1 [1]   PISTON
14 161061A1 [2]   O-RING
15 156077A1 [14]   SPRING
16 LE00774 [2]   RING
17 LJ00722 [2]   PISTON
18 160306A1 [3]   CAP
19 154467A1 [3]   O-RING,10.8mm ID x 2.4mm Width
20 LG00336 [4]   SPRING
21 LE00775 [4]   RING
22 LB00543 [4]   BUSHING
23 LR00572 [1]   ACTUATING PLATE
24 160967A1 [1]   BEARING, NEEDLE,22 mm ID x 35 mm OD x 20 mm
25 160867A1 [1]   RING, SNAP      RING SNAP
26 NSS [1]   NOT SOLD SEPARAT      Block Assy
27 NSS [1]   NOT SOLD SEPARAT      Housing
28 151033A1 [1]   PLUG
29 LNM0426 [2]   VALVE POPPET
30 166176A1 [2]   BACK-UP RING
31 154487A1 [2]   O-RING
32 154471A1 [2]   O-RING
33 NSS [1]   NOT SOLD SEPARAT      Cover Sheet
34 160859A1 [2]   DOWEL
35
36 154515A1 [4]   O-RING
37 108R014Z045B [4]   BOLT
38 155944A1 [2]   PLUNGER
39 156079A1 [2]   SPRING
40 156305A1 [2]   CAP
41 153991A1 [2]   BACK-UP RING
