CASE CX130 EXCAVATOR KNJ2900 HYDRAULIC PUMP PARTS

CASE CX130 EXCAVATOR KNJ2900 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
KNJ2900 CX130
Pos. Part No Qty Parts name Comments
KNJ2900 [1]   PUMP, HYDRAULIC
     Consists Of Ref. Numbers 1 To 107, 160 To 162, 164 To 205
1 LU00089 [1]   ROTOR
     See Page(s) 08-081-00-01
28 LU00090 [1]   ROTOR
     See Page(s) 08-079-00-01
52 LW00318 [1]   COVER
     See Page(s) 08-077-00-01
62 LS00134 [1]   CONTROL BLOCK
     See Page(s) 08-075-00-01
70 LW00319 [1]   COVER
     See Page(s) 08-075-00-01
75 LJ00761 [2]   PILOT VALVE
84 LJ00762 [2]   PILOT VALVE
     See Page(s) 08-071-00-01
88 LJ00766 [1]   PUMP
     See Page(s) 08-073-00-01
107 LJ00763 [2]   REGULATOR
     See Page(s) 08-067-00-01
160 LT00100 [1]   HOUSING
161 LT00101 [1]   HOUSING
164 LA00715 [4]   SCREW,Hex Skt
165 162R010VN [4]   NUT
168 LBQ5164 [2]   O-RING
169 LK00118 [6]   PLUG
170 LA00716 [4]   DOWEL
191 LB00559 [1]   SPLINED COUPLING
198 LK00310 [1]   PLUG
200 LK00312 [1]   HYDRAULIC HOSE
201 LR00595 [1]   HYD TUBE
202 LK00313 [1]   TEE
203 LK00314 [1]   TEE
204 LLP0106 [3]   ELBOW
205 LK00315 [2]   ELBOW
206 NSS [1]   NOT SOLD SEPARAT
Parts on group :
Pos. Part No Qty Parts name Comments
KNJ2900 [1]   PUMP, HYDRAULIC
     Consists Of Ref. Numbers 160 To 162, 164 To 205
162 LA00714 [8]   SPECIAL PIN
166 LK00309 [8]   PLUG
167 863-16060 [8]   HEX SOC SCREW,M16 x 60mm, Cl 12.9
169 LK00118 [6]   PLUG
171 164915A1 [2]   ORIFICE
172 LJ00765 [1]   VALVE
     See Page(s) 08-065-00-01
192 LJ00767 [1]   VALVE, PRESSURE RELI      EF
     See Page(s) 08-065-00-01
199 LK00311 [1]   HYDRAULIC HOSE
204 LLP0106 [2]   ELBOW
205 LK00315 [1]   ELBOW
