Rexroth A6VM160 travel motor parts

Rexroth A6VM160 travel motor parts

$1,000.00 USD
$1,000.00 USD
特價 售罄
結帳時計算運費。
A6VM160
31Q6-41010 31Q6-41700 R210W-9 R210W-9A R210W9AMH R210W9-MH ROTARY GROUP XJDD-00109 XJDD-00121
31N6-45010 R200W-7 ROTARY GROUP ZGAR-00271 ZGAR-00282
31N6-45011 31N6-45012 R200W-7 R200W-7A R210W-9S ROTARY GROUP XJDD-00109 XJDD-00121
Pos. Part No Qty Parts name Comments
*. 31N6-45010 [1]   TRAVEL MOTOR      *-1,*-2,*-3
*-1. @ [1]   MOTOR UNIT
1 ZGAR-00271 [1]   ROTARY GROUP
1-1. ZGAR-00282 [1]   ROTARY-HYD SECTION
1-1-1. ZGAR-00297 [1]   CYLINDER
1-1-2. ZGAR-00298 [1]   CONTROL LENS
1-1-3. ZGAR-00299 [1]   PIN-CENTER
1-1-4. ZGAR-00311 [7]   PISTON
1-1-5. ZGAR-00312 [14]   RING-STEEL
1-1-6. ZGAR-00301 [1]   SHIM-ADJUSTMENT
1-1-7. ZGAR-00307 [1]   SPRING-PRESSURE
1-1-11. ZGAR-00309 [1]   PLATE-RETAINER
1-1-12. ZGAR-00310 [14]   SCREW
1-2. ZGAR-00283 [1]   SHAFT-DRIVE
1-3. ZGAR-00284 [1]   SHIM
1-6. ZGAR-00285 [1]   PLATE-BACK UP
1-7. ZGAR-00294 [1]   RING-RETAINING
1-10. ZGAR-00295 [1]   BEARING-ROLLER
1-11. ZGAR-00296 [1]   BEARING-ROLLER
5 ZGAR-00273 [1]   HOUSING
S8. ZGAR-00274 [1]   SCREW-LOCKING
9 ZGAR-00275 [1]   RING-RETAINING
K10. XJDD-00115 [1]   RING-SHAFT SEAL
11 ZGAR-00277 [1]   PLATE-BACK UP
K12. XJDD-00117 [1]   O-RING
S13. ZGAR-00279 [1]   SCREW-LOCKING
17 ZGAR-00280 [2]   PIN-THREADED
K18. XJDD-00120 [2]   NUT-SEAL LOCK
*-2. @ [1]   CONTROL ASSY      SEE 4150,60
*-3. @ [1]   COUNTER BALANCE VLV      SEE 4165
K. XJDD-00685 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR      SEE 4140
*-2. ZGAR-00272 [1]   CONTROL ASSY      SEE 4151
2 ZGAR-00314 [1]   COVER ASSY
2-1. ZGAR-00350 [1]   COVER
2-2. ZGAR-00351 [1]   SCREW-THROTTLE
2-10. ZGAR-00352 [4]   SCREW-SOCKET HEAD
K2-11. XJDD-00640 [1]   O-RING
S2-12. ZGAR-00343 [1]   SCREW-LOCKING
3 ZGAR-00315 [1]   PLATE-PORT
5 ZGAR-00317 [1]   TRUNNION-POSITIONING
7 ZGAR-00318 [1]   PISTON
8 ZGAR-00319 [1]   PIN-THREADED
15 ZGAR-00320 [8]   SCREW-SOCKET HEAD
K20. XJDD-00258 [3]   O-RING
23 ZGAR-00325 [1]   SCREW-SOCKET HEAD
24 ZGAR-00326 [3]   RING-SQUARE
26 ZGAR-00327 [2]   PIN-CYLINDER
28 ZGAR-00328 [1]   PIN-D/BREAK OFF
32 ZGAR-00330 [1]   PIN-D/BREAK OFF
K33. XJDD-00287 [1]   O-RING
S34. ZGAR-00332 [2]   SCREW-LOCKING
50 ZGAR-00333 [2]   RELIEF VALVE
*-1. @ [1]   MOTOR UNIT      SEE 4140
*-3. @ [1]   COUNTER BALANCE VLV      SEE 4165
K. XJDD-00685 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. 31N6-45011 [1]   TRAVEL MOTOR      *-1,*-2,*-3
*. 31N6-45012 [1]   TRAVEL MOTOR      *-1,*-2,*-3
*-1. @ [1]   MOTOR UNIT
1 XJDD-00109 [1]   ROTARY GROUP
1-1. XJDD-00121 [1]   ROTARY-HYD SECTION
1-1-1. XJDD-00140 [1]   CYLINDER
1-1-2. XJDD-00141 [1]   CONTROL LENS
1-1-3. XJDD-00142 [1]   PIN-CENTER
1-1-4. XJDD-00634 [7]   PISTON
1-1-6. XJDD-00144 [1]   SHIM(4.5T)-ADJUSTMENT
1-1-7. XJDD-00150 [1]   SPRING-PRESSURE
1-1-11. XJDD-00151 [1]   PLATE-RETAINER
1-1-12. XJDD-00635 [14]   SCREW
1-2. XJDD-00122 [1]   SHAFT-DRIVE
1-3. XJDD-00125 [1]   SHIM
1-6. XJDD-00128 [1]   PLATE-BACK UP
1-7. XJDD-00137 [1]   RING-RETAINING
1-10. XJDD-00138 [1]   BEARING-ROLLER
1-11. XJDD-00139 [1]   BEARING-ROLLER
5 XJDD-00636 [1]   HOUSING
8 XJDD-00308 [1]   SCREW-LOCKING
9 XJDD-00114 [1]   RING-RETAINING
K10. XJDD-00115 [1]   RING-SHAFT SEAL
11 XJDD-00116 [1]   PLATE-BACK UP
K12. XJDD-00117 [1]   O-RING
13 XJDD-00118 [1]   SCREW-LOCKING
17 XJDD-00111 [2]   PIN-THREADED
K18. XJDD-00120 [2]   NUT-SEAL LOCK
*-2. @ [1]   CONTROL ASSY      SEE 4151,61
*-3. @ [1]   COUNTER BALANCE VLV      SEE 4166
K. XJDD-00685 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR      SEE 4141
*-2. XJDD-00619 [1]   CONTROL ASSY      SEE 4150
2 XJDD-00637 [1]   COVER ASSY
2-1. XJDD-00638 [1]   COVER
2-2. XJDD-00601 [1]   SCREW-THROTTLE
2-10. XJDD-00639 [4]   SCREW-SOCKET HEAD
K2-11. XJDD-00640 [1]   0-RING
2-12. XJDD-00174 [1]   SCREW-LOCKING
3 XJDD-00641 [1]   PLATE-PORT
5 XJDD-00642 [1]   TRUNNION-POSITIONING
7 XJDD-00643 [1]   PISTON
8 XJDD-00644 [1]   PIN-THREADED
15 XJDD-00645 [8]   SCREW-SOCKET HEAD
K20. XJDD-00258 [3]   O-RING
23 XJDD-00646 [1]   SCREW-SOCKET HEAD
24 XJDD-00647 [3]   RING-SQUARE
26 XJDD-00648 [2]   PIN-CYLINDER
28 XJDD-00178 [1]   PIN-D/BREAK OFF
32 XJDD-00181 [1]   PIN-D/BREAK OFF
K33. XJDD-00287 [1]   O-RING
34 XJDD-00210 [2]   SCREW-LOCKING
50 XJDD-00622 [2]   RELIEF VALVE
*-1. @ [1]   MOTOR UNIT      SEE 4141
*-3. @ [1]   COUNTER BALANCE VLV      SEE 4165
K. XJDD-00685 [1]   SEAL KIT      SEE ILLUST
A6VM160 31Q6-41010 31Q6-41700
R210W-9 R210W-9A R210W9AMH R210W9-MH
Pos. Part No Qty Parts name Comments
*. 31Q6-41010 [1]   TRAVEL MOTOR      *-1,*-2
*. 31Q6-41700 [1]   TRAVEL MOTOR      *-1,*-2
*-1. XJDD-01037 [1]   MOTOR UNIT      INCL *-1-1, 4150
*-1. XJDD-01284 [1]   MOTOR UNIT      INCL *-1-1, 4151
1 XJDD-00109 [1]   ROTARY GROUP
1-1. XJDD-00121 [1]   ROTARY-HYD SECTION
1-1-1. XJDD-00140 [1]   CYLINDER
1-1-2. XJDD-00141 [1]   CONTROL LENS
1-1-3. XJDD-00142 [1]   PIN-CENTER
1-1-4. XJDD-00634 [7]   PISTON
1-1-6. XJDD-00144 [1]   SHIM(4.5T)-ADJUSTMENT
1-1-7. XJDD-00150 [1]   SPRING-PRESSURE
1-1-11. XJDD-01075 [1]   PLATE-RETAINING
1-1-12. XJDD-00635 [14]   SCREW
1-2. XJDD-00122 [1]   SHAFT-DRIVE
1-3. XJDD-00125 [1]   SHIM
1-6. XJDD-00128 [1]   PLATE(3.1T)-BACK UP
1-6. XJDD-00136 [1]   PLATE(3.15T)-BACK UP
1-6. XJDD-00129 [1]   PLATE(3.2T)-BACK UP
1-6. XJDD-00130 [1]   PLATE(3.25T)-BACK UP
1-6. XJDD-00131 [1]   PLATE(3.3T)-BACK UP
1-6. XJDD-00132 [1]   PLATE(3.35T)-BACK UP
1-6. XJDD-00133 [1]   PLATE(3.4T)-BACK UP
1-6. XJDD-00134 [1]   PLATE(3.45T)-BACK UP
1-6. XJDD-00135 [1]   PLATE(3.5T)-BACK UP
1-7. XJDD-00137 [1]   RING-RETAINING
1-10. XJDD-00138 [1]   BEARING-ROLLER
1-11. XJDD-00139 [1]   BEARING-ROLLER
5 XJDD-01086 [1]   HOUSING
8 XJDD-01010 [1]   SCREW-LOCKING
9 XJDD-00114 [1]   RING-RETAINING
K10. XJDD-00115 [1]   RING-SHAFT SEAL
11 XJDD-00116 [1]   PLATE-BACK UP
K12. XJDD-00117 [1]   O-RING
13 XJDD-01138 [1]   SCREW-LOCKING
17 XJDD-00111 [2]   PIN-THREADED
K18. XJDD-00120 [2]   NUT-SEAL LOCK
*-1-1. @ [1]   CONTROL ASSY      SEE 4150,51
*-3. @ [1]   COUNTER BALANCE VLV      SEE 4165
K. @ [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*-1-1. XJDD-01077 [1]   CONTROL
1 XJDD-00929 [1]   CONTROL PART
N1-1. XJDD-00944 [1]   HOUSING-CONTROL
1-2. XJDD-00265 [1]   BUSHING-CONTROL
1-3. XJDD-01014 [1]   PISTON-CONTROL
1-4. XJDD-00267 [1]   BUSHING-ADJUSTING
1-5. XJDD-00268 [1]   COLLAR-SPRING
1-7. XJDD-00269 [1]   SPRING-PRESSURE
1-9. XJDD-00270 [1]   SPRING-PRESSURE
K1-14. XJDD-00271 [1]   O-RING
1-15. XJDD-00272 [4]   BOLT-SOCKET
1-16. XJDD-00174 [2]   SCREW-LOCKING
1-17. XJDD-00273 [1]   RING-RETAINING
1-19. XJDD-00954 [1]   PIN-THREADED
1-20. XJDD-00275 [1]   PIN-CYLINDER
K1-21. XJDD-00276 [1]   NUT-SEAL LOCK
1-22. XJDD-00277 [2]   PIN-D/BREAK OFF
1-29. XJDD-00278 [1]   DISC-RETAINING
2 XJDD-01079 [1]   STROKE LIMIT-HYD
2-1. XJDD-01095 [1]   HOUSING
2-2. XJDD-01096 [1]   PISTON
2-3. XJDD-00281 [1]   PISTON-CONTROL
2-4. XJDD-00338 [1]   SPRING-PRESSURE
2-5. XJDD-00282 [1]   SCREW-LOCKING
2-6. XJDD-00963 [1]   SCREW-LOCKING
2-7. XJDD-01097 [4]   SCREW-SOCKET HEAD
K2-8. XJDD-00640 [1]   O-RING
2-9. XJDD-00966 [1]   SCREW-LOCKING
2-10. XJDD-00175 [2]   SCREW-LOCKING
2-11. XJDD-00286 [1]   ORIFICE
K2-12. XJDD-00287 [1]   O-RING
2-13. XJDD-01019 [1]   SHIM
2-14. XJDD-00277 [8]   PIN-D/BREAK OFF
2-15. XJDD-00971 [1]   PISTON
2-16. XJDD-00972 [1]   PISTON-CONTROL
2-17. XJDD-00973 [1]   SPRING-PRESSURE
K2-18. XJDD-00974 [1]   O-RING
2-19. XJDD-00975 [1]   SHIM
3 XJDD-01080 [1]   PLATE-PORT
N4. XJDD-00652 [1]   PISTON-POSITIONING
5 XJDD-00642 [1]   TRUNNION-POSITIONING
7 XJDD-01083 [1]   PISTON-W/PISTON RINGS
8 XJDD-00644 [1]   PIN-THREADED
10 XJDD-01085 [2]   GUIDE-VALVE
11 XJDD-00253 [2]   BOLT
12 XJDD-01088 [2]   SCREW-THROTTLE
13 XJDD-00254 [2]   BUSHING
15 XJDD-01089 [8]   SCREW-SOCKET HEAD
19 XJDD-00257 [2]   O-RING
K20. XJDD-00258 [10]   O-RING
K21. XJDD-00259 [2]   O-RING
K22. XJDD-00329 [2]   RING-BACK UP
23 XJDD-00646 [1]   SCREW-SOCKET HEAD
26 XJDD-00648 [2]   PIN-CYLINDER
28 XJDD-00178 [2]   PIN-D/BREAK OFF
32 XJDD-00181 [1]   PIN-D/BREAK OFF
K33. XJDD-00287 [1]   O-RING
34 XJDD-00210 [2]   SCREW-LOCKING
50 XJDD-00622 [2]   RELIEF VALVE
K. XJDD-01122 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
