Rexroth A6VM107 final drive travel motor rotary group

Rexroth A6VM107 final drive travel motor rotary group

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
A7VO107 R140W-7 R1400W-7A XJDD-
Pos. Part No Qty Parts name Comments
*. 31N4-45010 [1]   TRAVEL MOTOR
1 ZGAR-00399 [1]   ROTARY GROUP
1-1. ZGAR-00406 [1]   ROTARY-HYD SECTION
1-1-1. ZGAR-00421 [1]   CYLINDER
1-1-2. ZGAR-00422 [1]   CONTROL LENS
1-1-3. ZGAR-00423 [1]   CENTER PIN
1-1-4. ZGAR-00424 [7]   PISTON WITH P/RINGS
1-1-41. ZGAR-00434 [1]   PISTON
1-1-42. ZGAR-00435 [2]   SEALING RING-STEEL
1-1-6. ZGAR-00425 [1]   ADJUST SHIM
1-1-6. ZGAR-00426 [1]   ADJUST SHIM
1-1-6. ZGAR-00427 [1]   ADJUST SHIM
1-1-6. ZGAR-00428 [1]   ADJUST SHIM
1-1-6. ZGAR-00429 [1]   ADJUST SHIM
1-1-6. ZGAR-00430 [1]   ADJUST SHIM
1-1-7. ZGAR-00431 [1]   SPRING-PRESSURE
1-1-11. ZGAR-00432 [1]   RETAINING PLATE
1-1-12. ZGAR-00433 [14]   SCREW
1-2. ZGAR-00407 [1]   SHAFT-DRIVE
1-3. ZGAR-00408 [1]   SHIM
1-6. ZGAR-00409 [1]   PLATE-BACK UP
1-6. ZGAR-00410 [1]   PLATE-BACK UP
1-6. ZGAR-00411 [1]   PLATE-BACK UP
1-6. ZGAR-00412 [1]   PLATE-BACK UP
1-6. ZGAR-00413 [1]   PLATE-BACK UP
1-6. ZGAR-00414 [1]   PLATE-BACK UP
1-6. ZGAR-00415 [1]   PLATE-BACK UP
1-6. ZGAR-00416 [1]   PLATE-BACK UP
1-6. ZGAR-00417 [1]   PLATE-BACK UP
1-7. ZGAR-00418 [1]   RING-RETAINING
1-10. ZGAR-00419 [1]   BEARING-ROLLER
1-11. ZGAR-00420 [1]   BEARING-ROLLER
5 ZGAR-00401 [1]   HOUSING
8 ZGAR-00332 [1]   SCREW-LOCKING
9 ZGAR-00402 [1]   RING-RETAINING
K10. XJDD-00212 [AR]   SEAL RING-SHAFT
11 ZGAR-00404 [1]   PLATE-BACK UP
K12. XJDD-00214 [AR]   O-RING
13 ZGAR-00332 [1]   SCREW-LOCKING
17 ZGAR-00280 [2]   PIN-THREADED
K18. XJDD-00120 [AR]   NUT-SEAL LOCK
*-1. @ [1]   CONTROL      SEE 4150
*-2. @ [1]   COUNTER BALANCE VLV      SEE 4160
K. XJDD-00683 [1]   SEAL KIT      SEE ILLUST
00683
