| P7F00450 D61EX-15E0 D61PX,-15E0 D65EX-15 D65EX-16 D65EX-17 D65PX-15 D65PX-16 D65PX-17 D65WX-15 D65WX-16 D85EX-15 D85MS-15 D85PX-15(E0) D375A-6 D475A-5(A) D475ASD-5E0 GD755-5R WA380-5 WA380-6 WA380-7 WA430-6 WA470-6 WA470-7 WA480-6 |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1S-00240 |
[1] |
Pump Assembly Komatsu
|
26.322 kg. |
|
["SN: 11609-UP"] analogs:["7081S00241"] |$0. |
| |
708-1S-01930 |
[1] |
Pump Subassembly Komatsu China
|
|
|
["SN: 11609-UP"] |$1. |
| 1 |
708-1S-12320 |
[1] |
Shaft Komatsu China
|
|
|
["SN: 11609-UP", "SCC: C2"] |
| 2 |
708-1S-12260 |
[1] |
Bearing Komatsu
|
0.12 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 3 |
706-73-40890 |
[1] |
Bearing Komatsu
|
0.26 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["7088E12141"] |
| 4 |
708-7T-05020 |
[1] |
Spacer Kit Komatsu
|
0.01 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 5 |
708-1S-12280 |
[1] |
Ring, Wear Komatsu
|
0.001 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 6 |
708-1S-12330 |
[1] |
Retainer Komatsu
|
0.01 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 7 |
708-1S-12340 |
[1] |
Case Komatsu
|
0.18 kg. |
|
["SN: 11609-UP"] |
| 8 |
708-1T-11880 |
[1] |
Seal, Oil Komatsu
|
0.03 kg. |
|
["SN: 11609-UP"] |
| 9 |
207-09-11140 |
[1] |
O-ring Komatsu
|
0.002 kg. |
|
["SN: 11609-UP"] |
| 10 |
04065-06220 |
[1] |
Ring, Snap Komatsu
|
0.013 kg. |
|
["SN: 11609-UP"] |
| 11 |
708-1S-13130 |
[1] |
Block, Cylinder Komatsu
|
1.53 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["R7081S13130"] |
| 12 |
708-1S-13460 |
[1] |
Plate, Valve Komatsu
|
0.2 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 13 |
708-3S-13160 |
[2] |
Washer Komatsu China
|
|
|
["SN: 11609-UP", "SCC: C2"] |
| 14 |
708-3S-13430 |
[1] |
Spring Komatsu
|
0.07 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 15 |
04065-03515 |
[1] |
Ring, Snap Komatsu
|
0.003 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 16 |
708-1S-13370 |
[1] |
Guide, Retainer Komatsu
|
0.045 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["7083S13370", "R7081S13370"] |
| 17 |
708-1S-13380 |
[3] |
Pin Komatsu
|
0.06 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
| 18 |
708-1S-13360 |
[1] |
Retainer, Shoe Komatsu
|
0.18 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["R7081S13360"] |
| 19 |
708-1S-13320 |
[7] |
Piston Subassembly Komatsu
|
0.09 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["R7081S13320"] |
| 20 |
708-1S-14210 |
[1] |
Plug Komatsu China
|
|
|
["SN: 11609-UP", "SCC: C2"] |
| 21 |
708-1S-14220 |
[1] |
Plug Komatsu China
|
|
|
["SN: 11609-UP", "SCC: C2"] |
| 22 |
07002-11223 |
[2] |
O-ring Komatsu China
|
0.001 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["0700201223"] |
| 23 |
708-1S-14230 |
[1] |
Piston Subassembly Komatsu
|
0.087 kg. |
|
["SN: 11609-UP", "SCC: C2"] analogs:["7083S14250"] |
| 24 |
708-1S-14241 |
[1] |
Spring Komatsu
|
0.01 kg. |
|
["SN: 11609-UP", "SCC: C2"] |
