LPV30-CR hydraulic pump filter 708-2L-25480

LPV30-CR hydraulic pump filter 708-2L-25480

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。

PC30MRX-1 PC30MR-1 PC30UU-3 PC30-8 PC40-8

PC30R-8 PC35R-8 PC40R-8 PC45R-8 PC58SF-1
D155AX-5/6
D155A-6 D155AX-5 D155AX-6 D275A-5(D) D275AX-5 WA500-6(R) WA6006(R) WD600
708-1T-00470 708-1S-00150 708-1S-01131

Pos. Part No Qty Parts name Comments
     708-1T-00440   [1]   PUMP ASS'Y Komatsu 26.901 kg.
  ["SN: 76001-UP"]
        708-1T-01410   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 76001-UP"]
1   708-1T-12410   [1]   SHAFT Komatsu China
  ["SN: 76001-UP"]
2   706-73-40890   [1]   BEARING Komatsu 0.26 kg.
  ["SN: 76001-UP"] analogs:["7088E12141"]
3   708-1T-12420   [1]   BEARING Komatsu 0.26 kg.
  ["SN: 76001-UP"]
4   708-7T-05010   [1]   SPACER KIT Komatsu 0.052 kg.
  ["SN: 76001-UP"]
5   708-1S-12280   [1]   RING,WIRE Komatsu 0.001 kg.
  ["SN: 76001-UP"]
6   708-1S-12330   [1]   RETAINER Komatsu 0.01 kg.
  ["SN: 76001-UP"]
7   708-1S-12340   [1]   CASE Komatsu 0.18 kg.
  ["SN: 76001-UP"]
8   708-1T-11880   [1]   SEAL,OIL Komatsu 0.03 kg.
  ["SN: 76001-UP"]
9   207-09-11140   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 76001-UP"]
10   04065-06220   [1]   RING Komatsu 0.013 kg.
  ["SN: 76001-UP"]
11   708-1T-13510   [1]   BLOCK,CYLINDER Komatsu 2.2 kg.
  ["SN: 76001-UP"]
12   708-1T-13520   [1]   PLATE,VALVE Komatsu 0.2 kg.
  ["SN: 76001-UP"]
13   708-3S-13160   [2]   WASHER Komatsu China
  ["SN: 76001-UP"]
14   708-3S-13150   [1]   SPRING Komatsu 0.15 kg.
  ["SN: 76001-UP"]
15   04065-03515   [1]   RING,SNAP Komatsu 0.003 kg.
  ["SN: 76001-UP"]
16   708-1T-13540   [1]   GUIDE,RETAINER Komatsu 0.05 kg.
  ["SN: 76001-UP"]
17   708-1S-13380   [3]   PIN Komatsu 0.06 kg.
  ["SN: 76001-UP"]
18   708-1T-13550   [1]   RETAINER,SHOE Komatsu 0.2 kg.
  ["SN: 76001-UP"]
19   708-1T-13310   [7]   PISTON SUB ASS'Y Komatsu 0.12 kg.
  ["SN: 76001-UP"]
20   708-1S-14210   [1]   PLUG Komatsu China
  ["SN: 76001-UP"]
21   708-1S-14220   [1]   PLUG Komatsu China
  ["SN: 76001-UP"]
22   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 76001-UP"] analogs:["0700201223"]
23   708-1S-14230   [1]   PISTON SUB ASS'Y Komatsu 0.087 kg.
  ["SN: 76001-UP"] analogs:["7083S14250"]
24   708-1S-14241   [1]   SPRING Komatsu 0.01 kg.
  ["SN: 76001-UP"]
