KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 708-2G-00180 708-2G-01180 HYDRAULIC PUMP ROTARY GROUP

KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 708-2G-00180 708-2G-01180 HYDRAULIC PUMP ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-2G-00180 708-2G-01180
PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
     708-2G-04740   [1]   Case Assembly,Front Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$2.
3   708-8E-16150   [2]   Plug Komatsu 0.02 kg.
  ["SN: 80001-UP"]
4   07002-61023   [2]   O-ring Komatsu 0.22 kg.
  ["SN: 80001-UP"] analogs:["7082L23920"]
5   708-1L-29340   [2]   Orifice Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
6   04530-11222   [1]   Bolt, Eye Komatsu 0.122 kg.
  ["SN: 80001-UP"]
7   07044-12412   [1]   Plug Komatsu 0.09 kg.
  ["SN: 80001-UP"] analogs:["0704402412", "R0704412412"]
8   07002-62434   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7081W28910"]
9   07040-12414   [1]   Plug Komatsu 0.092 kg.
  ["SN: 80001-UP"] analogs:["0704002412", "0704012412"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
     708-2G-04680   [1]   Cap Assembly,End Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$2.
3   708-2G-12151   [2]   Bearing Komatsu 0.21 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   07000-A5185   [2]   O-ring Komatsu OEM 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   04020-01434   [2]   Pin, Dowel Komatsu 0.044 kg.
  ["SN: 80001-UP", "SCC: C2"]
6   07000-B2012   [7]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   01010-61655   [12]   Bolt Komatsu 0.119 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["801015613", "0101031655", "0101051655", "0101081655"]
8   01643-51645   [12]   Washer Komatsu 0.021 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   07000-B2014   [4]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
10   708-2L-25480   [4]   Filter Komatsu OEM 0.5 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-8E-16150   [3]   Plug Komatsu 0.02 kg.
  ["SN: 80001-UP"]
12   07002-61023   [3]   O-ring Komatsu 0.22 kg.
  ["SN: 80001-UP"] analogs:["7082L23920"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
1   708-2G-12640   [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   708-2G-12252   [1]   Bearing Komatsu China 0.875 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7082G12251"]
3   708-2G-05010   [1]   Washer Kit Komatsu 0.75 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   708-1F-12270   [1]   Ring, Snap Komatsu 0.014 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   708-2G-12230   [1]   Seal, Oil Komatsu 0.000 kg.
  ["SN: 80001-UP"]
6   708-8H-32160   [1]   Spacer Komatsu 0.05 kg.
  ["SN: 80001-UP"]
7   04065-07825   [1]   Ring, Snap Komatsu 0.022 kg.
  ["SN: 80001-UP"]
     708-2G-04710   [1]   Cylinder Block Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$12.
10   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   04065-05520   [1]   Ring, Snap Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-2G-13131   [1]   Seat Komatsu 0.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   708-2G-13152   [1]   Spring Komatsu 0.2 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-2G-13141   [1]   Seat Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
15   708-2G-13510   [1]   Guide, Retainer Komatsu OEM 0.21 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   708-2H-23360   [3]   Pin Komatsu 0.006 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   708-2G-13341   [1]   Retainer, Shoe Komatsu OEM 0.39 kg.
  ["SN: 80001-UP", "SCC: C2"]
18   708-2G-13810   [9]   Piston Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
     708-2G-04670   [1]   Cradle Subassembly Komatsu 0.000 kg.
  ["SN: 80001-UP", "SCC: C2"] |$24.
21   04020-01434   [1]   Pin, Dowel Komatsu 0.044 kg.
  ["SN: 80001-UP", "SCC: C2"]
22   07000-B1009   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7082L23910"]
23   01252-61230   [6]   Bolt, Hexagon Socket Head Komatsu 0.044 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
1   708-2G-14120   [1]   Slider Komatsu 0.365 kg.
  ["SN: 80001-UP", "SCC: C2"]
1   708-2G-03640   [1]   Valve Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
1   708-2G-03650   [1]   Piston Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
6   708-2L-35760   [1]   Ball Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   708-2L-35770   [1]   Plug Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   708-2L-35170   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
10   708-2G-15211   [1]   Spool Komatsu 0.03 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-2G-15290   [1]   Retainer Komatsu 0.05 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-2G-15140   [1]   Seat Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   708-2G-15270   [1]   Spring Komatsu 2.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-2G-15280   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
15   708-2G-15151   [1]   Seat Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   708-2G-15250   [1]   Spring Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
18   07000-B3038   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
19   708-2G-15230   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
21   708-2G-15240   [1]   Plug Komatsu 0.08 kg.
  ["SN: 80001-UP", "SCC: C2"]
22   07000-B2012   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   07000-B2050   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   708-2G-15310   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
25   708-2G-14190   [1]   Cover Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
26   01580-10806   [1]   Nut Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["801920104"]
27   708-2L-35290   [1]   Nut Komatsu 0.12 kg.
  ["SN: 80001-UP", "SCC: C2"]
28   708-2G-15330   [1]   Ring, Wear Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"]
29   01252-61645   [4]   Bolt, Hexagon Socket Head Komatsu 0.119 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
1   708-2G-12650   [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   708-2G-12252   [1]   Bearing Komatsu China 0.875 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7082G12251"]
3   708-2G-05010   [1]   Washer Kit Komatsu 0.75 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   708-1F-12270   [1]   Ring, Snap Komatsu 0.014 kg.
  ["SN: 80001-UP", "SCC: C2"]
     708-2G-04720   [1]   Block Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$9.
7   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
8   04065-05520   [1]   Ring, Snap Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   708-2G-13131   [1]   Seat Komatsu 0.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
10   708-2G-13152   [1]   Spring Komatsu 0.2 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-2G-13141   [1]   Seat Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-2G-13510   [1]   Guide, Retainer Komatsu OEM 0.21 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   708-2H-23360   [3]   Pin Komatsu 0.006 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-2G-13341   [1]   Retainer, Shoe Komatsu OEM 0.39 kg.
  ["SN: 80001-UP", "SCC: C2"]
15   708-2G-13810   [9]   Piston Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
     708-2G-04670   [1]   Cradle Subassembly Komatsu 0.000 kg.
  ["SN: 80001-UP", "SCC: C2"] |$21.
18   04020-01434   [1]   Pin, Dowel Komatsu 0.044 kg.
  ["SN: 80001-UP", "SCC: C2"]
19   07000-B1009   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["7082L23910"]
20   01252-61230   [6]   Bolt, Hexagon Socket Head Komatsu 0.044 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-01180   [1]   Pump Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$1.
1   708-2G-14120   [1]   Slider Komatsu 0.365 kg.
  ["SN: 80001-UP", "SCC: C2"]
1   708-2G-03640   [1]   Valve Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
1   708-2G-03650   [1]   Piston Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
6   708-2L-35760   [1]   Ball Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   708-2L-35770   [1]   Plug Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"]
9   708-2L-35170   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
10   708-2G-15211   [1]   Spool Komatsu 0.03 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-2G-15290   [1]   Retainer Komatsu 0.05 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-2G-15140   [1]   Seat Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   708-2G-15270   [1]   Spring Komatsu 2.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
14   708-2G-15280   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
15   708-2G-15151   [1]   Seat Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   708-2G-15250   [1]   Spring Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
18   07000-B3038   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
19   708-2G-15230   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
21   708-2G-15240   [1]   Plug Komatsu 0.08 kg.
  ["SN: 80001-UP", "SCC: C2"]
22   07000-B2012   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   07000-B2050   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   708-2G-15310   [1]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
25   708-2G-14190   [1]   Cover Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
26   01580-10806   [1]   Nut Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["801920104"]
27   708-2L-35290   [1]   Nut Komatsu 0.12 kg.
  ["SN: 80001-UP", "SCC: C2"]
28   708-2G-15330   [1]   Ring, Wear Komatsu 0.005 kg.
  ["SN: 80001-UP", "SCC: C2"]
29   01252-61645   [4]   Bolt, Hexagon Socket Head Komatsu 0.119 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-2G-03720   [1]   Valve Assembly Komatsu China
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2G-00180   [1]   Pump Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
   1.   702-21-62200   [1]   Valve, Pilot Komatsu China
  ["SN: 80001-UP"]
2   720-1L-15440   [1]   O-ring Komatsu China
  ["SN: 80001-UP"]
3   720-1L-15430   [1]   O-ring Komatsu China
  ["SN: 80001-UP"] analogs:["7291111170", "7291121140", "7291121000", "7291121120", "7291111110", "7291121130", "7291121160", "7291121110", "7291111160", "7291121100"]
4   702-21-54180   [2]   Screw Komatsu China
  ["SN: 80001-UP"]
5   702-16-58320   [2]   O-ring Komatsu China
  ["SN: 80001-UP"]
   6.   01252-60635   [2]   Bolt, Hexagon Socket Head Komatsu 0.011 kg.
  ["SN: 80001-UP"]
   7.   20Y-62-22790   [1]   Band, Red Komatsu 0.001 kg.
  ["SN: 80001-UP"]
   8.   702-21-62900   [1]   Valve, Pilot Komatsu China
  ["SN: 80001-UP"]
   14.   20Y-62-22830   [1]   Band, White Komatsu 0.001 kg.
  ["SN: 80001-UP"]
   15.   708-2G-15680   [2]   Plug Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
   16.   07000-B1008   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
   17.   07001-01008   [4]   Ring, Back-up Komatsu 0.001 kg.
  ["SN: 80001-UP"]
   18.   07002-61423   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23950"]
   19.   01643-31232   [3]   Washer Komatsu 0.027 kg.
  ["SN: 80001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
   20.   01010-81220   [2]   Bolt Komatsu 0.032 kg.
  ["SN: 80001-UP"] analogs:["0101051220"]
   21.   08193-21012   [2]   Clip Komatsu 0.011 kg.
  ["SN: 80001-UP"]
   22.   708-2G-19130   [1]   Spacer Komatsu China
  ["SN: 80001-UP"]
   23.   01010-81235   [1]   Bolt Komatsu 0.048 kg.
  ["SN: 80001-UP"] analogs:["0101051235", "01010E1235", "801015136"]
   24.   04434-50612   [1]   Clip Komatsu 0.01 kg.
  ["SN: 80001-UP"]

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
