KOMATSU PC200-8 / PC200LC-8 PC200-8M0 PC200LC-8M0 PC200LL-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-8M0 PC220LC-8M0 PC230NHD-8K PC240LC-8K PC240NLC-8K EXCAVATOR 706-7G-01170 706-7G-01210 706-7G-03130 706-7G-03170 SWING MOTOR ROTARY GROUP

KOMATSU PC200-8 / PC200LC-8 PC200-8M0 PC200LC-8M0 PC200LL-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-8M0 PC220LC-8M0 PC230NHD-8K PC240LC-8K PC240NLC-8K EXCAVATOR 706-7G-01170 706-7G-01210 706-7G-03130 706-7G-03170 SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-7G-01170 706-7G-01210 706-7G-03130 706-7G-03170 PC200-8 / PC200LC-8 PC200-8M0 PC200LC-8M0 PC200LL-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-8M0 PC220LC-8M0 PC230NHD-8K PC240LC-8K PC240NLC-8K
Pos. Part No Qty Parts name Comments
     706-7G-01210   [1]   MOTOR ASSEMBLY Komatsu China
  ["SN: K53945-UP"] |1.
     706-7G-01170   [1]   MOTOR ASSEMBLY Komatsu 53 kg.
  ["SN: K51121-K53944"] |1.
        706-7G-03170   [1]   MOTOR SUBASSEMBLY Komatsu China
  ["SN: K53945-UP"] |1.
        706-7G-03130   [1]   MOTOR SUBASSEMBLY Komatsu China
  ["SN: K51121-K53944"] |1.
1   706-7G-41240   [1]   CASE Komatsu China
  ["SN: K51121-UP"]
2   706-7G-71180   [1]   HOUSING Komatsu China
  ["SN: K51121-UP"]
3   706-7G-40110   [1]   BUSHING Komatsu China
  ["SN: K51121-UP"]
4   708-8K-15190   [1]   PIN, DOWEL Komatsu China
  ["SN: K51121-UP"]
5   709-25-11650   [2]   VALVE, CHECK Komatsu 0.02 kg.
  ["SN: K51121-UP"]
6   709-25-11361   [2]   SPRING Komatsu 0.005 kg.
  ["SN: K51121-UP"]
7   709-25-11640   [2]   PLUG Komatsu 0.157 kg.
  ["SN: K51121-UP"]
8   07000-B2020   [2]   O-RING Komatsu China
  ["SN: K53945-UP"]
     07000-12020   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K51121-K53944"] |8.
9   708-21-12541   [3]   PLUG Komatsu China
  ["SN: K51121-UP"] analogs:["7068651180"]
10   708-8F-31620   [1]   PLUG Komatsu China
  ["SN: K51121-UP"]
11   706-7G-71710   [2]   VALVE Komatsu 0.1 kg.
  ["SN: K51121-UP"]
12   706-7G-71560   [2]   SPRING Komatsu 0.05 kg.
  ["SN: K51121-UP"]
13   706-7G-71630   [2]   PLUG Komatsu China
  ["SN: K51121-UP"]
14   07002-63334   [2]   O-RING Komatsu 1.46 kg.
  ["SN: K53945-UP"]
     07002-13334   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: K51121-K53944"] analogs:["0700203334"] |14.
15   706-7G-40210   [1]   O-RING Komatsu China
  ["SN: K53945-UP"]
     706-75-42370   [1]   O-RING Komatsu 0.012 kg.
  ["SN: K51121-K53944"] |15.
16   01010-61450   [6]   BOLT Komatsu 0.085 kg.
  ["SN: K51121-UP"] analogs:["0101031450", "0101051450", "0101081450"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7G-01210   [1]   MOTOR ASSEMBLY Komatsu China
  ["SN: K53945-UP"] |1.
     706-7G-01170   [1]   MOTOR ASSEMBLY Komatsu 53 kg.
  ["SN: K51121-K53944"] |1.
        706-7G-03170   [1]   MOTOR SUBASSEMBLY Komatsu China
  ["SN: K53945-UP"] |1.
        706-7G-03130   [1]   MOTOR SUBASSEMBLY Komatsu China
  ["SN: K51121-K53944"] |1.
1   706-7G-41630   [1]   SHAFT, DRIVE Komatsu 3 kg.
  ["SN: K51121-UP"]
2   706-75-42880   [1]   BEARING Komatsu 2.42 kg.
  ["SN: K51121-UP"]
3   706-7G-41660   [1]   SPACER Komatsu China
  ["SN: K51121-UP"]
4   706-7G-40890   [1]   BEARING Komatsu China
  ["SN: K51121-UP"]
5   706-7G-41510   [1]   SPACER KIT Komatsu China
  ["SN: K51121-UP"]
6   04064-04518   [1]   RING, SNAP Komatsu China 0.007 kg.
  ["SN: K51121-UP"] analogs:["20Y3029190"]
7   706-75-43410   [1]   SEAL, OIL Komatsu 0.15 kg.
  ["SN: K53945-UP"]
     706-7E-11280   [1]   SEAL, OIL Komatsu 0.15 kg.
  ["SN: K51121-K53944"] |7.
8   706-7G-41910   [1]   SPACER Komatsu 0.042 kg.
  ["SN: K51121-UP"]
9   04065-06220   [1]   RING, SNAP Komatsu 0.013 kg.
  ["SN: K51121-UP"]
10 706-7G-41310 [1]   BLOCK, CYLINDER Komatsu 2.3 kg.
  ["SN: K51121-UP"]
11   706-7G-41720   [1]   PLATE, VALVE Komatsu 0.38 kg.
  ["SN: K51121-UP"]
12   706-75-43750   [1]   PIN, DOWEL Komatsu China
  ["SN: K51121-UP"]
13   706-7G-41320   [1]   SHAFT, CENTRE Komatsu China
  ["SN: K51121-UP"]
14   706-7G-41130   [1]   RING, CENTRE Komatsu China
  ["SN: K51121-UP"]
15   706-7G-41140   [1]   SPRING Komatsu 0.06 kg.
  ["SN: K51121-UP"]
     706-7G-05010   [1]   RETAINER KIT Komatsu 0.22 kg.
  ["SN: K51121-UP"] |16.
18   706-7G-41410   [7]   PISTON SUBASSEMBLY Komatsu 0.000 kg.
  ["SN: K51121-UP"]
19   706-7G-91441   [5]   PLATE Komatsu 0.11 kg.
  ["SN: K51121-UP"]
20   706-7G-91450   [4]   DISC Komatsu 0.08 kg.
  ["SN: K51121-UP"]
21   706-7G-91120   [1]   PISTON, BRAKE Komatsu China
  ["SN: K51121-UP"]
22   708-1W-49170   [1]   O-RING Komatsu China
  ["SN: K53945-UP"]
     706-75-92310   [1]   O-RING Komatsu 0.012 kg.
  ["SN: K51121-K53944"] |22.
23   706-7G-91520   [1]   O-RING Komatsu China
  ["SN: K53945-UP"]
     708-8F-31610   [1]   O-RING Komatsu OEM 0.006 kg.
  ["SN: K51121-K53944"] |23.
24   706-7G-91360   [6]   SPRING Komatsu China
  ["SN: K51121-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7G-01210   [1]   MOTOR ASSEMBLY Komatsu China
  ["SN: K53945-UP"] |1.
     706-7G-01170   [1]   MOTOR ASSEMBLY Komatsu 53 kg.
  ["SN: K51121-K53944"] |1.
        702-75-01310   [1]   VALVE, RELIEF Komatsu 1.92 kg.
  ["SN: K51121-UP"] |1.
11   07000-F2020   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K51121-UP"] analogs:["0700022020"]
12   07001-02020   [1]   RING, BACK-UP Komatsu 0.001 kg.
  ["SN: K51121-UP"]
13   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: K51121-UP"] analogs:["0700203034"]
        702-15-77000   [1]   VALVE ASSEMBLY Komatsu 1.17 kg.
  ["SN: K51121-UP"] |14.
16   709-70-71610   [2]   SEAL Komatsu China
  ["SN: K51121-UP"]
17   702-15-71130   [2]   SPRING Komatsu 0.005 kg.
  ["SN: K51121-UP"]
18   702-15-71140   [2]   PLUG Komatsu China
  ["SN: K51121-UP"]
19   07002-01423   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: K51121-UP"] analogs:["0700211423"]
   20.   07000-B3042   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K53945-UP"]
        07000-13042   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: K51121-K53944"] analogs:["0700003042"] |20.
   21.   07000-B1009   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: K53945-UP"] analogs:["7082L23910"]
        07000-11009   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K51121-K53944"] analogs:["0700001009"] |21.
   22.   01252-60825   [2]   BOLT Komatsu 0.017 kg.
  ["SN: K51121-UP"] analogs:["0125240825", "0125230825"]
