KOMATSU PC120-6 PC120-6E0-T2 PC120-6Z PF3-1 PF3W-1 PW130-6K PW130-7K PW130ES-6K PW150ES-6K EXCAVATOR 202-966-4911  TZ504S200000-A TZ504S200002-A SWING MOTOR ROTARY GROUP

KOMATSU PC120-6 PC120-6E0-T2 PC120-6Z PF3-1 PF3W-1 PW130-6K PW130-7K PW130ES-6K PW150ES-6K EXCAVATOR 202-966-4911  TZ504S200000-A TZ504S200002-A SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
202-966-4911  TZ504S200000-A
TZ504S200002-A
PC120-6 PC120-6E0-T2 PC120-6Z PF3-1 PF3W-1 PW130-6K PW130-7K PW130ES-6K PW150ES-6K
Pos. Part No Qty Parts name Comments
     202-966-4911   [1]   MOTOR ASS'Y,SWING (TZ504S000002-A) Komatsu China
  ["SN: K30001-UP"] analogs:["RM2029664911", "2029664910"] |1.
        TZ504S200002-A   [1]   MOTOR ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
        TZ504S200000-A   [1]   MOTOR ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
     TZ501S2101-02   [1]   REAR FLANGE KIT Komatsu China
  ["SN: K30001-UP"] |1.
1   TZ501S2001-02   [1]   FLANGE Komatsu China
  ["SN: K30001-UP"]
2   TZ501S2033-00   [1]   ORIFICE Komatsu China
  ["SN: K30001-UP"] analogs:["TZ501S20330"]
3   TZMB700-060   [9]   PLUG Komatsu 0.01 kg.
  ["SN: K30001-UP"]
4   TZ850A0006-00   [1]   PLATE¤ NAME Komatsu 0.01 kg.
  ["SN: K30001-UP"]
5   TZ504S2002-00   [1]   CASE Komatsu China
  ["SN: K30001-UP"]
6   TZ550A200300-A   [1]   PLATE,SWASH Komatsu China
  ["SN: K30001-UP"]
7   TZ550A2004-00   [1]   BLOCK,CYLINDER Komatsu 0.8 kg.
  ["SN: K30001-UP"]
     TZ550A2105-00   [1]   PISTON SHOE ASS'Y Komatsu China
  ["SN: K30001-UP"] analogs:["TZ550A200500"] |8.
10   TZ550A2007-00   [1]   PLATE Komatsu China
  ["SN: K30001-UP"] analogs:["R550A20070", "TZ550A20070"]
11   TZ300A2008-00   [1]   BALL,THRUST Komatsu China
  ["SN: K30001-UP"] analogs:["R300A20080"]
12   TZ550A2009-00   [1]   PLATE,TIMING Komatsu 0.01 kg.
  ["SN: K30001-UP"]
13   TZ310B2010-00   [2]   WASHER Komatsu 0.01 kg.
  ["SN: K30001-UP"]
14   TZ550A2011-00   [1]   WASHER KIT Komatsu 0.171 kg.
  ["SN: K30001-UP"]
15   TZ510B2014-00   [1]   SPRING Komatsu 0.044 kg.
  ["SN: K30001-UP"] analogs:["TZ550A201401"]
16   TZ300A2017-00   [1]   PIN Komatsu China
  ["SN: K30001-UP"] analogs:["R300A20170"]
17   TZ501S2018-01   [1]   SHAFT Komatsu China
  ["SN: K30001-UP"]
18   TZ503S2019-00   [1]   GAUGE,OIL Komatsu China
  ["SN: K30001-UP"]
19   06000-06203   [1]   BEARING,BALL Komatsu 0.078 kg.
  ["SN: K30001-UP"]
20   06000-06001   [1]   BEARING,BALL Komatsu 0.024 kg.
  ["SN: K30001-UP"]
21   TZ15Z-17-35-8   [1]   SEAL,OIL (KIT) Komatsu 0.012 kg.
  ["SN: K30001-UP"] analogs:["TZ01703508"]
22   TZIRTW-32   [1]   RING,SNAP Komatsu 0.01 kg.
  ["SN: K30001-UP"]
23   TZJB1354-4-10   [2]   PIN Komatsu 0.01 kg.
  ["SN: K30001-UP"]
24   TZJB15062-118F   [3]   PIN Komatsu China
  ["SN: K30001-UP"]
25   TZ1354-8-25   [2]   PIN Komatsu China
  ["SN: K30001-UP"]
26   TZJW1516-G45-9   [1]   O-RING (KIT) Komatsu China
  ["SN: K30001-UP"] analogs:["TZW4513209"]
27   TZJW1516-G35-9   [1]   O-RING (KIT) Komatsu 0.01 kg.
  ["SN: K30001-UP"]
28   TZB-2101   [1]   BLEEDER Komatsu China
  ["SN: K30001-UP"] analogs:["TZ000B2101"]
29   01252-31035   [14]   BOLT Komatsu 0.034 kg.
  ["SN: K30001-UP"] analogs:["0125261035"]
30   07000-12014   [1]   O-RING (KIT) Komatsu China 0.01 kg.
  ["SN: K30001-UP"] analogs:["0700002014"]
31   07040-11409   [1]   PLUG Komatsu 0.033 kg.
  ["SN: K30001-UP"]
32   07000-12011   [1]   O-RING (KIT) Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["YM24315000110", "0700002011"]
33   TZSBP-1-8   [2]   PLUG Komatsu China
  ["SN: K30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     202-966-4911   [1]   MOTOR ASS'Y,SWING (TZ504S000002-A) Komatsu China
  ["SN: K30001-UP"] analogs:["RM2029664911", "2029664910"] |1.
     TZ504S200002-A   [1]   MOTOR ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
        TZ504S200000-A   [1]   MOTOR ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
     TZ501S2135-01   [2]   RELIEF VALVE ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
     TZ501S213500-C   [2]   RELIEF VALVE ASS'Y Komatsu China
  ["SN: K30001-UP"] |1.
8   TZ501S2032-02   [1]   RETAINER Komatsu China
  ["SN: K30001-UP"]
     TZ501S2032-01   [1]   RETAINER Komatsu China
  ["SN: K30001-UP"] |8.
9   TZ24C4106-00   [1]   PLUG Komatsu China
  ["SN: K30001-UP"]
10   TZ23C4007-00   [1]   SHIM Komatsu China
  ["SN: K30001-UP"]
11   TZ501S2037-00   [1]   POPPET Komatsu China
  ["SN: K30001-UP"]
     TZ21C4018-00   [1]   POPPET Komatsu China
  ["SN: K30001-UP"] |11.
12   TZ21C4019-00   [1]   SPRING Komatsu China
  ["SN: K30001-UP"]
13   07000-11008   [1]   O-RING (KIT) Komatsu China 0.01 kg.
  ["SN: K30001-UP"] analogs:["0700001008", "2016018950"]
14   07000-13022   [1]   O-RING (KIT) Komatsu OEM 0.001 kg.
  ["SN: K30001-UP"] analogs:["0700003022"]
15   TZARP568-019-9   [3]   O-RING (KIT) Komatsu China
  ["SN: K30001-UP"] analogs:["TZAR568019"]
K.   TZ504S9000-00   [1]   SEAL KIT Komatsu China
  ["SN: K30001-UP"]
        TZARP568-040-9   [1]   O-RING Komatsu China
  ["SN: K30001-UP"] |K.
        TZTC105-135-14   [1]   SEAL,OIL Komatsu China
  ["SN: K30001-UP"] analogs:["TZ10513514"] |K.
        TZ15Z-17-35-8   [1]   SEAL,OIL Komatsu 0.012 kg.
  ["SN: K30001-UP"] analogs:["TZ01703508"] |K.
        TZJW1516-G45-9   [1]   O-RING Komatsu China
  ["SN: K30001-UP"] analogs:["TZW4513209"] |K.
        TZJW1516-G35-9   [1]   O-RING Komatsu 0.01 kg.
  ["SN: K30001-UP"] |K.
        07000-12014   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: K30001-UP"] analogs:["0700002014"] |K.
        07000-12011   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["YM24315000110", "0700002011"] |K.
