HITACHI ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4637117 SWING MOTOR ROTARY GROUP

HITACHI ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4637117 SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4637117
ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F
Pos. Part No Qty Parts name Comments
9250922 [2]   SWING DEVICE
1 959499 [1]   RING;RETAINING
2 4637117 [1]   MOTOR;OIL (SWING)
3 9250921 [1]   T.MISSION (SWING)
4 3090862 [1]   GAUGE;LEVEL
7 4471860 [1]   PIPE
8 8067457 [1]   PIPE
10 4343365 [1]   CAP
11 456336 [2]   CORK
13 4194712 [2]   COCK
14 94-2024 [2]   PLUG
Parts on group MOTOR;OIL (SWING):
Pos. Part No Qty Parts name Comments
4637117 [1]   MOTOR;OIL
011 0365401 [1]   PISTON SUB I 0983304
011 0983304 [1]   PISTON SUB
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
020 0983301 [1]   CASING SUB
020A. +++++++ [1]   CASING
020B. +++++++ [2]   PIN
031 0960201 [1]   VALVE
033 0218824 [3]   BOLT;SOCKET
051 4654510 [2]   VALVE;RELIEF
051A. A811030 [1]   O-RING
101 0803003 [1]   SHAFT
106 0365405 [3]   SPACER
111 0803004 [1]   CYLINDER
113 0365407 [1]   BUSHING
114 0365408 [1]   SPRING
116 0365409 [12]   ROD;PUSH
117 0365410 [1]   SPACER
118 0365411 [1]   SPACER
123 0803005 [1]   RETAINER
124 0365413 [1]   PLATE
131 0719603 [1]   PLATE;VALVE
301 0983302 [1]   CASING
304 0365416 [1]   COVER
351 0803007 [2]   PLUNGER
355 0803008 [2]   SPRING
390 +++++++ [1]   PLATE I 0817703
390 +++++++ [1]   NAME-PLATE
391 0625509 [2]   PIN
401 0365417 [4]   BOLT;SOCKET
432 991345 [2]   RING;RETAINING
433 0747305 [1]   RING;RETAINING
437 0973069 [1]   RING;RETAINING
438 0931346 [1]   RING;RETAINING
443 0983303 [1]   BRG.;ROL.
444 0747306 [1]   BRG.;NEEDLE
468 0629404 [2]   PLUG
469 0803009 [2]   PLUG
471 A811110 [1]   O-RING
472 0496103 [1]   O-RING I 0983305
472 0983305 [1]   O-RING
487 0957366 [2]   O-RING
488 0984614 [2]   O-RING
491 0251914 [1]   SEAL;OIL
702 0803010 [1]   PISTON
706 0365326 [1]   O-RING
707 0365427 [1]   O-RING
712 0747307 [16]   SPRING;BRAKE
742 0365428 [3]   PLATE
743 0365429 [4]   PLATE
