HITACHI ZX110 ZX110-E ZX110M ZX125US ZX125US-E EXCAVATOR 9193375 9197339 9227636 HYDRAULIC PUMP PARTS

HITACHI ZX110 ZX110-E ZX110M ZX125US ZX125US-E EXCAVATOR 9193375 9197339 9227636 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
PUMP DEVICE 9193375 9197339 9227636 ZX110 ZX110-E ZX110M ZX125US ZX125US-E
Pos. Part No Qty Parts name Comments
+++++++ [1]   PUMP;UNIT
1 1026892 [1]   CASING;FRONT
2 2038178 [1]   SHAFT;DRIVE
3 4355286 [1]   RACE;INNER
4 4229543 [1]   RING;RETAINING
6 4280841 [1]   BRG.;ROL.
7 991342 [2]   RING;RETAINING
8 4343074 [4]   O-RING
9 4198956 [4]   PIN
10 2042069 [2]   PLATE
11 M340613 [8]   BOLT;SOCKET
12 1025666 [1]   PLATE;SWASH
13 4382272 [2]   PLATE I 4407464
13 4407464 [2]   PLATE
14 9134109 [6]   PLUG
14A. 4506408 [1]   O-RING
17 2042059 [2]   ROTOR
18 4289874 [2]   SPRING;DISC
19 3065991 [2]   BUSHING
20 3065989 [2]   RETAINER
22 8071391 [18]   PISTON
24 4410166 [2]   O-RING
26 1025540 [1]   CASING;REAR
27 2038174 [1]   SHAFT;DRIVE
28 1025667 [1]   PLATE;SWASH
29 4355279 [1]   BRG.;ROL.
30 927488 [2]   RING;RETAINING
34 3076 [1]   CASING;PUMP
35 4355272 [1]   BRG.;NEEDLE
36 4355277 [1]   BRG.;NEEDLE
36 4461927 [1]   BRG.;NEEDLE
37 4271350 [4]   PIN;KNOCK I 4422627
37 4422627 [4]   PIN;KNOCK
38 2044792 [1]   PLATE;VALVE
39 2044793 [1]   PLATE;VALVE
42 4428917 [6]   PISTON;SERVO
43 4397537 [6]   SPRING;COMPRES.
45 4409640 [2]   PIN;KNOCK
47 4432356 [2]   PIN
48 4436322 [4]   RING;BACK-UP
49 4180349 [4]   O-RING
51 4200227 [2]   PIN
52 3081504 [2]   LINK
53 4397509 [2]   PIN
53 4465289 [2]   PIN
54 4404102 [2]   PIN
55 4144013 [2]   PIN;SPRING
56 4116299 [2]   PIN;SPRING
58 M341240 [6]   BOLT;SOCKET
59 495841 [6]   WASHER;SPRING
60 M341240 [6]   BOLT;SOCKET I 4393030
60 4393030 [6]   BOLT
61 4427347 [3]   PLUG
62 9134111 [2]   PLUG
62A. 4509180 [1]   O-RING
63 9134110 [2]   PLUG
63A. 957366 [1]   O-RING
64 495841 [6]   WASHER;SPRING I A590912
64 A590912 [6]   WASHER;SPRING
66 4436271 [2]   SENSOR;PRES.
66A. 4365826 [1]   O-RING
67 4265372 [1]   SENSOR;REVOL.
68 4306888 [1]   O-RING
69 A590106 [1]   WASHER;PLANE
70 M340616 [1]   BOLT;SOCKET
71 4252767 [1]   BRACKET
72 M340613 [1]   BOLT;SOCKET
73 4169516 [1]   WASHER;SPRING
76 4515041 [4]   PIN;SPRING
77 4348665 [2]   O-RING
78 4180349 [10]   O-RING
79 4343074 [4]   O-RING
82 4320490 [1]   SEAL;OIL
83 930451 [1]   RING;RETAINING
100 4463047 [1]   KIT;SEAL
Parts on group PUMP DEVICE:
Pos. Part No Qty Parts name Comments
9193375 [1]   PUMP DEVICE
9197339 [1]   PUMP DEVICE
9227636 [1]   PUMP DEVICE
1 +++++++ [1]   PUMP;UNIT
3 9199253 [1]   REGULATOR
3 9198187 [1]   REGULATOR
4 9199254 [1]   REGULATOR
4 9198188 [1]   REGULATOR
5 4429488 [1]   PIPE
6 4293950 [2]   ELBOW;S
06A. 957366 [1]   O-RING
7 4153543 [1]   O-RING
8 4181700 [1]   PUMP;GEAR
9 M341030 [2]   BOLT;SOCKET
10 984054 [2]   WASHER;SPRING
11 4114402 [2]   WASHER
13 4340275 [1]   COUPLING
13 4464407 [1]   COUPLING
13A. 4366376 [1]   HUB
13A. 4627119 [1]   HUB
13B. 4334899 [2]   SCREW;SET
13C. 4101345 [4]   PIN;SPRING
13C. 4101345 [3]   PIN;SPRING
13D. 4334892 [4]   INSERT
13D. 4627120 [3]   INSERT
13E. 4334894 [4]   BOLT;SOCKET
13E. 4627121 [3]   BOLT;SOCKET
13F. 4334891 [1]   ELEMENT
13F. 4627118 [1]   ELEMENT
16 M492564 [2]   SCREW;DRIVE
17 +++++++ [1]   NAME-PLATE
