DOOSAN SOLAR 420LC-V EXCAVATOR 401-00255 401-00255B HYDRAULIC MAIN PUMP ROTARY GROUP AND SPARE PARTS

Name: DOOSAN SOLAR 420LC-V EXCAVATOR 401-00255 401-00255B HYDRAULIC MAIN PUMP ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

DOOSAN SOLAR 420LC-V EXCAVATOR 401-00255 401-00255B HYDRAULIC MAIN PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

SOLAR 420LC-V 401-00255 401-00255B

Pos.	Part No	Qty	Parts name	Comments
*.	401-00255KT	[1]	SEAL KIT;PUMP
-.	401-00255	[1]	PUMP	401-00255B
-.	401-00255B	[1]	PUMP	400914-00247
-.	400914-00247	[1]
1	*NA00911	[1]	POMPE
2	02057203	[1]	CONTROL
5	02031868	[1]	COVER
6	02057118	[1]	PORT PLATE WITH VALVES
7	02057200	[1]	PIPE ASS'Y
7A.	09156348	[2]	O-RING
Parts on group SOLAR 420LC-V:

Pos.	Part No	Qty	Parts name	Comments
1	09610429	[2]	COVER
1	K9002256	[2]	COVER
10	02030556	[1]	HOUSING;CONTROL
11	02031863	[1]	GASKET
12	09921021	[2]	PISTON;POSITIONING
13	09425458	[2]	TRUNNION;POSITIONING
14	02057216	[2]	COLLAR;SPRING	02067546
14	02067546	[2]
15	09432558	[2]	SPRING;PRESSURE
16	09651472	[2]	PISTON
16	0K9001926	[2]	PISTON
17	09445016	[2]	PIN;THREADED
1A.	09651448	[1]	COVER
1B.	09150108	[1]	O-RING
1C.	09085709	[1]	O-RING
1D.	09083116	[4]	SCREW;SOCKET-HEAD
1E.	09151692	[1]	SCREW;LOCKING
1F.	09086120	[1]	PIN;THREADED
1F.	2.123-00289	[1]	PIN;THREADED
1G.	09152459	[1]	NUT;SEAL LOCK
2	02057202	[1]	CONTROL MODULE
26	09083716	[2]	SCREW;HEX
2A.	02057201	[1]	CONTROL MODULE
2Aa.	02057192	[1]	HOUSING;CONTROL
2Ab.	02054797	[2]	PISTON;CONTROL
2Ac.	02054798	[2]	BUSH;CONTROL
2Ad.	09436378	[2]	PISTON;POSITIONING
2Ae.	02057199	[2]	PIN
2Af.	09430649	[4]	COLLAR;SPRING
2Ag.	09650259	[2]	SPRING;PRESSURE
2Ah.	09436380	[2]	SCREW;LOCKING
2Ai.	09420991	[2]	PIN;THREADED
2Aj.	02054799	[2]	PISTON;CONTROL
2Aj.	2.452-00006	[2]
2Ak.	02054800	[2]	BUSH;CONTROL
2Ak.	2.110-00017	[2]
2Al.	09152425	[2]	NUT;SEAL LOCK
2Am.	09086730	[2]	O-RING
2An.	02600655	[2]	O-RING
2Ao.	09083757	[2]	O-RING
2Ap.	09083027	[6]	SCREW;SOCKET-HEAD
2Aq.	09831318	[5]	PIN;DOUBLE BREAK-OFF
2Ar.	09084149	[2]	PIN;CYLINDER
2As.	09831319	[1]	PIN;DOUBLE BREAK-OFF
2At.	02600705	[1]	PLUG
2B.	02030917	[1]	HOUSING;CONTROL
2C.	09449944	[2]	PISTON;CONTROL
2D.	09449344	[2]	BUSH;SPRING
2E.	09651102	[2]	SPRING;PRESSURE
2F.	09420992	[2]	PIN;THREADED
2G.	09432513	[2]	COLLAR;SPRING
2H.	09432511	[2]	COLLAR;SPRING
2I.	02031945	[2]	SPRING;PRESSURE
2J.	02031946	[2]	SPRING;PRESSURE
2K.	09650250	[1]	BUSH
2L.	09083258	[1]	BALL
2M.	09650251	[1]	SCREW;VALVE
2N.	02600655	[4]	O-RING
2O.	9151810	[2]	O-RING
2P.	09153364	[2]	SCREW;LOCKING
2Q.	09153816	[1]	SCREW;LOCKING
2R.	09152425	[2]	NUT;SEAL LOCK
2S.	09083051	[6]	SCREW;SOCKET-HEAD
2U.	09153338	[1]	SCREW;LOCKING
37	09156647	[4]	RING;SQUARE
37	K9001927	[4]	RING;SQUARE
42	09083136	[8]	SCREW;SOCKET M16X60
43	09083142	[4]	BOLT;SOCKET M16X90
44	09084186	[2]	PIN;CYLINDER
Parts on group SOLAR 420LC-V:

Pos.	Part No	Qty	Parts name	Comments
2	02043832	[1]	ROTARY GROUP
2	210204-00029	[1]
20	09083415	[1]	RING;RETAINING
21	09831662	[1]	RING;SHAFT SEAL
21	401106-00202	[1]
22	09083430	[1]	SHIM
23	09153364	[1]	SCREW;LOCKING
24	09151694	[3]	SCREW;LOCKING
25	02601069	[2]	BEARING;PLAIN ROLLER
27	02601143	[1]	SHAFT;KEY
28	09157403	[1]	O-RING
2A.	02043825	[1]	ROTARY GROUP HYDR. SECTION
2A.	K9001909	[1]	ROTARY GROUP;SECTION
2Aa.	02042247	[1]	CYLINDER
2Ab.	02031617	[1]	PIN;CENTER
2Ab.	K9001910	[1]	PIN;CENTER
2Ac.	02031949	[7]	PISTON & PISTON RINGS
2Ac.	K9001911	[7]	PISTON & PISTON RINGS
2Ac1.	02036858	[1]	PISTON
2Ac2.	09831898	[2]	RING;STEEL SEALING
2Ad.	02045069	[1]	COLLAR;SPRING
2Ad.	02045070	[1]	COLLAR;SPRING
2Ad.	02045071	[1]	COLLAR;SPRING
2Ae.	09418513	[4]	CUP SPRING
2Af.	02033027	[1]	PLATE;RETAINING
2Ag.	09831108	[14]	SCREW;PAN HEAD	K9001916
2Ag.	K9001916	[14]	SCREW;PAN HEAD
2B.	02036865	[1]	SHAFT;DRIVE
2B.	K9001913	[1]	SHAFT;DRIVE
2C.	02031913	[1]	SHIM
2C.	02031914	[1]	SHIM
2C.	02031915	[1]	SHIM
2D.	02050516	[1]	CONTROL LENS;RIGHT-HAND
2D.	250201-01408	[1]
2E.	02031630	[1]	PLATE;BACK-UP
2E.	02031632	[1]	PLATE;BACK-UP
2E.	02031633	[1]	PLATE;BACK-UP
2E.	02031634	[1]	PLATE;BACK-UP
2E.	02031635	[1]	PLATE;BACK-UP
2E.	02031636	[1]	PLATE;BACK-UP
2E.	02031637	[1]	PLATE;BACK-UP
2F.	09083367	[1]	RING;RETAINING
2F.	K9001914	[1]	RING;RETAINING
2G.	09157648	[1]	BEARING;UNIT TAPERED-ROLLER
2H.	09151103	[1]	BEARING;TAPERED-ROLLER
3	02054462	[1]	ROTARY GROUP
3	02077073	[1]	ROTARY GROUP
3	210204-00030	[1]
3A.	02043825	[1]	ROTARY GROUP HYDR. SECTION
3A.	02075457	[1]	ROTARY GROUP HYDR. SECTION
3A.	K9001909	[1]	ROTARY GROUP;SECTION
3Aa.	02042247	[1]	CYLINDER
3Ab.	02031617	[1]	PIN;CENTER
3Ab.	02080908	[1]	PIN;CENTER
3Ab.	K9001910	[1]	PIN;CENTER
3Ac.	02031949	[7]	PISTON & PISTON RINGS
3Ac.	K9001911	[7]	PISTON & PISTON RINGS
3Ac1.	02036858	[1]	PISTON
3Ac2.	09831898	[2]	RING;STEEL SEALING
3Ad.	02045069	[1]	COLLAR;SPRING
3Ad.	02045070	[1]	COLLAR;SPRING
3Ad.	02045071	[1]	COLLAR;SPRING
3Ae.	09418513	[4]	CUP SPRING
3Af.	02033027	[1]	PLATE;RETAINING
3Ag.	09831108	[14]	SCREW;PAN HEAD
3Ag.	02602395	[14]	SCREW;PAN HEAD
3Ag.	K9001916	[14]	SCREW;PAN HEAD
3B.	02047356	[1]	SHAFT;DRIVE
3B.	K9001917	[1]	SHAFT;DRIVE
3C.	09651590	[1]	SHIM
3C.	09651589	[1]	SHIM
3C.	09651588	[1]	SHIM
3C.	09651587	[1]	SHIM
3C.	09651586	[1]	SHIM
3D.	02050517	[1]	CONTROL LENS;LEFT-HAND
3D.	250201-01409	[1]
3E.	02031630	[1]	PLATE;BACK-UP
3E.	02031631	[1]	PLATE;BACK-UP
3E.	02031632	[1]	PLATE;BACK-UP
3E.	02031633	[1]	PLATE;BACK-UP
3E.	02031634	[1]	PLATE;BACK-UP
3E.	02031635	[1]	PLATE;BACK-UP
3E.	02031636	[1]	PLATE;BACK-UP
3E.	02031637	[1]	PLATE;BACK-UP
3F.	09083367	[1]	RING;RETAINING
3F.	K9001914	[1]	RING;RETAINING
3G.	02601626	[1]	BEARING;UNIT TAPERED-ROLLER
3H.	09151103	[1]	BEARING;TAPERED-ROLLER
4	02047182	[1]	GEAR PUMP;COMPLETE
4	400910-00134	[1]
4A.	02601660	[1]	PUMP;GEAR
4B.	09083058	[4]	BOLT;SOCKET M10X20
4C.	09083067	[4]	BOLT;SOCKET M10X50
4D.	2180-1217D54	[1]	O-RING
4E.	2180-1217D57	[1]	O-RING
4F.	2180-1216D125	[1]	O-RING
5	02047183	[1]	HOUSING;PUMP
7	02036543	[1]	GEAR
7	K9001919	[1]	GEAR
8	02036540	[1]	SHAFT;STUB	02086580
8	02086580	[1]	SHAFT;STUB
9	09440107	[1]	STUD;CONNECT
