Caterpillar CAT325C CAT328DLCR CAT330C CAT330CL CAT330D CAT330DL CAT335FL CAT335FLCR CAT336D CAT336D2 CAT336D2L CAT336DL CAT336ELN CAT336F CAT336FL CAT340DL CAT340D2 CAT340F travel motor parts

Caterpillar CAT325C CAT328DLCR CAT330C CAT330CL CAT330D CAT330DL CAT335FL CAT335FLCR CAT336D CAT336D2 CAT336D2L CAT336DL CAT336ELN CAT336F CAT336FL CAT340DL CAT340D2 CAT340F travel motor parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
MOTOR GP-TRAVEL
355-5668 CAT325C CAT328DLCR CAT330C CAT330CL CAT330D CAT330DL CAT335FL CAT335FLCR CAT336D CAT336D2 CAT336D2L CAT336DL CAT336ELN CAT336F CAT336FL CAT340DL CAT340D2 CAT340F MOTOR GP-TRAVEL
S/N MPL1-UP; JBT1-UP
PART OF 191-5606, 322-8729 MOTOR & MTG GP-TRAVEL
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1 1T-0936 [1] PLUG-ORIFICE
2 4B-4158 [4] SCREW-DRIVE (NO 4X0.25-IN)
3 6V-3382 J [1] SEAL-LIP TYPE
4 8J-2559 [1] PLATE-WARNING (OIL FILL)
5 087-4786 [1] ADAPTER
6 108-6503 [9] PISTON AS
7 118-4057 [9] SPRING
8 124-1541 [2] PIN
9 124-1561 [20] SPRING-BRAKE
10 137-3708 [1] RETAINER
11 167-3855 [1] SHAFT
12 167-3857 [1] KEY
13 167-3858 [1] KEY
14 167-3859 [1] PLATE-CAM
15 167-3862 [1] PLATE-RETAINER
16 167-3863 [1] BALL
17 167-3865 [5] PLATE-SEPARATOR
18 167-3866 [4] PLATE-FRICTION
19 167-3867 [1] PLATE-PORT
20 167-3868 [1] PISTON-BRAKE
21 167-3872 [1] SPOOL
22 170-1612 J [2] SEAL
23 170-1626 J [1] RING-BACKUP
24 170-1627 J [1] RING-BACKUP
25 173-4063 [1] BARREL AS-MOTOR
26 173-4066 [1] SPACER (63.05X79.8X7-MM THK)
27 175-7436 [1] VALVE
28 175-7887 [2] DOWEL
29 180-6769 [1] BEARING AS
30 180-6770 [1] BEARING AS
31 186-5175 [1] PLUG
32 193-7901 [1] BODY AS
124-1555 [4] PLUG
33 271-6377 [1] HEAD AS
096-5916 [2] SEAT
124-1555 [4] PLUG
34 274-4512 [1] SEAT
35 274-4513 [2] RETAINER
36 345-3744 [1] PISTON-ACTUATOR
37 095-1572 J [2] SEAL-O-RING
38 095-1585 J [1] SEAL-O-RING
39 095-1596 J [1] SEAL-O-RING
40 095-1700 J [2] SEAL-O-RING
41 095-7380 [1] SPRING
42 096-3978 [1] SPRING
43 096-5919 J [2] RING-BACKUP
44 099-7030 J [1] RING-BACKUP
45 170-1616 J [1] SEAL
46 2D-6642 [2] BALL
47 2M-9780 J [1] SEAL-O-RING
48 2R-1236 [1] RING-RETAINING (LOCK, INTERNAL)
49 3D-2824 J [2] SEAL-O-RING
50 3K-0360 J [2] SEAL-O-RING
51 4K-4284 [1] RING-RETAINING
52 6V-5192 M [4] BOLT-SOCKET HEAD (M8X1.25X30-MM)
53 7Y-5219 J [2] SEAL-O-RING
54 8T-2393 M [8] BOLT-SOCKET HEAD (M16X2X60-MM)
55 9S-8005 [2] PLUG (3/4-16-THD)
56 9S-8008 [2] PLUG (1-1/16-12-THD)
  AVAILABLE REPAIR KIT(S):
272-0290 [1] KIT-SEAL (TRAVEL MOTOR)
J   KIT MARKED J SERVICES PART(S) MARKED J
M   METRIC PART
2 204-2755 [2] VALVE GP-RELIEF
